POWERPATH PS-8-LP Installation Instructions Manual page 22

□ ■ ■ □ ■
□ ■ ■ ■ □
□ ■ ■ ■ ■
■ □ □ □ □
■ □ □ □ ■
■ □ □ ■ □
■ □ □ ■ ■
■ □ ■ □ □
■ □ ■ □ ■
■ □ ■ ■ □
■ □ ■ ■ ■
■ ■ □ □ □
■ ■ □ □ ■
■ ■ □ ■ □
■ ■ □ ■ ■
■ ■ ■ □ □
■ ■ ■ □ ■
■ ■ ■ ■ □
■ ■ ■ ■ ■
Note 1: When LED indicator D3 is lighted, it indicates a general ground fault condition. Momentarily depress switch
SW5 (Ground Fault Detect Enable Pushbutton). The Coded Trouble LEDs will indicate the circuit location of the
ground fault.
FUSE REPLACEMENT PROCEDURE (All Models):
1. Turn off the AC Mains Power.
2. Open the enclosure and turn off DC battery power.
3. Remove F1.
4. Replace F1 with a 10A 250V fuse.
5. Remove F2.
6. Replace F2 with a 10A 250V fuse.
7. Turn on DC battery power.
8. Close the enclosure.
9. Turn on AC Mains.
P84905-002 A
□
AUX Output Current Limit
□
SYNC BUS Short
□
SYNC BUS Open
■
SYNC BUS Current Limit
Ground Fault
■
Dry Contact 1
(Note 1)
Ground Fault
■
Dry Contact 2
(Note 1)
Ground Fault
■
NAC Output 1+
(Note 1)
Ground Fault
■
NAC Output 1–
(Note 1)
Ground Fault
■
NAC Output 2+
(Note 1)
Ground Fault
■
NAC Output 2–
(Note 1)
Ground Fault
■
NAC Output 3+
(Note 1)
Ground Fault
■
NAC Output 3–
(Note 1)
Ground Fault
■
NAC Output 4+
(Note 1)
Ground Fault
■
NAC Output 4–
(Note 1)
Ground Fault
■
AUX Output+
(Note 1)
Ground Fault
■
AUX Output–
(Note 1)
Ground Fault
■
SYNC BUS+
(Note 1)
Ground Fault
■
SYNC BUS-
(Note 1)
Ground Fault
■
Battery Wires
(Note 1)
firealarmresources.com
Reduce the number of NAC Appliances on Output1
Check for a wiring short. Check for improperly wired NAC
circuit. (If an appliance is wired + to – and – to + a short trouble
will be indicated.
Check SYNC BUS terminals for good connections. Check NAC
circuit wiring for continuity. Check NAC circuit for 10K Ohm
EOLR.
Excessive current on the SYNC BUS. Reduce the number of
Power Supplies connected to the circuit.
Check for circuit wire to enclosure or conduit.
Same as above
Same as above
Same as above
Same as above
Same as above
Same as above
Same as above
Same as above
Same as above
Same as above
Same as above
Same as above
Same as above
Same as above
Sheet 22 of 37
