Installation, Operating and Service Instructions for
RSAH
Models:
• RSAH111E
• RSAH111E-T
• RSAH154E
• RSAH154E-T
Manual Contents
1.
General Information . . . . . . . . . . . . . . . . . . . . . .5
2.
Pre-Installation . . . . . . . . . . . . . . . . . . . . . . . . . .7
3. Water Piping and Trim . . . . . . . . . . . . . . . . . . . .10
4.
Venting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15
5.
Electrical . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17
6.
OIl Piping . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .20
7.
System Start-Up . . . . . . . . . . . . . . . . . . . . . . . .22
8.
Operating . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .28
10. Boiler Cleaning . . . . . . . . . . . . . . . . . . . . . . . . .34
11. Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . .37
12. Service Parts . . . . . . . . . . . . . . . . . . . . . . . . . . .42
TO THE INSTALLER:
Affix these instructions adjacent to boiler.
TO THE CONSUMER:
Retain these instructions for future reference.
For service or repairs to boiler, call your heating contractor. When seeking information on boiler, provide
Boiler Model Number and Serial Number as shown on Rating Label.
110891-02 - 5/22
• Natural Draft
• Oil-Fired
• Water Boiler
• B20 Ready
