- Page 1 Blast Chiller / Freezer Instruction manual Model: CK640-A CK640-A_A5_v1_20190507.indb 1 2019/5/7 15:55...
-
Page 2: Safety Tips
Telephone Helpline: 1300225960 Safety Tips • Position on a flat, stable surface. • A service agent/qualified technician should carry out installation and any repairs if required. Do not remove any components or service panels on this product. • Consult Local and National Standards to comply with the following: - Health and Safety at Work Legislation - Fire Precautions... -
Page 3: Caution Risk Of Fire
Telephone Helpline: 1300225960 • This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience or knowledge, unless they have been given supervision or instruction concerning the use of the appliance by a person responsible for their safety. -
Page 4: Installation
Telephone Helpline: 1300225960 Installation • Blast chilling data refers to standard products (low fat content) with a thickness below 50 mm: therefore avoid overlaying products Note: If the unit has not been on trays or the insertion of pieces with a stored or moved in an upright much higher thickness, as this will lead to position, let it stand upright for... -
Page 5: Control Panel
Telephone Helpline: 1300225960 Insert the food probe • Before selecting which cycle to use, the probe must be inserted into the food. This allows the internal temperature of the food to be measured. • It is important that the probe is correctly connected to the unit. Note: To prevent bacterial contamination or contamination of any other biological nature, the needle probe must be disinfected after use. - Page 6 Telephone Helpline: 1300225960 Message • If it is on for ½ second every 3 seconds, the test to verify correct pin probe insertion will be ongoing • If flashing and the LED is on, then the test to verify correct pin probe insertion will have had a negative outcome and the cycle will have been started in timed mode •...
- Page 7 Telephone Helpline: 1300225960 Timed Positive Blast Chilling And Storage Cycle To start the cycle: • ensure the device is in “stand-by” mode and no procedures are running • press to select “PoS” and ensure the LED is flashing • press within 15 seconds: the display will show the duration of the blast chilling step (in minutes) •...
- Page 8 Telephone Helpline: 1300225960 During chilling: • the display shows the residual chilling time remaining • the LED is on • parameter r2 sets the chilling time duration • parameter r8 sets the operational set point • press several times to: - display the message “nEg”...
- Page 9 Telephone Helpline: 1300225960 If the temperature • the device will switch to storage mode measured by • the display will show the message “End” the pin probe • the buzzer will sound for the period of time set by parameter AA reaches the •...
- Page 10 Telephone Helpline: 1300225960 To start the cycle: • ensure the device is in “stand-by” mode and no procedures are running • press to select “nEg” and ensure the LED is flashing • press within 15 seconds: the display will show the blast chilling end-point temperature •...
-
Page 11: Setting The Configuration Parameters
Telephone Helpline: 1300225960 During storage: • the display shows the cabinet temperature • if chilling had a positive outcome, the LEDs will be on; if chilling had a negative outcome, the LEDs will be on and the will flash. • the parameter rA sets the operational set point •... -
Page 12: Cleaning, Care And Maintenance
Telephone Helpline: 1300225960 To select a • press parameter To modify a • press parameter: • press within 15 s • press or leave for 15 s To exit the • press for 4 s , or leave for 60 s procedure Note: Interrupt the power supply after altering the parameters. -
Page 13: Internal Diagnostics
Telephone Helpline: 1300225960 Internal Diagnostics Code Message Remedies Consequences Cabinet • See P0 Consequences if the error occurs while in “stand-by” mode: probe parameter • If parameter C11 is set to 0, it will not be possible to start error •... -
Page 14: Technical Specifications
Telephone Helpline: 1300225960 Fault Probable Cause Solution The appliance is The appliance is not properly levelled Adjust the screw feet to level the appliance leaking water (if applicable) The discharge outlet is blocked Clear the discharge outlet Movement of water to the drain is Clear the floor of the appliance obstructed (if applicable) -
Page 15: Declaration Of Conformity
DECLARATION OF CONFORMITY Equipment Type Countertop Blast Chiller Model CK640-A Legislation Electrical Safety Electromagnetic Compatibility Standards AS/NZS 60335.1:2011 +A1:2012 +A2:2014 +A3:2015 +A4:2017 AS/NZS 60335.2.89:2010 +A1:2013 +A2:2016 EN55014-1:2006 +A1:2009 +A2:2011 EN55014-2:2015 EN61000-3-2:2014 EN61000-3-3:2013 Producer Name Polar Producer Address 15 Badgally Road, Campbelltown, NSW 2560 I, the undersigned, hereby declare that the equipment specified above conforms to the above Legislation and Standard(s). - Page 16 http://www.polar-refrigerator.com/ CK640-A_A5_v1_20190507 CK640-A_A5_v1_20190507.indb 16 2019/5/7 15:55...
