Albasca MK-5800BT Configuration Manual

Bluetooth 2d imager barcode scanner
Hide thumbs Also See for MK-5800BT:
Table of Contents

Advertisement

Quick Links

Download this manual
MK-5800BT
Bluetooth 2D Imager Barcode Scanner
Configuration Guide

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MK-5800BT and is the answer not in the manual?

Questions and answers

Related Manuals for Albasca MK-5800BT

Summary of Contents for Albasca MK-5800BT

  • Page 1 MK-5800BT Bluetooth 2D Imager Barcode Scanner Configuration Guide...
  • Page 2 FEDERAL COMMUNICATIONS COMMISSION INTERFERENCE STATEMENT This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.

  • Page 3: Revision History

    Revision History Version Description Date V1.0.0 Initial release. November 4, 2016 1. Added the Specify Decoding Area (Top, Bottom, Left, Right) feature in Chapter 4. 2. Added Chapter 10 Batch Programming. 3. Changed the range of Decode Session Timeout to 100ms - 3,600,000ms.

  • Page 4: Table Of Contents

    Table Of Contents Revision History ............................... -3- Chapter 1 Getting Started ..........................1 Barcode Programming ..........................1 Factory Defaults ............................1 Chapter 2 Scan Mode ............................2 Batch Mode .............................. 2 Trigger Mode ............................3 Decode Session Timeout ......................... 3 Level Trigger/Pulse Trigger ......................
  • Page 5 Chapter 4 Illumination & Aiming........................15 Illumination ............................. 15 Aiming ..............................16 Chapter 5 Beep & LED Notifications ......................17 Startup Beep ............................17 Good Read Beep for Non-programming Barcode ................. 18 Beep Type............................18 Beep Volume ..........................19 Beep on Unknown Character ........................ 19 Good Read Beep for Programming Barcode ..................
  • Page 6 Enable/Disable All Symbologies ..................... 32 Enable/Disable 1D Symbologies ....................32 Enable/Disable 2D Symbologies ....................32 Video Reverse ..........................33 1D Symbologies ............................. 34 Code 128 ............................34 Restore Factory Defaults......................34 Enable/Disable Code 128......................34 Set Length Range for Code 128 ..................... 34 GS1-128 (UCC/EAN-128) ......................
  • Page 7 EAN-13 Beginning with 977 Add-On Code Required ............. 44 EAN-13 Beginning with 978 Add-On Code Required ............. 44 EAN-13 Beginning with 979 Add-On Code Required ............. 45 ISSN ..............................46 Restore Factory Defaults......................46 Enable/Disable ISSN ....................... 46 Add-On Code ........................... 47 Add-On Code Required ......................
  • Page 8 ITF-14 ............................. 58 ITF-6 ............................... 59 Matrix 2 of 5 ............................ 60 Restore Factory Defaults......................60 Enable/Disable Matrix 2 of 5 ....................60 Set Length Range for Matrix 2 of 5 ..................60 Check Digit Verification ......................61 Industrial 2 of 5 ..........................62 Restore Factory Defaults......................
  • Page 9 Start/Stop Character Format ....................72 Code 93 ............................73 Restore Factory Defaults......................73 Enable/Disable Code 93......................73 Set Length Range for Code 93 ....................73 Check Digit Verification ......................74 GS1-Databar (RSS) ........................75 Restore Factory Defaults......................75 Enable/Disable GS1 Databar ....................75 Transmit Application Identifier “01”...
  • Page 10 QR Code ............................84 Restore Factory Defaults......................84 Enable/Disable QR Code ......................84 Set Length Range for QR Code ....................84 Micro QR ..........................84 QR Twin Code ......................... 85 Character Encoding ......................... 85 Data Matrix............................86 Restore Factory Defaults......................86 Enable/Disable Data Matrix .....................
  • Page 11 Appendix 1: AIM ID Table ........................98 Appendix 2: Code ID Table ......................... 101 Appendix 3: ASCII Table ........................102 Appendix 4: Parameter Programming Examples ................106 a. Program the Decode Session Timeout ..................106 b. Program the Time Period from Idle to Sleep ................106 c.

  • Page 12: Chapter 1 Getting Started

    Enter Setup Chapter 1 Getting Starte Barcode Programming Scanning the Enter Setup barcode can enable the scanner to enter the setup mode. Then you can scan a number of programming barcodes to configure your engine. To exit the setup mode, scan the Exit Setup barcode.

  • Page 13: Chapter 2 Scan Mode

    Enter Setup Chapter 2 Scan Mode Batch Mode This round of multiple scans continues until the active trigger signal is no longer present. Rereading the same barcode is not allowed if it was decoded previously in the same round. For good read, the engine transmits decoded data via communication port.

  • Page 14: Trigger Mode

    Enter Setup Trigger Mode The session continues until the barcode is decoded or decode session timeout expires or the active trigger signal is no longer present. For good read, the scanner transmits decoded data via communication port. To activate another session, the Host needs to first negate the trigger, waits 20ms or longer and then drive the TRIG pin low.

  • Page 15: Level Trigger/Pulse Trigger

    Enter Setup Level Trigger/Pulse Trigger Level trigger: Decode session is activated and continued by constant active trigger signal. The decode session ends once the barcode is decoded or decode session timeout expires. Pulse trigger: Decode session is activated by electric pulse of trigger signal. The decode session continues until the barcode is decoded or decode session timeout expires.

  • Page 16: Timeout Between Decodes (Same Barcode)

    Enter Setup Timeout between Decodes (Same Barcode) Timeout between Decodes (Same Barcode) can avoid undesired rereading of same barcode in a given period of time. To enable/disable the Timeout between Decodes (Same Barcode), scan the appropriate barcode below. Enable Timeout between Decodes (Same Barcode): Do not allow the engine to re-read same barcode before the timeout between decodes (same barcode) expires.

  • Page 17: Sense Mode

    Enter Setup Sense Mode If the Sense Mode is enabled, the scanner activates a decode session every time it detects a change in ambient illumination. The decode session continues until the barcode is decoded or the decode session timeout expires. Driving the TRIG pin on the host interface connector low can also activate a decode session.

  • Page 18: Image Stabilization Timeout

    Enter Setup Image Stabilization Timeout This parameter defines the amount of time that the scanner waits for the image to stabilize to a point that it can be decoded with more accuracy. It is programmable in 1ms increments from 0ms to 1,600ms. The default setting is 500ms.To learn how to program this parameter, see Appendix 4.

  • Page 19: Timeout Between Decodes (Same Barcode)

    Enter Setup Timeout between Decodes (Same Barcode) Timeout between Decodes (Same Barcode) can avoid undesired rereading of same barcode in a given period of time. To enable/disable the Timeout between Decodes (Same Barcode), scan the appropriate barcode below. Enable Timeout between Decodes (Same Barcode): Do not allow the scanner to re-read same barcode before the timeout between decodes (same barcode) expires.

  • Page 20: Sensitivity

    Enter Setup Sensitivity Sensitivity specifies the degree of acuteness of the scanner response to changes in ambient illumination. The higher the sensitivity, the lower requirement in illumination change to trigger the scanner. You can select an appropriate degree of sensitivity that fits the ambient environment. Medium Sensitivity Low Sensitivity High Sensitivity...

  • Page 21: Continuous Mode

    Enter Setup Continuous Mode This mode enables the scanner to scan/capture, decode and transmit over and over again. When the scanner is operating in Continuous Mode, barcode reading can be suspended/resumed through control over the trigger signal. When barcode reading is in progress, negating the trigger signal after having maintained it for 30ms or longer will suspend barcode reading;...

  • Page 22: Timeout Between Decodes (Same Barcode)

    Enter Setup Timeout between Decodes (Same Barcode) Timeout between Decodes (Same Barcode) can avoid undesired rereading of same barcode in a given period of time. To enable/disable the Timeout between Decodes (Same Barcode), scan the appropriate barcode below. Enable Timeout between Decodes (Same Barcode): Do not allow the scanner to re-read same barcode before the timeout between decodes (same barcode) expires.

  • Page 23: Chapter 3 Scanning Preferences

    Enter Setup Chapter 3 Scanning Preferences Introduction This chapter contains information as to how to adapt your scanner to various applications with preference setting. For instance, to narrow the field of view of the scanner to make sure it reads only those barcodes intended by the user.

  • Page 24: Specify Decoding Area

    Enter Setup Specify Decoding Area If Specific Area Decoding is enabled, the scanner only reads barcodes that intersect the predefined decoding area. The default decoding area is an area of 40% top, 60% bottom, 40% left and 60% right of the scanner’s field of view, as shown in the figure below.
  • Page 25 Enter Setup Top of Decoding Area Bottom of Decoding Area Left of Decoding Area Right of Decoding Area ** Exit Setup...

  • Page 26: Chapter 4 Illumination & Aiming

    Enter Setup Chapter 4 Illumination & Aiming Illumination A couple of illumination options are provided to improve the lighting conditions during every image capture: Normal: Illumination LEDs are turned on during image capture. Always ON: Illumination LEDs keep ON after the engine is powered on. OFF: Illumination LEDs are OFF all the time.

  • Page 27: Aiming

    Enter Setup Aiming When scanning/capturing image, the scanner projects an aiming pattern which allows positioning the target barcode within its field of view and thus makes decoding easier. Normal: The scnner projects an aiming pattern only during barcode scanning/capture. Always ON: Aiming pattern is constantly ON after the scanner is powered on. OFF: Aiming pattern is OFF all the time.

  • Page 28: Chapter 5 Beep & Led Notifications

    Enter Setup Chapter 5 Beep & LED Notifications Startup Beep If startup beep is enabled, the scanner will beep after being turned on. ** Enable Startup Beep Disable Startup Beep ** Exit Setup...

  • Page 29: Good Read Beep For Non-Programming Barcode

    Enter Setup Good Read Beep for Non-programming Barcode The scanner can provide a PWM output to an external driver circuit to drive a beeper after decoding a non-programming barcode. Scan the appropriate barcode below to enable or disable the emission of good read beep.

  • Page 30: Beep Volume

    Enter Setup Beep Volume ** Loud Medium Beep on Unknown Character Due to the differences in keyboard layouts, some characters contained in barcode data may be unavailable on the selected keyboard (USB HID-KBW). As a result, the scanner fails to transmit the unknown characters.

  • Page 31: Good Read Beep For Programming Barcode

    Enter Setup Good Read Beep for Programming Barcode ** Good Read Beep On for Programming Barcode Good Read Beep Off for Programming Barcode ** Exit Setup...

  • Page 32: Transmit Ngr Message

    Enter Setup Transmit NGR Message Scan a barcode below to select whether or not to transmit a user-defined NGR (Not Good Read) message when a barcode is not decoded. Transmit NGR Message ** Do Not Transmit NGR Message Edit NGR Message To edit an NGR message, scan the Edit NGR Message barcode and the numeric barcodes corresponding to the ASCII values (hex) of desired characters and then scan the Save barcode.

  • Page 33: Chapter 6 Prefix & Suffix

    Enter Setup Chapter 6 Prefix & Suffix In many applications, barcode data needs to be edited and distinguished from one another. Usually AIM ID and Code ID can be used as identifiers, but in some special cases customized prefix and terminating character suffix like Carriage Return or Line Feed can also be the alternatives.

  • Page 34: Global Settings

    Enter Setup Global Settings Enable/Disable All Prefix/Suffix Disable All Prefix/Suffix: Transmit barcode data with no prefix/suffix. Enable All Prefix/Suffix: Allow user to append Code ID prefix, AIM ID prefix, custom prefix/suffix and terminating character to the barcode data before the transmission. Enable All Prefix/Suffix Disable All Prefix/Suffix Prefix Sequences...

  • Page 35: Custom Prefix

    Enter Setup Custom Prefix Enable/Disable Custom Prefix If custom prefix is enabled, you are allowed to append to the data a user-defined prefix that cannot exceed 11 characters. Enable Custom Prefix ** Disable Custom Prefix Set Custom Prefix To set a custom prefix, scan the Set Custom Prefix barcode and the numeric barcodes representing the hexadecimal values of a desired prefix and then scan the Save barcode.

  • Page 36: Aim Id Prefix

    Enter Setup AIM ID Prefix AIM (Automatic Identification Manufacturers) IDs and ISO/IEC 15424 standards define symbology identifiers and data carrier identifiers. (For the details, see the “Appendix 1: AIM ID Table” section). If AIM ID prefix is enabled, the engine will add the symbology identifier before the scanned data after decoding.

  • Page 37: Modify Code Id

    Enter Setup Modify Code ID Code ID of each symbology can be programmed separately. See the following example to learn how to program a Code ID. Example: Set the Code ID of PDF417 to “p” Check the hex value of “p” in the ASCII Table. (“p”: 70) Scan the Enter Setup barcode.
  • Page 38 Enter Setup Modify AIM-128 Code ID Modify EAN-8 Code ID Modify EAN-13 Code ID Modify UPC-E Code ID Modify UPC-A Code ID Modify ISBN Code ID Modify ISSN Code ID Modify Code 39 Code ID Modify Code 93 Code ID Modify Interleaved 2 of 5 Code ID ** Exit Setup...
  • Page 39 Enter Setup Modify ITF-14 Code ID Modify ITF-6 Code ID Modify Codabar Code ID Modify Industrial 25 Code ID Modify Standard 25 Code ID Modify Matrix 25 Code ID Modify COOP 25 Code ID Modify Code 11 Code ID Modify Plessey Code ID Modify MSI/Plessey Code ID Modify GS1 Databar Code ID ** Exit Setup...

  • Page 40: Custom Suffix

    Enter Setup Custom Suffix Enable/Disable Custom Suffix If custom suffix is enabled, you are allowed to append to the data a user-defined suffix that cannot exceed 11 characters. Enable Custom Suffix Disable Custom Suffix Set Custom Suffix To set a custom suffix, scan the Set Custom Suffix barcode and the numeric barcodes representing the hexadecimal values of a desired suffix and then scan the Save barcode.

  • Page 41: Terminating Character Suffix

    Enter Setup Terminating Character Suffix A terminating character can be used to mark the end of data, which means nothing can be added after it. A terminating character suffix cannot exceed 7 characters. Enable/Disable Terminating Character Suffix To enable/disable terminating character suffix, scan the appropriate barcode below. Enable Terminating Character Suffix Disable Terminating Character Suffix ** Exit Setup...

  • Page 42: Set Terminating Character Suffix

    Enter Setup Set Terminating Character Suffix The engine provides a shortcut for setting the terminating character suffix to CR (0x0D) or CRLF (0x0D,0x0A) and enabling it by scanning the appropriate barcode below. Terminating Character CR (0x0D) Terminating Character CRLF (0x0D,0x0A) To set a terminating character suffix, scan the Set Terminating Character Suffix barcode and the numeric barcodes representing the hexadecimal value of a desired terminating character and then scan the Save barcode.

  • Page 43: Chapter 7 Symbologies

    Enter Setup Chapter 7 Symbologies Global Settings Enable/Disable All Symbologies If the Disable All Symbologies feature is enabled, the scanner will not be able to read any non-programming barcodes except the programming barcodes. Enable All Symbologies Disable All Symbologies Enable/Disable 1D Symbologies If the Disable 1D Symbologies feature is enabled, the scanner will not be able to read any 1D barcodes.

  • Page 44: Video Reverse

    Enter Setup Video Reverse The Video Reverse feature only applies to 2D barcodes. Regular barcode: Dark image on a bright background. Inverse barcode: Bright image on a dark background. The examples of regular barcode and inverse barcode are shown below. Regular Barcode Inverse Barcode Video Reverse is used to allow the scanner to read barcodes that are inverted.

  • Page 45: 1D Symbologies

    Enter Setup 1D Symbologies Code 128 Restore Factory Defaults Restore the Factory Defaults of Code 128 Enable/Disable Code 128 Enable Code 128 Disable Code 128 Set Length Range for Code 128 Set the Minimum Length Set the Maximum Length ** Exit Setup...

  • Page 46: Gs1-128 (Ucc/Ean-128)

    Enter Setup GS1-128 (UCC/EAN-128) Restore Factory Defaults Restore the Factory Defaults of GS1-128 Enable/Disable GS1-128 Enable GS1-128 Disable GS1-128 Set Length Range for GS1-128 Set the Minimum Length Set the Maximum Length ** Exit Setup...

  • Page 47: Restore Factory Defaults

    Enter Setup AIM-128 Restore Factory Defaults Restore the Factory Defaults of AIM-128 Enable/Disable AIM-128 ** Enable AIM-128 Disable AIM-128 Set Length Range for AIM-128 Set the Minimum Length Set the Maximum Length ** Exit Setup...

  • Page 48: Restore Factory Defaults

    Enter Setup EAN-8 Restore Factory Defaults Restore the Factory Defaults of EAN-8 Enable/Disable EAN-8 ** Enable EAN-8 Disable EAN-8 ** Exit Setup...

  • Page 49: Transmit Check Digit

    Enter Setup Transmit Check Digit EAN-8 is 8 digits in length with the last one as its check digit used to verify the integrity of the data. Transmit EAN-8 Check Digit Do Not Transmit EAN-8 Check Digit Add-On Code An EAN-8 barcode can be augmented with a two-digit or five-digit add-on code to form a new one. In the examples below, the part surrounded by blue dotted line is an EAN-8 barcode while the part circled by red dotted line is add-on code.

  • Page 50: Ean-8 Add-On Code Required

    Enter Setup Add-On Code Required When EAN-8 Add-On Code Required is selected, the scanner will only read EAN-8 barcodes that contain add-on codes. EAN-8 Add-On Code Required ** EAN-8 Add-On Code Not Required EAN-8 Extension Disable EAN-8 Zero Extend: Transmit EAN-8 barcodes as is. Enable EAN-8 Zero Extend: Add five leading zeros to decoded EAN-8 barcodes to extend to13 digits.

  • Page 51: Restore Factory Defaults

    Enter Setup EAN-13 Restore Factory Defaults Restore the Factory Defaults of EAN-13 Enable/Disable EAN-13 ** Enable EAN-13 Disable EAN-13 Transmit Check Digit Transmit EAN-13 Check Digit Do Not Transmit EAN-13 Check Digit ** Exit Setup...

  • Page 52: Add-On Code

    Enter Setup Add-On Code An EAN-13 barcode can be augmented with a two-digit or five-digit add-on code to form a new one. Enable 2-Digit Add-On Code Disable 2-Digit Add-On Code Enable 5-Digit Add-On Code Disable 5-Digit Add-On Code Enable 2-Digit Add-On Code/ Enable 5-Digit Add-On Code: The scanner decodes a mix of EAN-13 barcodes with and without 2-digit/5-digit add-on codes.

  • Page 53: Ean-13 Beginning With 290 Add-On Code Required

    Enter Setup EAN-13 Beginning with 290 Add-On Code Required This setting programs the scanner to require an add-on code (2-digit or 5-digit) on EAN-13 barcodes that begin with “290”. The following settings can be programmed: Require Add-On Code: All EAN-13 barcodes that begin with “290” must have a 2-digit or 5-digit add-on code.

  • Page 54: Ean-13 Beginning With 414/419 Add-On Code Required

    Enter Setup EAN-13 Beginning with 414/419 Add-On Code Required This setting programs the scanner to require an add-on code (2-digit or 5-digit) on EAN-13 barcodes that begin with a “414” or “419”. The following settings can be programmed: Require Add-On Code: All EAN-13 barcodes that begin with a “414” or “419” must have a 2-digit or 5-digit add-on code.

  • Page 55: Ean-13 Beginning With 977 Add-On Code Required

    Enter Setup EAN-13 Beginning with 977 Add-On Code Required This setting programs the scanner to require an add-on code (2-digit or 5-digit) on EAN-13 barcodes that begin with “977”. The following settings can be programmed: Require Add-On Code: All EAN-13 barcodes that begin with “977” must have a 2-digit or 5-digit add-on code.

  • Page 56: Ean-13 Beginning With 979 Add-On Code Required

    Enter Setup EAN-13 Beginning with 979 Add-On Code Required This setting programs the scanner to require an add-on code (2-digit or 5-digit) on EAN-13 barcodes that begin with “979”. The following settings can be programmed: Require Add-On Code: All EAN-13 barcodes that begin with “979” must have a 2-digit or 5-digit add-on code.

  • Page 57: Issn

    Enter Setup ISSN Restore Factory Defaults Restore the Factory Defaults of ISSN Enable/Disable ISSN Enable ISSN ** Disable ISSN ** Exit Setup...

  • Page 58: Add-On Code

    Enter Setup Add-On Code An ISSN barcode can be augmented with a two-digit or five-digit add-on code to form a new one. Enable 2-Digit Add-On Code Disable 2-Digit Add-On Code Enable 5-Digit Add-On Code Disable 5-Digit Add-On Code Enable 2-Digit Add-On Code/ Enable 5-Digit Add-On Code: The scanner decodes a mix of ISSN barcodes with and without 2-digit/5-digit add-on codes.

  • Page 59: Isbn

    Enter Setup ISBN Restore Factory Default Restore the Factory Defaults of ISBN Enable/Disable ISBN ** Enable ISBN Disable ISBN Set ISBN Format ** ISBN-13 ISBN-10 ** Exit Setup...

  • Page 60: Add-On Code

    Enter Setup Add-On Code An ISBN barcode can be augmented with a two-digit or five-digit add-on code to form a new one. Enable 2-Digit Add-On Code Disable 2-Digit Add-On Code Enable 5-Digit Add-On Code Disable 5-Digit Add-On Code Enable 2-Digit Add-On Code/ Enable 5-Digit Add-On Code: The scanner decodes a mix of ISBN barcodes with and without 2-digit/5-digit add-on codes.

  • Page 61: Upc-E

    Enter Setup UPC-E Restore Factory Defaults Restore the Factory Defaults of UPC-E Enable/Disable UPC-E Enable UPC-E Disable UPC-E Transmit Check Digit Transmit UPC-E Check Digit Do Not Transmit UPC-E Check Digit ** Exit Setup...

  • Page 62: Add-On Code

    Enter Setup Add-On Code A UPC-E barcode can be augmented with a two-digit or five-digit add-on code to form a new one. Enable 2-Digit Add-On Code Disable 2-Digit Add-On Code Enable 5-Digit Add-On Code Disable 5-Digit Add-On Code Enable 2-Digit Add-On Code/ Enable 5-Digit Add-On Code: The scanner decodes a mix of UPC-E barcodes with and without 2-digit/5-digit add-on codes.

  • Page 63: Transmit System Character "0

    Enter Setup Transmit System Character “0” The first character of UPC-E barcode is the system character “0”. Transmit System Character “0” Do Not Transmit System Character “0” UPC-E Extension Disable UPC-E Extend: Transmit UPC-E barcodes as is. Enable UPC-E Extend: Extend UPC-E barcodes to make them compatible in length to UPC-A. Enable UPC-E Extend Disable UPC-E Extend ** Exit Setup...

  • Page 64: Upc-A

    Enter Setup UPC-A Restore Factory Defaults Restore the Factory Defaults of UPC-A Enable/Disable UPC-A Enable UPC-A Disable UPC-A Transmit Check Digit Transmit UPC-A Check Digit Do Not Transmit UPC-A Check Digit ** Exit Setup...

  • Page 65: Add-On Code

    Enter Setup Add-On Code A UPC-A barcode can be augmented with a two-digit or five-digit add-on code to form a new one. Enable 2-Digit Add-On Code Disable 2-Digit Add-On Code Enable 5-Digit Add-On Code Disable 5-Digit Add-On Code Enable 2-Digit Add-On Code/ Enable 5-Digit Add-On Code: The scanner decodes a mix of UPC-A barcodes with and without 2-digit/5-digit add-on codes.

  • Page 66: Transmit Preamble Character

    Enter Setup Transmit Preamble Character Preamble characters (Country Code and System Character) can be transmitted as part of a UPC-A barcode. Select one of the following options for transmitting UPC-A preamble to the host device: transmit system character only or transmit system character and country code (“0” for USA). System Character &...

  • Page 67: Interleaved 2 Of 5

    Enter Setup Interleaved 2 of 5 Restore Factory Defaults Restore the Factory Defaults of Interleaved 2 of 5 Enable/Disable Interleaved 2 of 5 ** Enable Interleaved 2 of 5 Disable Interleaved 2 of 5 Set Length Range for Interleaved 2 of 5 Set the Minimum Length Set the Maximum Length ** Exit Setup...

  • Page 68: Check Digit Verification

    Enter Setup Check Digit Verification A check digit is optional for Interleaved 2 of 5 and can be added as the last digit. It is a calculated value used to verify the integrity of the data. Disable: The scanner transmits Interleaved 2 of 5 barcodes as is. Do Not Transmit Check Digit After Verification: The scanner checks the integrity of all Interleaved 2 of 5 barcodes to verify that the data complies with the check digit algorithm.
  • Page 69 Enter Setup ITF-14 ITF-14 is a special kind of Interleaved 2 of 5 with a length of 14 characters and the last character as the check character. Restore the Factory Defaults of ITF-14 Disable ITF-14 Enable ITF-14 But Do Not Transmit Check Digit Enable ITF-14 and Transmit Check Digit Note: It is advisable not to enable ITF-14 and Interleaved 2 of 5 at the same time.
  • Page 70 Enter Setup ITF-6 ITF-6 is a special kind of Interleaved 2 of 5 with a length of 6 characters and the last character as the check character. Restore the Factory Defaults of ITF-6 ** Disable ITF-6 Enable ITF-6 But Do Not Transmit Check Digit Enable ITF-6 and Transmit Check Digit Note: It is advisable not to enable ITF-6 and Interleaved 2 of 5 at the same time.

  • Page 71: Matrix 2 Of 5

    Enter Setup Matrix 2 of 5 Restore Factory Defaults Restore the Factory Defaults of Matrix 2 of 5 Enable/Disable Matrix 2 of 5 Enable Matrix 2 of 5 ** Disable Matrix 2 of 5 Set Length Range for Matrix 2 of 5 Set the Minimum Length Set the Maximum Length ** Exit Setup...

  • Page 72: Check Digit Verification

    Enter Setup Check Digit Verification Disable Do Not Transmit Check Digit After Verification Transmit Check Digit After Verification ** Exit Setup...

  • Page 73: Industrial 2 Of 5

    Enter Setup Industrial 2 of 5 Restore Factory Defaults Restore the Factory Defaults of Industrial 2 of 5 Enable/Disable Industrial 2 of 5 Enable Industrial 2 of 5 Disable Industrial 2 of 5 Set Length Range for Industrial 2 of 5 Set the Minimum Length Set the Maximum Length ** Exit Setup...

  • Page 74: Check Digit Verification

    Enter Setup Check Digit Verification Disable Transmit Check Digit After Verification Do Not Transmit Check Digit After Verification ** Exit Setup...

  • Page 75: Standard 2 Of 5（Iata 2 Of 5

    Enter Setup Standard 2 of 5（IATA 2 of 5） Restore Factory Defaults Restore the Factory Defaults of Standard 25 Enable/Disable Standard 25 Enable Standard 25 Disable Standard 25 Set Length Range for Standard 25 Set the Minimum Length Set the Maximum Length ** Exit Setup...

  • Page 76: Check Digit Verification

    Enter Setup Check Digit Verification Disable Transmit Check Digit After Verification Do Not Transmit Check Digit After Verification ** Exit Setup...

  • Page 77: Code 39

    Enter Setup Code 39 Restore Factory Defaults Restore the Factory Defaults of Code 39 Enable/Disable Code 39 ** Enable Code 39 Disable Code 39 Transmit Start/Stop Character Transmit Start/Stop Character Do Not Transmit Start/Stop Character ** Exit Setup...

  • Page 78: Set Length Range For Code 39

    Enter Setup Set Length Range for Code 39 Set the Minimum Length Set the Maximum Length Check Digit Verification Disable Transmit Check Digit After Verification Do Not Transmit Check Digit After Verification Enable/Disable Code 39 Full ASCII The engine can be configured to identify all ASCII characters by scanning the appropriate barcode below. Enable Code 39 Full ASCII Disable Code 39 Full ASCII ** Exit Setup...

  • Page 79: Enable/Disable Code 32

    Enter Setup Enable/Disable Code 32 Code 32 is a variant of Code 39 used by the Italian pharmaceutical industry. Scan the appropriate bar code below to enable or disable Code 32. Code 39 must be enabled and Code 39 check digit verification must be disabled for this parameter to function.

  • Page 80: Transmit Code 32 Check Digit

    Enter Setup Transmit Code 32 Check Digit Code 32 must be enabled for this parameter to function. ** Do Not Transmit Code 32 Check Digit Transmit Code 32 Check Digit Transmit Code 32 Start/Stop Character Code 32 must be enabled for this parameter to function. ** Do Not Transmit Code 32 Start/Stop Character Transmit Code 32 Start/Stop Character ** Exit Setup...

  • Page 81: Codabar

    Enter Setup Codabar Restore Factory Defaults Restore the Factory Defaults of Codabar Enable/Disable Codabar ** Enable Codabar Disable Codabar Set Length Range for Codabar Set the Minimum Length Set the Maximum Length ** Exit Setup...

  • Page 82: Check Digit Verification

    Enter Setup Check Digit Verification Disable Transmit Check Digit After Verification Do Not Transmit Check Digit After Verification Transmit Start/Stop Character Transmit Start/Stop Character Do not Transmit Start/Stop Character ** Exit Setup...

  • Page 83: Start/Stop Character Format

    Enter Setup Start/Stop Character Format You can choose your desired start/stop character format by scanning the appropriate barcode below. ** ABCD/ABCD as the Start/Stop Character ABCD/TN*E as the Start/Stop Character Start/Stop Character in Uppercase Start/Stop Character in Lowercase ** Exit Setup...

  • Page 84: Code 93

    Enter Setup Code 93 Restore Factory Defaults Restore the Factory Defaults of Code 93 Enable/Disable Code 93 ** Enable Code 93 Disable Code 93 Set Length Range for Code 93 Set the Minimum Length Set the Maximum Length ** Exit Setup...

  • Page 85: Check Digit Verification

    Enter Setup Check Digit Verification Disable Do Not Transmit Check Digit After Verification Transmit Check Digit After Verification ** Exit Setup...

  • Page 86: Gs1-Databar (Rss)

    Enter Setup GS1-Databar (RSS) Restore Factory Defaults Restore the Factory Defaults of GS1-Databar Enable/Disable GS1 Databar ** Enable GS1-DataBar Disable GS1-DataBar Transmit Application Identifier “01” Transmit Application Identifier “01” Do Not Transmit Application Identifier “01” ** Exit Setup...

  • Page 87: Code 11

    Enter Setup Code 11 Restore Factory Defaults Restore the Factory Defaults of Code 11 Enable/Disable Code 11 ** Enable Code 11 Disable Code 11 Set Length Range for Code 11 Set the Minimum Length Set the Maximum Length ** Exit Setup...

  • Page 88: Transmit Check Digit

    Enter Setup Transmit Check Digit Transmit Check Digit ** Do Not Transmit Check Digit Check Digit Verification Disable One Check Digit, MOD11 Two Check Digits, MOD11/MOD11 Two Check Digits, MOD11/MOD9 One Check Digit, MOD11 (Len<=10) One Check Digit, MOD11 (Len<=10) Two Check Digits, MOD11/MOD11 (Len>10) Two Check Digits, MOD11/MOD9 (Len>10)

  • Page 89: Plessey

    Enter Setup Plessey Restore Factory Defaults Restore the Factory Defaults of Plessey Enable/Disable Plessey ** Enable Plessey Disable Plessey Set Length Range for Plessey Set the Minimum Length Set the Maximum Length ** Exit Setup...

  • Page 90: Check Digit Verification

    Enter Setup Check Digit Verification Disable Do Not Transmit Check Digit After Verification Transmit Check Digit After Verification ** Exit Setup...

  • Page 91: Msi-Plessey

    Enter Setup MSI-Plessey Restore Factory Defaults Restore the Factory Defaults of MSI-Plessey Enable/Disable MSI-Plessey ** Enable MSI-Plessey Disable MSI-Plessey Set Length Range for MSI-Plessey Set the Minimum Length Set the Maximum Length ** Exit Setup...

  • Page 92: Transmit Check Digit

    Enter Setup Transmit Check Digit Transmit Check Digit Do Not Transmit Check Digit Check Digit Verification Disable One Check Digit, MOD10 Two Check Digits, MOD10/MOD10 Two Check Digits, MOD10/MOD11 ** Exit Setup...

  • Page 93: 2D Symbologies

    Enter Setup 2D Symbologies PDF 417 Restore Factory Defaults Restore the Factory Defaults of PDF 417 Enable/Disable PDF 417 ** Enable PDF 417 Disable PDF 417 Set Length Range for PDF 417 Set the Minimum Length Set the Maximum Length ** Exit Setup...

  • Page 94: Pdf 417 Twin Code

    Enter Setup PDF 417 Twin Code PDF417 twin code is 2 PDF417 barcodes paralleled vertically or horizontally. They must both be either regular or inverse barcodes. They must have similar specifications and be placed closely together. There are 3 options for reading PDF417 twin codes: Single PDF417 Only: Read either PDF417 code.

  • Page 95: Qr Code

    Enter Setup QR Code Restore Factory Defaults Restore the Factory Defaults of QR Code Enable/Disable QR Code ** Enable QR Code Disable QR Code Set Length Range for QR Code Set the Minimum Length Set the Maximum Length Micro QR Enable Micro QR ** Disable Micro QR ** Exit Setup...

  • Page 96: Qr Twin Code

    Enter Setup QR Twin Code QR twin code is 2 QR barcodes paralleled vertically or horizontally. They must both be either regular or inverse barcodes. They must have similar specifications and be placed closely together. There are 3 options for reading QR twin codes: Single QR Only: Read either QR code.

  • Page 97: Data Matrix

    Enter Setup Data Matrix Restore Factory Defaults Restore the Factory Defaults of Data Matrix Enable/Disable Data Matrix ** Enable Data Matrix Disable Data Matrix Set Length Range for Data Matrix Set the Minimum Length Set the Maximum Length ** Exit Setup...

  • Page 98: Rectangular Barcode

    Enter Setup Rectangular Barcode ** Enable Rectangular Barcode Disable Rectangular Barcode Mirror Image ** Decode Mirror Images Do Not Decode Mirror Images ** Exit Setup...

  • Page 99: Data Matrix Twin Code

    Enter Setup Data Matrix Twin Code Data Matrix twin code is 2 Data Matrix barcodes paralleled vertically or horizontally. They must both be either regular or inverse barcodes. They must have similar specifications and be placed closely together. There are 3 options for reading Data Matrix twin codes: Single Data Matrix Only: Read either Data Matrix code.

  • Page 100: Chinese Sensible Code

    Enter Setup Chinese Sensible Code Restore Factory Defaults Restore the Factory Defaults of Chinese Sensible Code Enable/Disable Chinese Sensible Code Enable Chinese Sensible Code ** Disable Chinese Sensible Code Set Length Range for Chinese Sensible Code Set the Minimum Length Set the Maximum Length ** Exit Setup...

  • Page 101: Chapter 8 Image Control

    Enter Setup Chapter 8 Image Control Image Flipping The user may get reversed images when the engine is installed in non-standard ways. When it happens, image flipping can be used to right the “wrong”. The following figures illustrate standard image and three flipped images. ...

  • Page 102: Flip

    Enter Setup Flip ** Do Not Flip Flip Vertically Flip Horizontally Flip Horizontally and Vertically Flip Vertically Flip Vertically Do Not Flip Vertically Flip Horizontally Flip Horizontally Do Not Flip Horizontally ** Exit Setup...

  • Page 103: Chapter 9 Batch Programming

    Enter Setup Chapter 9 Batch Programming Introduction Batch programming enables users to integrate a batch of commands into a single batch barcode. Listed below are batch programming rules: 1. Command format: Command + “=” + Parameter Value. 2. Each command is terminated by a semicolon (;). Note that there is no space between a command and its terminator semicolon.

  • Page 104: Create A Batch Command

    Enter Setup Create a Batch Command A batch command may contain a number of individual commands each of which is terminated by a semicolon (;). Command Structure: Command (+ “=” + Parameter Value) 4 command syntaxes are described as below: 1.

  • Page 105: Create A Batch Barcode

    Enter Setup Create a Batch Barcode Batch barcodes can be produced in the format of PDF417, QR Code or Data Matrix. Example: Create a batch barcode for Illumination Always On, Sense Mode, Decode Session Timeout = 2s: 1. Input the following commands: 0200010;0302010;0313000=2000;...

  • Page 106: Use Batch Barcode

    Enter Setup Use Batch Barcode To put a batch barcode into use, scan the following barcodes. (Use the example above.) Enter Setup Enable Batch Barcode Batch Barcode Exit Setup ** Exit Setup...

  • Page 107: Chapter 10 Troubleshooting

    Chapter 10 Troubleshooting Problem: Barcodes cannot be read. Solution: 1. Find out the barcode type and verify that the barcode type is enabled. If the barcode parameters include check digit verification, select the Disable option. 2. If you do not know the barcode type, enable all symbologies. 3.
  • Page 108 Problem: Illumination and aiming beams are OFF. Solution: 1. Verify that the engine is properly powered up. 2. Send “?” to the engine. If the engine returns a reply of “!”, then send programming commands to turn on illumination and aimer. Problem: Carriage Return/Line Feed settings.

  • Page 109: Appendix

    Appendix Appendix 1: AIM ID Table Symbology AIM ID Remark Standard EAN-13 EAN-13 EAN-13 + 2/5-Digit Add-On Code Standard EAN-8 ]E4…]E1… EAN-8 EAN-8 + 2-Digit Add-On Code ]E4…]E2… EAN-8 + 5-Digit Add-On Code Standard UPC-E UPC-E UPC-E + 2/5-Digit Add-On Code Standard UPC-A UPC-A UPC-A + 2/5-Digit Add-On Code...
  • Page 110 Full ASCII enabled; do not transmit check digit Standard Codabar Codabar Transmit check digit after verification Do not transmit check digit after verification...
  • Page 111 Symbology AIM ID Remark Code 93 Standard Code 93 MOD11; transmit check digit MOD11/MOD11; transmit check digit Code 11 Do not transmit check digit after verification No check digit verification GS1-DataBar (RSS) Standard GS1-DataBar Plessey Standard Plessey MOD10; transmit check digit MOD10;...

  • Page 112: Appendix 2: Code Id Table

    Appendix 2: Code ID Table Symbology Code ID Code 128 GS1-128(UCC/EAN-128) AIM-128 EAN-8 EAN-13 ISSN ISBN UPC-E UPC-A Interleaved 2 of 5 ITF-6 ITF-14 Matrix 2 of 5 Industrial 2 of 5 Standard 2 of 5 Code 39 Codabar Code 93 Code 11 Plessey MSI-Plessey...

  • Page 113: Appendix 3: Ascii Table

    Appendix 3: ASCII Table Char (Null char.) (Start of Header) (Start of Text) (End of Text) (End of Transmission) (Enquiry) (Acknowledgment) (Bell) (Backspace) (Horizontal Tab) (Line Feed) (Vertical Tab) (Form Feed) (Carriage Return) (Shift Out) (Shift In) (Data Link Escape) (XON) (Device Control 1) (Device Control 2) (XOFF) (Device Control 3)
  • Page 114 Char (Request to Send) (Unit Separator) (Space) (Exclamation Mark) " (Double Quote) (Number Sign) (Dollar Sign) (Percent) & (Ampersand) (Single Quote) (Left / Opening Parenthesis) (Right / Closing Parenthesis) (Asterisk) (Plus) (Comma) (Minus / Dash) (Dot) (Forward Slash) (Colon) (Semi-colon) <...
  • Page 115 Char > (Greater Than) (Question Mark) (AT Symbol) (Left / Opening Bracket) (Back Slash) (Right / Closing Bracket)
  • Page 116 Char (Caret / Circumflex) (Underscore) (Grave Accent) (Left/ Opening Brace) (Vertical Bar) (Right/Closing Brace) (Tilde) (Delete)

  • Page 117: Appendix 4: Parameter Programming Examples

    Appendix 4: Parameter Programming Examples The following examples show you how to program parameters by scanning programming barcodes. a. Program the Decode Session Timeout Example: Set the decode session timeout to 1500ms Scan the Enter Setup barcode. Scan the Decode Session Timeout barcode. (See the “Decode Session Timeout” section in Chapter 3) Scan the numeric barcodes “1”, “5”, “0”...

  • Page 118: Program The Timeout Between Decodes (Same Barcode)

    d. Program the Timeout between Decodes (Same Barcode) Example: Set the timeout between decodes (same barcode) to 1000ms Scan the Enter Setup barcode. Scan the Timeout between Decodes (Same Barcode) barcode. (See the “Timeout between Decodes (Same Barcode)” section in Chapter 3) Scan the numeric barcodes “1”, “0”, “0”...

  • Page 119: Program The Decoding Area

    g. Program the Decoding Area Example: Set the decoding area to 20% top, 80% bottom, 20% left and 80% right. Scan the Enter Setup barcode. Scan the Specific Area Decoding barcode. (See the “Specific Area Decoding” section in Chapter 4) Scan the Top of Decoding Area barcode.

  • Page 120: Program The Terminating Character Suffix

    i. Program the Terminating Character Suffix Example: Set the terminating character suffix to 0x0D Scan the Enter Setup barcode. Scan the Set Terminating Character Suffix barcode. (See the “Set Terminating Character Suffix” section in Chapter 6) Scan the numeric barcodes “0” and “D”. Scan the Save barcode.

  • Page 121: Program The Length Range (Maximum/Minimum Lengths) For A Symbology

    l. Program the Length Range (Maximum/Minimum Lengths) for a Symbology Note: If minimum length is set to be greater than maximum length, the engine only decodes barcodes with either the minimum or maximum length. If you only want to read barcodes with a specific length, set both minimum and maximum lengths to be that desired length.

  • Page 122: Program The Custom Inter-Keystroke Delay

    n. Program the Custom Inter-keystroke Delay Example: Set the inter-keystroke delay to 5ms Scan the Enter Setup barcode. Scan the Custom Delay barcode. (See the “Inter-Keystroke Delay” section in Chapter 2) Scan the numeric barcodes “0” and “5”. Scan the Exit Setup barcode. (If you still need to program other parameter/feature, skip this step.) o.

  • Page 123: Appendix 5: Digit Barcodes

    Appendix 5: Digit Barcodes...

  • Page 125: Appendix 6: Save/Cancel Barcodes

    Appendix 6: Save/Cancel Barcodes After reading numeric barcode(s), you need to scan the Save barcode to save the data. If you scan the wrong digit(s), you can either scan the Cancel barcode and then start the configuration all over again, or scan the Delete the Last Digit barcode and then the correct digit, or scan the Delete All Digits barcode and then the digits you want.

  • Page 126: Appendix 7: Ascii Function Key Mapping Table

    Appendix 7: ASCII Function Key Mapping Table ASCII Function ASCII Value (HEX) No Function Key Mapping Function Key Mapping (Null char.) Null Ctrl+2 Keypad Enter Ctrl+A (Start of Header) Caps Lock Ctrl+B (Start of Text) Null Ctrl+C (End of Text) Null Ctrl+D (End of Transmission)
  • Page 127 ASCII Function Key Mapping Table (Continued) The function key mappings of the last five characters in the previous table differ from one keyboard layout to another. Country/ Function Key Mapping Keyboard Layout United States Ctrl+[ Ctrl+\ Ctrl+] Ctrl+6 Ctrl+- Belgium Ctrl+[ Ctrl+<...

  • Page 128: Appendix 8: Code Pages List

    Appendix 8: Code Pages List Numeric Barcode Needed Code Page Windows 1252 (Latin I) Windows 1251 (Cyrillic)

This manual is also suitable for:
