Outdoor LP Gas Barbecue Grill
Model No. GBC1748WRSE-C /
GBC1848WBSE-C / GBC1848W-C
Table of Contents
. . . . . . . . . . . . . . . . . . . .
Assembly Instructions . . . . . . . . . . . . . . . . . . . . . . . . 8
Installing LP Gas Tank . . . . . . . . . . . . . . . . . . . . . . . 13
Operating Instructions . . . . . . . . . . . . . . . . . . . . . . . 13
Cleaning and Care . . . . . . . . . . . . . . . . . . . . . . . . . 15
Limited Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
.
The use and installation must conform with local
codes or, in the absence of local codes, with either the
National Fuel Gas Code, ANSI Z223.1/NFPA 54, Natural
Gas and Propane Installation Code, CSA B149.1, or
Propane Storage and Handling Code, B149.2, or the
Standard for Recreational Vehicles, ANSI A 119.2/NFPA
1192, and CSA Z240 RV Series, Recreational Vehicle
Code, as applicable .
THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT
SAFETY INFORMATION . PLEASE READ AND KEEP FOR
FUTURE REFERENCE .
If you are assembling this unit for someone else, give
this manual to him or her to read and save for future
reference .
OWNER'S MANUAL
FOR YOUR SAFETY:
1. Do NOT store or use gasoline or
other flammable liquids or vapors in
the vicinity of this or any other
appliance.
2. An LP cylinder not connected for
use shall not be stored in the vicinity
of this or any other appliance.
DANGER
Never operate this appliance
unattended.
FOR YOUR SAFETY:
For Outdoor Use Only!
Page 2
If you smell gas -
1. Shut off gas to appliance.
2. Extinguish any open flame.
3. Open lid.
4. If odor continues, keep away from
the appliance, immediately call your
gas supplier or your fire department.
Failure to follow these instructions
could result in fire or explosion
which could cause property damage,
personal injury or death.
Natural gas conversion kit (model no.
VFK1702W-C) available at Walmart or
www.Walmart.ca
Manufactured in China for: RevoAce Inc . Limited
Hong Kong, China
1 .800 .694 .0013 • service@revoace .com
8:00 am to 5:00 pm central time, Monday to Friday .
GBC1748W-C-OM-EF-F104
WARNING
WARNING
DANGER
(outside any enclosure)
.
.
Advertisement
Related Manuals for Backyard GBC1748WRSE-C
Summary of Contents for Backyard GBC1748WRSE-C
-
Page 1: Table Of Contents
OWNER’S MANUAL Outdoor LP Gas Barbecue Grill Model No. GBC1748WRSE-C / WARNING GBC1848WBSE-C / GBC1848W-C FOR YOUR SAFETY: 1. Do NOT store or use gasoline or other flammable liquids or vapors in the vicinity of this or any other appliance. -
Page 2: Important Safeguards
FOR YOUR SAFETY W WARNINGS: 1. Improper installation, adjustment, alteration, service or maintenance can cause injury or property damage. 2. Read the installation, operation, and maintenance instructions thoroughly before installing or servicing this equipment. 3. Failure to follow these instructions could result in fire or explosion, which could cause property damage, personal injury, or death. - Page 3 IMPORTANT SAFEGUARDS W The LP gas cylinder must be constructed and marked in accordance with the Specifications for LP-gas Cylinders of the U.S. Department of Transportation (D.O.T.) or the National Standard of Canada, CAN/ CSA-B339, Cylinders, Spheres and Tubes for the Transportation of Dangerous Goods; and Commission. W LP gas cylinder must be arranged for vapor withdrawal.
- Page 4 IMPORTANT SAFEGUARDS LP: If you are unable to stop a leak, disconnect the LP gas supply. Call a gas appliance serviceman or your local LP gas supplier. NG: If you are unable to stop a leak, turn off the main valve on the NG supply line. Call a gas appliance serviceman or your local NG supplier.
- Page 5 IMPORTANT SAFEGUARDS W Storage of grill indoors is permissible only if the cylinder is disconnected, removed from the grill and properly stored outdoors. W Always open grill lid carefully and slowly as heat and steam trapped within grill can cause severe burns. W Do NOT attempt to disconnect the gas regulator from the cylinder or any gas fitting while the grill is in use.
-
Page 6: Expanded View & Hardware
Expanded View... - Page 7 Parts List Lid Handle G1748-010 Left Side Shelf G1748-110 Lid Handle Support (2) G1748-020 Grease Cup B0219-H08 Temperature Gauge B0104-J70 Grease Tray G1646-140 Warming Rack G1646-020 Left Cart Frame G1646-130 Cooking Grid (3) G1646-030 Rear Cart Frame Support G1646-150 Heat Plate (4) G1646-04R LP Gas Tank Retainer Wire G1349-190...
-
Page 8: Assembly Instructions
Assembly Instructions Assemble Left Cart Frame DO NOT RETURN TO PLACE OF PURCHASE. Please have your owner’s manual and model number available for reference . Note: The model number is printed on a label which can be found on the inside door, back or side of the cart assembly . Assembly Tips: 1 . - Page 9 Attach Rear Cart Frame Support Attach Cart Frame Support Wires Attach Feet and Tighten all Screws from Steps 2-5 Attach LP Gas Tank Retainer Wire, Axle and Wheels...
- Page 10 Attach Grill Body Assembly and Regulator/Hose Attach Temperature Gauge Support Attach Left Side Shelf Attach Right Side Shelf Note: Leave 5 mm of bolt threads exposed . Note: Leave 5 mm of bolt threads exposed .
- Page 11 Secure Side Shelves Attach Control Knobs Attach Lid Handle Insert Heat Plates and Cooking Grids...
- Page 12 Insert Warming Rack Insert Grease Tray and Grease Cup Natural gas conversion kit (model no. VFK1702W-C) available at Walmart or www.Walmart.ca.
-
Page 13: Installing Lp Gas Tank
Installing LP Gas Tank To operate, you will need one precision-filled standard grill LP gas tank with external valve threads . CAUTION 20 lb W LP gas tank must be properly disconnected and 9 Kg removed prior to moving this grill. 12.2 in. -
Page 14: Operating Instructions
Operating Instructions Figure 1：Main Burners Checking for Leaks Burner/ Burner Connections Venturi Tube Make sure the regulator hose and valve connections are securely fastened to the burner and the tank . Visually check the connection between the burner/venturi tube and orifice . Make sure the burner/venturi tube fits over the orifice . - Page 15 Operating Instructions (Continued) Push and turn any control knob to (HIGH) . The burner should light . If it does not, repeat up to Figure 4 three times . If ignition does not occur in 5 seconds, turn burner control knob “ OFF,” wait 5 minutes, and repeat lighting procedure .
-
Page 16: Cleaning And Care
Cleaning and Care W CAUTION: 1. All cleaning and maintenance should be done when grill is cool and with the fuel supply disconnected. 2. Do NOT clean any grill part in a self-cleaning oven. The extreme heat will damage the finish. 3. -
Page 17: Limited Warranty
Limited Warranty RevoAce Inc . Limited (“RA”) warrants to the original retail purchaser of this product, and to no other person, that if this product is assembled, maintained, and operated in accordance with the printed instructions accompanying it, then for a period of one (1) year for all remaining parts from the date of purchase, all parts in such product shall be free from defects in material and workmanship . -
Page 18: Troubleshooting
Troubleshooting Problem Possible Cause Prevention/Cure LP: Make sure regulator is securely attached to the LP gas tank per LP gas tank valve is closed “Installing LP Gas Tank,” then turn LP gas tank valve to “OPEN” NG main valve is closed NG: Make sure regulator and NG main line are securely attached per “Installing Natural Gas Line,”... - Page 19 Troubleshooting (Continued) Problem Possible Cause Prevention/Cure New burner may have residual manufacturing Burn grill for 15 minutes on (HIGH) with the lid closed oils Flame is yellow Spider webs or insect nest in venturi Clean venturi or orange Food residue, grease, etc . on burners Clean burner Poor alignment of valve to burner/venturi tube Ensure burner/venturi tube is properly engaged with valve...
