ALTA
Installation, Operating and Service Instructions for
Models:
• ALTAC-136
• ALTAC-200
Manual Contents
1.
Installer Read Before Proceeding . . . . . . . . . . .3
2.
3.
Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . .6
4.
How It Works . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
5.
Locating Boiler . . . . . . . . . . . . . . . . . . . . . . . . .10
6.
Preparing Boiler . . . . . . . . . . . . . . . . . . . . . . . .14
7.
General Venting . . . . . . . . . . . . . . . . . . . . . . . . .17
8.
Sidewall Direct Venting . . . . . . . . . . . . . . . . . . .24
9. Vertical Direct Venting . . . . . . . . . . . . . . . . . . .30
10. Heating System Piping . . . . . . . . . . . . . . . . . . .36
11. Domestic Water Piping . . . . . . . . . . . . . . . . . . .39
12. Gas Piping . . . . . . . . . . . . . . . . . . . . . . . . . . . . .42
13. Field Wiring . . . . . . . . . . . . . . . . . . . . . . . . . . . .43
14. Condensate Disposal . . . . . . . . . . . . . . . . . . . .46
15. Start-up and Checkout . . . . . . . . . . . . . . . . . .47
16. Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .53
17. Before Leaving Jobsite . . . . . . . . . . . . . . . . . .65
18. Service and Maintenance . . . . . . . . . . . . . . . . .66
19. Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . .71
20. Internal Wiring Diagrams . . . . . . . . . . . . . . . . .86
21. Service Parts . . . . . . . . . . . . . . . . . . . . . . . . . . .89
Appendix
D. Code Required Text . . . . . . . . . . . . . . . . . . . . . .99
TO THE INSTALLER:
Affix these instructions adjacent to boiler.
Provide model number and serial number when
seeking information and support.
TO THE HOMEOWNER:
Retain these instructions for future reference.
Contact heating installer or technician for all issues
and support.
Version en Español disponible en el web del fabricante.
This boiler must only be installed, serviced, or repaired by a qualified installer, service agency or gas supplier.
Improper installation, adjustment, alteration, service or maintenance can cause severe personal injury, death,
or substantial property damage. For assistance or additional information, consult a qualified installer, service
agency, or the gas supplier. Read these instruction carefully before installing.
110327-04 - 1/22
• Combi Boiler/Water Heater
• Condensing
• Direct Vent
• Gas Fired
Page
www.usboiler.net
!
