4 BURNER GAS BBQ GRILL
Model No. GBC1849W-U (ASDA Spec Code: 16B.02.18.027 )

Table of Contents

. . . . . . . . . . . . . . . . . . . .
Specifications. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Assembly Instructions. . . . . . . . . . . . . . . . . . . . . . . . 8
Installing Gas Cylinder . . . . . . . . . . . . . . . . . . . . . . 12
Gas Regulator. . . . . . . . . . . . . . . . . . . . . . . . . 12 & 13
Operating Instructions. . . . . . . . . . . . . . . . . . . . . . . 14
Cleaning and Care . . . . . . . . . . . . . . . . . . . . . . . . . 17
Refund Informnation . . . . . . . . . . . . . . . . . . . . . . . . 18
Customer Services Information . . . . . . . . . . . . . . . . 18
Contact Us . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Thus instruction booklet contains important safety
information. Please read and keep for future reference.
If you sell or give this product to someone else, make sure
this manual accompanies this product.
If you need help, have missing or damaged parts, or have
any questions, please call us toll free at 0800-9520101 or
e-mail us at asdaservice@revoace.com.
This grill is supplied with a 27 mm clip on
propane regulator suitable for use with
propane patio gas cylinders.
Manufactured in China for: RevoAce Inc. Limited
Hong Kong, China
FOR YOUR SAFETY:
1. Do NOT store or use gasoline or other
flammable liquids or vapors in the vicinity
of this or any other appliance.
2. When cooking with oil/grease, do NOT allow
the oil/grease to exceed 350ºF (176.5ºC).
Do NOT store or use extra cooking oil in the
vicinity of this or any other appliance.
If you smell gas -
1. Shut off gas to appliance.
2. Extinguish any open flame.
3. Open lid.
4. If odor continues, keep away from the appliance
and immediately call your gas supplier or your fire
Page 2
department.
FOR YOUR SAFETY:
Do not use spirit, petrol or comparable fluids for
lighting or re-lighting!
Read the following instructions carefully and be
sure your barbecue is properly installed, assembled
and cared for. Failure to follow these instructions
may result in serious bodily injury and/or property
damage.
FOR YOUR SAFETY:
For Outdoor Use Only (Outside any enclosure).
Never operate this appliance unattended.
Keep children and pets away.
This barbecue will become very hot, do not move it
during operation.
0359-17
GBC1849W-U-E-OM-F100
CAUTION
.
.
ATTENTION
.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GBC1849W-U and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Backyard GBC1849W-U

Summary of Contents for Backyard GBC1849W-U

  • Page 1: Table Of Contents

    4 BURNER GAS BBQ GRILL Model No. GBC1849W-U (ASDA Spec Code: 16B.02.18.027 ) FOR YOUR SAFETY: 1. Do NOT store or use gasoline or other flammable liquids or vapors in the vicinity of this or any other appliance. 2. When cooking with oil/grease, do NOT allow the oil/grease to exceed 350ºF (176.5ºC).

  • Page 2: Important Safeguards

    Important Safeguards Warning is dangerous. W Use outdoor only. W The gas cylinder, regulator and hose must be W Read the instructions before using the appliance. approved. W WARNING: Accessible parts may be very hot. Keep W Regulator and hose: young children away.
  • Page 3 Important Safeguards Warning W to ensure that it is not subjected to twisting. ability to properly assemble or safely operate the appliance. W Never use a gas cylinder with a damaged body, valve, collar or footing. f. Strong odors, colds, sinus congestion, etc. may prevent the detection of propane.
  • Page 4 Important Safeguards Warning W Do NOT operate this appliance without reading for leaks, burner obstructions and inspect for any “Operating Instructions” in this manual. abrasion, wear or cuts to the hose. W Do NOT touch metal parts of grill until they have W Failure to open lid while igniting the grill’s burners, completely cooled to avoid burns, unless you are or not waiting 5 minutes to allow the gas to clear if...

  • Page 5: Specifications

    Specifications Approvals 0359-17 Pin: 0359CR01461 Barbecue Appliance Category Weight 21 kg / 46.3 lbs Dimensions (L x W x H) 138.6cm x 61cm x 106.4cm Grilling surface (L x W) 68.0cm x 33.2cm Load weight Side shelf Max. 6 kg. Side burner table Max.

  • Page 6: Expanded View & Hardware

    Expanded View...
  • Page 7 Parts List Lid Handle G1849-010 Side Burner Electrode* B0406-000 Handle Shied G1849-020 Right Side Shelf G1849-080 Brand Plate* B0109-LBA Shelf Support B (2) G1849-090 Lid* G1849-070 Shelf Surport A (2) G1849-100 Top Hinge(2)* G1849-050 Upper Cart Frame (2) G1849-110 Bottom Hinge(2)* G1716-030 Rear Cart Frame G1849-120...

  • Page 8: Assembly Instructions

    Assembly Instructions DO NOT RETURN TO PLACE OF Attach Upper Cart Frames, Leg PURCHASE Connectors and Legs Assembly Tips: 1. Select an area where you will assemble this product. To protect components, choose a smooth surface that’s free of cracks or openings. 2.
  • Page 9 Attach Axis and Wheels Attach Lid and Grill Body Assembly Attach Axle, Wheels and Control Knobs Attach Shelf Support A&B...
  • Page 10 Attach Left Side Shelf Attach Right Side Shelf Note: Leave 5 mm of bolt threads exposed. Note: Leave 5 mm of bolt threads exposed. Attach Side Burner, Side Burner Grid Attach Regulator/Hose Assembly and Side Control Knob...
  • Page 11 Insert Heat Plate and Cooking Grid Insert Warming Rack...

  • Page 12: Installing Gas Cylinder

    Installing LP Gas Cylinder To operate you will need a precision-filled gas cylinder between 11kg and 15kg. Your barbecue is supplied with a regulator and hose suitable for use with a propane patio gas cylinder with a 27mm connection. CAUTION Place Gas Cylinder W Gas cylinder must be properly disconnected and removed prior to moving this grill.
  • Page 13 Gas Regulator (continued) Fitting the Hose Figure E Before connecting the “Snap on compact” to a cylinder valve: Connect regulation rubber hose to the barbed stem on the regulator. Tip: Lubricate the barbed stem with water to help connect the regulator hose to the regulator. Use a hose clamp to secure the regulation rubber hose to the regulator.

  • Page 14: Operating Instructions

    Operating Instructions Checking for Leaks Figure 1: Main Burners Burner/venturi tube Burner Connections Make sure the regulator hose and valve connections are securely fastened to the burner and the tank. Visually check the connection between the burner/venturi tube and orifice. Make sure the burner/venturi tube fits over the orifice.
  • Page 15 Operating Instructions (continued) • If ignition does not occur in 5 seconds, turn burner control knob (OFF), wait 5 minutes, and Figure 6 repeat lighting procedure. If igniter does not light burner, use a lit match secured with the lighting rod (included with grill) to Flame Slight light burners.
  • Page 16 Operating Instructions (continued) Lighting Open lid. Check for obstructions of airflow to the burners. Spiders, insects and webs can clog the burner/venturi tube A clogged burner tube can lead to a fire. • Control knob must be in the (OFF) position (Figure 3). Connect gas cylinder per “Installing Gas cylinder”...

  • Page 17: Cleaning And Care

    Cleaning and Care W CAUTION: All cleaning and maintenance should be done when grill is cool and with the fuel supply disconnected. W CAUTION: Do NOT clean any grill part in a self-cleaning oven. The extreme heat will damage the finish. W CAUTION: Do NOT enlarge valve orifices or burner ports when cleaning the valves or burners.

  • Page 18: Refund Informnation

    When calling or writing please quote the product spec code or model number. Produtc name: UniFlame 4 Burner Gas BBQ Grill Spec Code: 16B.02.18.028 / Model number: GBC1849W-U Contact Us Customer Services: 0800 9520101 / asdaservice@revoace.com Visit our website: www.asda.com...

  • Page 19: Troubleshooting

    Troubleshooting Problem Possible Cause Prevention/Cure Make sure regulator is securely attached to the Gas cylinder per “Installing Gas Gas cylinder valve is closed Cylinder,” then turn gas cylinder valve to “OPEN” Gas cylinder is low or empty Exchange, refill or replace gas cylinder Turn Gas cylinder valve to “CLOSED”...
