Summary of Contents for Albasca CCD-820

  • Page 1 BAR CODE...
  • Page 3 Programming Menu V3.9 Notice The manufacturer shall not be liable for technical or editorial errors or omissions contained herein; nor incidental consequential damages connection with the furnishing, performance or use of use the publication.

  • Page 4: Table Of Contents

    Contents Chapter 1 Description ............3 1.1 General ..............3 1.2 Introduction ............4 1.3 Codes Read ............4 1.4 Installation ............4 1.5 Pin Assignment ............. 6 Chapter 2 Configuration - General ........8 2.1 Flow Chart ............8 2.2 Loop of Programming ..........
  • Page 5 6.9 Setup Insertion ..........62 6.10 Scanning Line Selection for Multi Parallel lines modes ................ 65 Chapter 7 Bluetooth Configuration........66 7.1 Scanner Mode ............. 66 7.2 Out of Range ............67 7.3 Sleep Mode ............68 7.4 Batch Mode ............68 7.5 Firmware Version ..........

  • Page 6: Chapter 1 Description

    Chapter 1 Description 1.1 General Thank you for purchasing this barcode scanner with an advanced and versatile decoder. The decoder works with variety of barcode types, reading devices, and computer interfaces. It discriminates over twenty different symbologies automatically. This menu provides an easy way to configure the decoding options interface...

  • Page 7: Introduction

    1.2 Introduction The Decoder is an advanced and versatile decoding facility for barcoding systems .It works with variety of bar code types, reading devices, and computer interfaces. It discriminates about twenty different symbologies automatically. This manual provides an easy way to configure the decoding options and interface selections by scanning bar codes listed in the menu.
  • Page 8 Power supply for RS-232C scanner - There are 3 ways to supplying the power, use external +5V power supply, use optional power cable (KBDC) which taking the power from KB wedge or if the host supports +5V power from pin 9. Installing the scanner to the Host System - 1.

  • Page 9: Pin Assignment

    1.5 Pin Assignment A> Input Port for Mini Decoder DB 9 Male Pin No. Wand / CCD / Slot Reader Laser Scanner N.C. S.O.S. DATA DATA N.C. N.C. N.C. N.C. N.C. TRIGGER N.C. P. E. SHIELD SHIELD B> Output Port PC Keyboard Output DIN 5 MALE DIN 5 FEMALE...
  • Page 10 Power Lead...

  • Page 11: Chapter 2 Configuration - General

    Chapter 2 Configuration - General 2.1 Flow Chart...

  • Page 12: Loop Of Programming

    2.2 Loop of Programming The philosophy of programming parameters has been shown on the flow chart of 2.1. Basically user should 1. Scan Start of Configuration. 2. Scan all necessary labels for parameters that meet applications. 3. Scan End of Configuration to end the programming. 4.

  • Page 13: Main Page Of Configuration

    2.4 Main Page of Configuration Save Parameters %$ +/0 Recall Stored Parameters %$ + / 1 Set AII Defaults %$ + / 2 Start Configuration %$ + / 3 End Configuration %$ + / 4 Abort Configuration %$ + / 6 Version Information %$ + / 5 Save Parameters -...

  • Page 14: Chapter 3 Interface And

    Chapter 3 Interface and Reading Mode Selection 3.1 Interface SeIection <Keyboard Mode> %00 U0 RS232 Mode %00 U8 WAND Emulation %00 M2 USB Mode %0 XO8...

  • Page 15: Reading Mode Selection

    Reading Mode Selection <Good Read OFF> %0 2 7 1 Trigger ON/OFF Continuous/Trigger OFF %0 2 7 0 Testing %0 2 7 2 %0 2 7 5 Continuous/Auto Power On Flash %0 2 7 3 %0 2 7 4 Flash/Auto Power On %0 2 7 6 Reserved1 Auto Sense(Option)

  • Page 16: Chapter 4 Communication Parameters

    Ch.4 Communication Parameters 4.1 RS232 Communication Parameters A> Set Up BAUD Rate 1200 2400 % 0Y71 4800 % 0Y7 2 <9600> % 0 Y73 %0Y7 7 19200 38400 %0Y74 %0Y7 5 B> Set Up Data Bits 7 Data Bits <8 Data Bits> %0Y80 C>...
  • Page 17 D> Set Up Parity <None> Even %0YN7 %0YN 2 Mark %0YN3 %0YN1 Space %0 YN0 E Handshaking RTS/CTS Enable <RTS/CTS Disable> %0 1 8 8 %0 1 8 0 ACK/NAK Enable <ACK/NAK Disable> %0 1 4 4 XON/XOFF Enable %0 1 4 0 <XON/XOFF Disable>...

  • Page 18: Keyboard Wedge Mode Parameters

    4.2 Keyboard Wedge Mode Parameters A > Terminal Type <IBM PC/AT, PS/2> IBM PC/XT %0 Z F 0 %0 Z F 1 IBM PS/2 25, 30 NEC 9800 %0 Z F 2 %0 Z F 3 Apple Desktop Bus( IBM 5550 %0 Z F 4 %0 Z F 5 IBM 122 Key (1)
  • Page 19 B> Upper/Lower Case <No Change> %0 3 3 0 Upper Case %0 3 3 1 Lower Case %0 3 3 2 C> Caps Lock Detection Enable <Disable> %0 X8 8 %0 X80 D> Send Character by ALT Method Enable %0 3O 8 <Disable>...

  • Page 20: Output Characters Parameters

    4.3 Output Characters Parameters A> Select Terminator <CR+LF> % 7 S2 + None % 7 S7 + % 7 S0 + % 7 S1 + Space % 7 S4 + HT(TAB) % 7 S3 + STX-ETX % 7 S5 +...
  • Page 21 B> Time-out Between Characters <0 ms> %0070 5 ms %0071 10 ms %0072 25 ms %0073 50 ms % 0074 100 ms %0075 200 ms %0076 300 ms %0077...

  • Page 22: Wand Emulation Mode Parameters

    4.4 Wand Emulation Mode Parameters A> TTL Level Representation <Bar Equals High> %0 2 K4 Bar Equals Low %0 2 K0 B> Scan Speed Selection <Fast> %0 2 8 8 Slow %0 2 8 0 C> Output Format Selection <Output as Code 39> %0 2 O8 Output as Code 39 Full ASCII...

  • Page 23: Chapter 5 Bar Codes & Others

    Ch.5 Bar Codes & Others 5.1 SymboIogies Selection UPC-A <ON> %0 A4 4 %0 A40 UPC-E <ON> %0 BO8 %0 BO0 EAN-13/JAN-13/ISBN-13 <ON> %0 A22 EAN-8/JAN-8 <ON> %0 A20 %0 A11 CODE 39 <ON> %0 A10 %0 EO8 %0 EO0 CODE 128 <ON>...
  • Page 24 Interleave 25 <ON> %0GO8 Industrial 25 ON %0GO0 <OFF> %0HO8 %0HO0 Matrix 25 ON <OFF> %0 I O8 %0 I O0 CODE 93 ON <OFF> % 0KO8 %0 KO0 CODE 11 ON <OFF> % 0 LO8 %0 L O 0 China Postage ON <OFF>...
  • Page 25 Code 2 of 6ON <OFF> %0 PO8 %0 POC LCD25 ON <OFF> %0QO8 %0 QO0 Telepen ON <OFF> % 0 TO8 % 0 TO0 Reserved5 ON <OFF> % 0 RO8 %0RO0 Reserved6 ON <OFF> % 0 SO8 %0 SO0...
  • Page 26 GS1 DataBar Omnidirectional ON % 0 UO8 <OFF> % 0 UO0 GS1 DataBar Limited ON % 0VO8 <OFF> %0VO0 GS1 DataBar Expanded ON % 0WO8 <OFF> % 0WO0 Select All Bar Codes % 1 A/+...

  • Page 27: Upc/Eani/Jan Parameters

    5.2 UPC/EANI/JAN Parameters A Reading Type UPCA=EAN13 ON UPCA=EAN13<OFF> %0 AK4 ISBN-1C Enable %0AK0 ISBN-13 <Enable> %0 B88 ISSN Enable %0 B 8 0 ISSN <Disable> %0 B44 Decode with Supplement %0 B40 <Auto discriminate %01O0 Supplement> Expand UPC-E Enable %0 1O8 Expand UPC-E <Disable>...
  • Page 28 B> Supplemental Set Up <Not Transmit> Transmit 2 Code %0B3 3 Transmit 5 Code %0B3 1 Transmit 2&5 Code %0B3 2 %0B3 0 C> Check Digit Transmission UPC-A Check Digit Transmission <ON> %0 AI2 UPC-E Check Digit %0AI 0 Transmission <ON> %0 BI2 EAN-8 Check Digit %0BI0...

  • Page 29: Code 39 Parameters

    5.3 Code 39 Parameters A> Type of Code <Standard> Full ASCII %0EH1 %0EH0 Italian Pharmacy/Code 32 <OFF> Italian Pharmacy/ %0E80 Code 32 ON %0E88 B> Check Digit Transmission <Do Not Calculate Check Digit> Calculate Check Digit %0EM 2 & Transmit Calculate Check Digit %0EM 6 &...
  • Page 30 D> Decode Asterisk Enable < Disable> %0E2 2 %0E20 E> Set Up Code Length To set the fixed length: 1. Scan the “Begin“ label of the desired set. 2. Go to the Decimal Value Tables in Appendix A, scan label(s) that represents the length to be read.

  • Page 31: Code 128 Parameters

    5.4 Code 128 Parameters A> Reading Type UCC/EA1-128 Enable <UCC/EA1-128 Disable> %0F 4 4 <Enable‟]C1‟Code %0F 40 Format> Disable„]C1„Code Format %0 F 2 2 <Enable Code128 Group Separators(GS)> %0F 20 Disable Code128 Group Separators(GS) %0F 1 1 %0F 10 B> Check Digit Transmission Do Not Calculate Check Digit %0F N1...
  • Page 32 D> Set Up Code Length To set the fixed length 1. Scan the “Begin“ label of the desired set. 2. Go to the Decimal Value Tables in Appendix A scan label(s) that represents the length to be read. 3. Scan the “Complete“ label of the desired set. Repeat the steps 1 - 3 to set additional lengths.

  • Page 33: Interleave 25 Parameters

    5.5 Interleave 25 Parameters A> Check Digit Transmission <Do Not Calculate Check Digit> % 0G N3 Calculate Check Digit & Transmit %0GN7 Calculate Check Digit & Not Transmit %0GN5 B Set Up Number of Character <Even> %0G88 %0G80 C Brazilian Banking Code <Disable>...
  • Page 34 D> Set 8p Code Length To set the fixed length: 1. Scan the “Begin“ label of the desired set. 2. Go to the Decimal Value Tables in Appendix A, scan label(s) that represents the length to be read. 3. Scan the “Complete“ label of the desired set. Repeat the steps 1 - 3 to set additional lengths.

  • Page 35: Industriai 25 Parameters

    5.6 IndustriaI 25 Parameters A> Reading type IATA25 Enable %0H44 <Disable> %0 H40 B Check Digit Transmission <Do Not Calculate Check Digit> Calculate Check Digit & Transmit %0HN3 %0HN7 Calculate Check Digit & Not Transmit % 0 HN5 C> Set Up Code Length To set the fixed length 1.
  • Page 36 <Variable> % 4 H1+ Fix Length (2 Sets Available> 1. 1st Set Begin 2. Decimal Value (Appendix A) 3. 1st Set Complete % 4 H00 % 4 H01 1. 2nd Set Begin 2. Decimal Value (Appendix A) %4H00 3. 2nd Set Complete %4 H02 Minimum Length 1.

  • Page 37: Matrix 25 Parameters

    5.7 Matrix 25 Parameters A> Check Digit Transmission <Do Not Calculate Check Digit> % 0 I N 3 Calculate Check Digit & Transmit % 0 I N 7 Calculate Check Digit & Not Transmit % 0 I N 5 B> Set Up Code Length To set the fixed length: 1.
  • Page 38 <Variable> %4 I1 + Fix Length (2 Sets Available) 1. 1st Set Begin 2. Decimal Value (Appendix A) % 4 I0 0 3. 1st Set Complete % 4 I0 0 1. 2nd Set Begin 2. Decimal Value (Appendix A) % 4 I0 0 3.

  • Page 39: Codabar/Nw7 Parameters

    5.8 CODABAR/NW7 Parameters A> Set Up Start/Stop Characters Upon Transmission <OFF> %C J H1 %0 J H0 B> Transmission Type of Start/Stop <A/B/C/D> <Start> <A/B/C/D> <Stop> %0 4 V F %0 4 FF A Start A Stop %0 4 V1 B Start %0 4 F1 B Stop...
  • Page 40 C> Set Up Code Length To set the fixed length: 1. Scan the “Begin“ label of the desired set. 2. Go to the Decimal Value Tables in Appendix A, scan label(s) that represents the length to be read. 3. Scan the “Complete“ label of the desired set. Repeat the steps 1 - 3 to set additional lengths.

  • Page 41: Code 93 Parameters

    5.9 Code 93 Parameters A> Check Digit Transmission <Calculate Check 2 Digits & Not Transmit> %0 KN4 Do Not Calculate Check Digit %0 KN3 B> Set Up Code Length To set the fixed length: 1. Scan the “Begin“ label of the desired set. 2.
  • Page 42 <Variable> % 4 K1 + Fix Length (2 Sets Available) 1. 1st Set Begin 2. Decimal Value (Appendix A) % 4 K0 0 3. 1st Set Complete % 4 K0 1 1. 2nd Set Begin 2. Decimal Value (Appendix A) % 4 K0 0 3.

  • Page 43: Code 11 Parameters

    5.10 Code 11 Parameters A> Check Digit Transmission <Do Not Calculate Check Digit> Calculate Check 1 %0 L N 3 Digit & Transmit %0 L N 7 Calculate Check 2 Digits & Not Transmit Calculate Check 2 %0 L N 5 Digits &...
  • Page 44 <Variable> % 4L 1 + Fix Length (2 Sets Available) 1. 1st Set Begin 2. Decimal Value (Appendix A) %4L00 3. 1st Set Complete %4L01 1. 2nd Set Begin 2. Decimal Value (Appendix A) 3. 2nd Set Complete % 4 L 0 0 % 4 L 0 2 Minimum Length 1.

  • Page 45: Msi/Plessey Code Parameters

    5.11 MSI/PLESSEY Code Parameters A> Check Digit Transmission Do Not Calculate Check Digit Calculate Check Digit % ONN3 & Transmit % ONN7 <Calculate Check Digit & Not Transmit> % ONN5 B> Set Up Code Length To set the fixed length: 1.
  • Page 46 <Variable> % 4 N1 + Fix Length (2 Sets Available) 1. 1st Set Begin 2. DecimaI VaIue (Appendix A) % 4 N0 0 3. 1st Set Complete % 4 N0 1 1. 2nd Set Begin 2. DecimaI VaIue (Appendix A) 3.

  • Page 47: Code 2 Of 6 Parameters

    5.12 Code 2 of 6 Parameters A> Check Digit Transmission <Do Not Calculate Check Digit> Calculate Check % 0 PN3 Digit & Transmit % 0 P N 7 Calculate Check Digit & Not Transmit % 0 P N 5 B> Set Up Code Length To set the fixed length: 1.
  • Page 48 <Variable> %4 P1+ Fix Length (2 Sets Available) 1. 1st Set Begin 2. Decimal Value (Appendix A) %4 P00 3. 1st Set Complete %4 P01 1. 2nd Set Begin 2. Decimal Value (Appendix A) %4 P00 3. 2nd Set Complete % 4 P02 Minimum Length 1.

  • Page 49: Lcd25 Parameters

    5.13 LCD25 Parameters A> Check Digit Transmission <Do Not Calculate Check Digit> Calculate Check Digit % 0QN3 & Transmit % 0 Q N 7 Calculate Check Digit & Not Transmit % 0 Q N 5 B> Setup Code length To set the fixed length: 1.
  • Page 50 <Variable> % 4 Q1 + Fix Length (2 Sets Available) 1. 1st Set Begin 2. Decimal Value (Appendix A) % 4Q00 3. 1st Set Complete % 4Q01 1. 2st Set Begin 2. Decimal Value (Appendix A) % 4Q00 2. 2nt Set Complete % 4Q02 Minimum Length 1.

  • Page 51: Telepen Parameters

    5.14 Telepen Parameters...
  • Page 52 <Variable> %4T1+ %4T00 %4T01 %4T02 %2%+-/ 3. Complete %2CF+...

  • Page 53: Gs1 Databar

    5.15 GS1 Databar A> GS1 DataBar Omnidirectionl <Transmit Check Digit> Don‟t Transmit %0UN7 Check Digit <Transmit %0UN5 Application ID> %0U88 Don‟t Transmit Application ID Transmit Symbology ID %0U80 %0U44 < Don’t Transmit Symbology ID> %0U40 B> GS1 DataBar Limited Parameters <Transmit Check Digit>...
  • Page 54 <Transmit Application ID> % 0 V88 Don„t Transmit Application ID Transmit Symbology ID % 0 V80 % 0 V4 4 <Don‘t Transmit Symbology ID> % 0 V4 0 C> GS1 DataBar Expanded Parameters Transmit Symbology ID % 0 W4 4 <Don‘t Transmit Symbology ID>...

  • Page 55: Chapter 6 Miscellaneous Parameters

    Ch.6 Miscellaneous Parameters 6.1 Language Selection <US English> %0 Z V0 UK English %0 Z V1 Italian %0 Z V2 Spanish %0 Z V3 French %0 Z V4 German %0 Z V5 Swedish %0 Z V6 Switzerland %0 Z V7 Hungarian %0 Z V8 Japanese...
  • Page 56 Belgium %0 Z V A Portuguese %0 Z V B Denmark %0 Z V C Netherlands %0 Z V D Turkey % 0 Z V E Reserved2 %0 Z V F...

  • Page 57: Bar Code Id

    6.2 Bar Code ID <OFF> %0 0 H1 %0 0 H0 Default %9 1 3 + With this function ON, a leading character will be added to the output string while scanning code, user may refer to the following table to know what kind of bar code is being scanned.
  • Page 58 UPC-A UPC-E %9 1 A+ EAN-13/JAN-13 %9 1 B+ EAN-8/JAN-8 %9 1Y+ %9 1Z + CODE 39 CODE 128 %9 1 E+ CODABAR/NW7 %9 1 F + Interleave 25 %9 1 J + %91G+ Industrial 25 Matrix 25 % 9 1 H+ % 9 1 I + CODE 93 CODE 11...
  • Page 59 Code 2 of 6 % 9 1 P+ Telepen % 9 1 T + LCD25 GS1 DataBar % 9 1 Q+ Omnidirectional ON % 9 1 U+ GS1 DataBar Limited ON % 9 1 V+ GS1 DataBar Expanded ON % 9 1W+ Reserved5 % 9 1R+ Reserved6...

  • Page 60: Reading Level

    6.3 Reading Level Bar Equals High <Bar Equals Low> %0 3 I 2 6.4 Accuracy %0 3 I 0 <1 Time> 2 Times (V-1040/LG700) %0 1 3 0 3 Times %0 1 3 1 4 Times %0 1 3 2 %0 1 3 3 6.5 Buzzer Beep Tone <High>...

  • Page 61: Sensitivity Of Continuous Reading Mode

    6.6 Sensitivity of Continuous Read ing Mode A> Quick Setting: <Fast> Slow %0 3 8 8 %0 3 8 0 B> Same Code Delay Reading Interval Following code sequences represent the length of time before a barcode can be rescanned at continuous and flash reading mode.

  • Page 62: Reverse Output Characters

    6.7 Reverse Output Characters <Disable> Enable Enable %03H0 %03H1 6.8 Setup Deletion To setup the deletion of output characters: Repeat the steps 1 – 6 to set additional deletion. A> Select Deletion Set Number 1st Set 2. 2nd Set %800+ 3rd Set %801+ 4.
  • Page 63 SymboIogies Selection B> UPC-A UPC-E % 8 1 A+ EAN-13/JAN-13/ISBN-13 % 8 1 B+ EAN-8/JAN-8 % 8 1 Y+ % 8 1Z + CODE 39 CODE 128 % 8 1 E+ % 8 1 F + CODABAR/N97 Interleave 25 % 8 1 J + % 8 1 G+ Industrial 25 Matrix 25...
  • Page 64 Code 2 of 6 % 81P+ Telepen LCD25 %81T+ GS1 DataBar %81 Q+ Omnidirectional GS1 DataBar Limited %81U+ GS1 DataBar % 8 1 V+ Expanded All Codes % 81W+ % 8 1 S+ None % 814+ Character Position to be Deleted C>...

  • Page 65: Setup Insertion

    6.9 Setup Insertion To setup the insertion of output characters 1. Scan the label of the desired set. 2. Scan the label of the desired symbology. 3. Go to the Decimal Value Tables in Appendix A, scan label(s) that represents the desired position to be inserted.
  • Page 66 SymboIogies Selection B> UPC-A UPC-E % 51A+ EAN-13/JAN-13/ISBN-13 % 51B+ EAN-8/JAN-8 % 51Y+ % 51Z+ CODE 39 CODE 128 % 51E+ % 51F+ CODABAR/NW7 Interleave 25 % 51J+ % 5 1 G + Industrial 25 Matrix 25 % 5 1 H + % 5 1 I + CODE 93 CODE 11...
  • Page 67 Code 2 of 6 Telepen %5 1 P+ % 5 1 T + LCD255 GS1 DataBar % 5 1 Q + Omnidirectional GS1 DataBar % 5 1 U+ Limited GS1 DataBar Expanded % 5 1 V+ % 5 1 W + All Codes None % 5 1 S+...

  • Page 68: Scanning Line Selection For Multi Parallel Lines Modes

    6.10 Scanning Line Selection for Multi Parallel lines modes <Double Click to Interchange Multi Parallel / Single line> Multiple Parallel Lines Only Single Line Only...

  • Page 69: Chapter 7 Bluetooth Configuration

    Ch7. Bluetooth Configuration BT Parameter Set Default 7.1 Scanner Mode A>Setup SPP Master Mode <SPP Master Mode> Please follow the steps to setup the communication between the scanner and cradle. 1) The scanner must scan “SPP Master Mode” barcode to set the scanner in master mode. 2) Scan the Bluetooth MAC address code located on the bottom of the cradle.

  • Page 70: Out Of Range

    C>Setup HID Slave Mode HID Slave Mode To setup the communication between the scanner and Bluetooth HID profile application device, follow the steps. The scanner must scan “HID Slave Mode” barcode to set the scanner in HID slave mode. When control the Bluetooth device to search the scanner, enter pin code to setup pairing.

  • Page 71: Sleep Mode

    7.3 Sleep Mode The scanner is equipped with sleep mode function to save battery energy when the scanner is not used for 1 minute or 10 minutes. During sleep mode, all the functions and connection will be halted until pressing the trigger button. The communication with cradle or Bluetooth device will be reconnected.

  • Page 72: Firmware Version

    7.5 Firmware Version Display the firmware version of the scanner, please scan below barcode. Scanner Firmware Version Cradle Firmware Version Scanner MAC Address Cradle MAC Address...

  • Page 73: Appendix A Decimal Value Table

    Appendix A Decimal Value Table...

  • Page 74: Appendix Bascii Table

    Appendix B ASCII Table NULL...
  • Page 75 SPACE “ „ & < >...
  • Page 77 ﹛...

  • Page 78: Appendix C Function Key Table

    Appendix C Function Key Table Insert Delete Home Page Up Page Down Left Right Down...

  • Page 79: Appendix D Decimal Value Table Ii

    Appendix D Decimal Value Table II Enter...
  • Page 80 All above programming are subject to change without notice.
  • Page 81 %$+/0 %$+/1 %$+/2 %$+/3 %$+/4 %$+/6 %$+/5 Ver3.9 0145-85E00I1...
