Ducting Options
spaces between walls, crawl spaces, ceilings, attics, or garages.
Use single wall rigid metal ductwork only.
Fasten all connections with sheet metal screws and tape all joints w/ certified Silver Tape or Duct
Tape.
side wall cap
w/gravity damper
3-1/4"x10" rear
ducting w/side
wall gravity damper
Typhoon, Hurricane, & Cyclone Use, Care, and Installation Guide
WARNING
Fire Hazard: NEVER exhaust air or terminate ductwork into
All exhaust must be ducted to the outside, unless using the
recirculating option.
cabinet
cabinet
Installation Instructions
soffit or crawl space
roof pitch w/
flashing & cap
side wall cap
w/gravity damper
