Item #1006 325 683
Model # FHWA80088A
USE AND CARE GUIDE
STONEHAVEN LP FIRE PIT
Questions, problems, missing parts? Before returning to the store,
call Home Decorators Collection Customer Service.
8 a.m. - 7 p.m., EST, Monday - Friday, 9 a.m. - 6 p.m., EST, Saturday
1-800-986-3460
HOMEDEPOT.COM/HOMEDECORATORS
THANK YOU
quality products designed to enhance your home. Visit us online to see our full line of products available for your home improvement needs.
Thank you for choosing Home Decorators Collection!

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the STONEHAVEN FHWA80088A and is the answer not in the manual?

Questions and answers

Related Manuals for Home Decorators Collection STONEHAVEN FHWA80088A

Summary of Contents for Home Decorators Collection STONEHAVEN FHWA80088A

  • Page 1 8 a.m. - 7 p.m., EST, Monday - Friday, 9 a.m. - 6 p.m., EST, Saturday 1-800-986-3460 HOMEDEPOT.COM/HOMEDECORATORS THANK YOU quality products designed to enhance your home. Visit us online to see our full line of products available for your home improvement needs. Thank you for choosing Home Decorators Collection!

  • Page 2: Table Of Contents

    Table of Contents WARNING Table of Contents FOR YOUR SAFETY: Table of Contents......2 Packaging Contents.
  • Page 3 Important Safety Information WARNING: Fire table is for outdoor use only. WARNING: Failure to follow the dangers, warning and cautions in this manual may result in serious bodily injury or death, or in a fire or an explosion causing damage to property. IMPORTANT NOTICE IF YOU SMELL GAS Extinguish any open flame.
  • Page 4 Important Safety Information (continued) The use of alcohol, prescription or non-prescription drugs may impair an individual’s ability to properly assemble or safely operate this outdoor fire table. DO NOT use in an explosive atmosphere. Keep gas fire table area clear and free from combustible materials, such as gasoline. This outdoor fire table is not to be installed or used in or on recreational vehicles and/or boats.

  • Page 5: Propane (Lp) Dangers And Warnings

    Important Safety Information (continued) ATTENTION: Any alteration of the outdoor fire table that is not specifically directed in the operations manual will void manufacturer warranty. PROPANE (LP) DANGERS AND WARNINGS LP GAS LP gas is flammable and hazardous if handled improperly. Familiarize yourself with its hazards before using any LP gas product. PROPANE HAZARDS Flammable, explosive under pressure, heavier than air and settles in pools in low areas.

  • Page 6: Hose And Regulator Assembly And Replacement

    Important Safety Information (continued) HOSE AND REGULATOR ASSEMBLY AND REPLACEMENT This fire table comes equipped with a standard LP gas hose and regulator including the appliance side connection for a CGA No. 791 Cylinder Connection Device. The LP gas hose and regulator supplied with this fire table must be used. Only a hose and regulator specified by manufacturer can be used for replacement.

  • Page 7: Warranty

    Warranty 1 YEAR FRAME LIMITED WARRANTY WHAT IS COVERED We warrant the frames to be free of manufacturing defects to the original purchaser for one year. WHAT IS NOT COVERED It remains the customer’s responsibility for freight and packaging charges to and from our service center. This warranty does not cover s warranty.

  • Page 8: Packaging Contents

    Pre-Assembly (continued) PACKAGE CONTENTS Part Description Quantity WARNING: Failure to position the parts in Burner Lid accordance with these diagrams or failure to use only parts speci cally approved with this appliance may Table Top result in property damage or personal injury. Left Side Panel Door Right Side Panel...

  • Page 9: Assembly

    Assembly CONNECTING THE SIDE PANELS TO THE TABLE TOP Place the table top (B) upside down on a soft surface. Connect the left side panel and right side panel (C&E) to the table top (B) using M6X15 combination bolts (AA). Do not tighten the bolts at this step.
  • Page 10 Assembly (continued) CONNECTING THE MIDDLE SIDE PANEL Connect the middle side panel (F) to the left side panel and right side panel (C&E) using M6x40 combination bolts (CC). Do not tighten the bolts at this step. NOTE: Loosely tighten all the bolts using the hex wrench (GG).
  • Page 11 Assembly (continued) CONNECTING THE LIMIT TUBES Connect the limit tubes (H) to the left side panel and right side panel (C&E) using M6X15 combination bolts (AA). Do not tighten the bolts at this step. NOTE: Loosely tighten all the bolts using the hex wrench (GG). HOMEDEPOT.COM/HOMEDECORATORS Please contact 1-800-986-3460...
  • Page 12 Assembly (continued) CONNECTING THE TANK SUPPORT Connect the tank support (G) to the left side panel and right side panel (C&E) using M6x30 combination bolts (BB). Do not tighten the bolts at this step. NOTE: Loosely tighten all the bolts using the hex wrench (GG).
  • Page 13 Assembly (continued) CONNECTING THE DOOR Connect the door (D) to the left side panel (C) using M6x12 countersunk bolt (EE) and plastic washers (FF). Attach the knob (Q) to the door (D) using M4x30 bolt (DD) as show below. NOTE: Tighten all the bolts using hex wrench (GG) at this step. HOMEDEPOT.COM/HOMEDECORATORS Please contact 1-800-986-3460...
  • Page 14 Assembly (continued) CHECKING THE TABLE AND PLACE THE GLASS BEADS Once all of the bolts are in place, fully tighten all the bolts using the hex wrench (GG). Place the glass beads (I) into the square burner bowl (J). CAUTION: To ensure proper function, the screen on the pilot housing should be free of glass beads. WARNING: Surfaces on the fire table can remain extremely hot for a period after use.
  • Page 15 Assembly (continued) PLACING THE BURNER LID Place the burner lid (A) over the burner bowl (B). Make sure to remove the burner lid before lighting. Do not place the lid back onto burner bowl until it has cooled down. WARNING: Surfaces on the fire table can remain extremely hot for a period after use.

  • Page 16: Operating

    Operation INSTALLING LP GAS TANK Loosen LP gas tank retainer bolt by turning counterclockwise. Place a precision- lled LP gas tank upright into hole in outdoor replace base so the tank valve is facing the gas line connection. Secure tank by turning LP gas tank retainer bolt clockwise until tight. CAUTION: LP gas tank must be properly disconnected and removed prior to moving this outdoor replace.
  • Page 17 Operation (continued) CONNECTING LP GAS TANK Before connecting, be sure there is no debris caught in the head of the LP gas tank, head of the regulator valve or in the head of the burner ports. Connect the regulator/hose assembly to the tank by turning the knob clockwise until it stops. HOMEDEPOT.COM/HOMEDECORATORS Please contact 1-800-986-3460...
  • Page 18 Operation (continued) DISCONNECTING LP GAS TANK Before disconnecting make sure the LP gas tank valve is “CLOSED”. Disconnect regulator/hose assembly from LP gas by turning the knob counterclockwise until it is loose. Place the protective cap cover on the LP gas tank and store it outdoors in a well-ventilated area out of direct sunlight. NOTE: LP gas tank must be properly disconnected and removed prior to moving this re table.
  • Page 19 Operation (continued) CHECKING FOR LEAKS AND BURNER CONNECTIONS the “Important Safety Information” section on page 3 to 6. Failure to follow those instructions can lead to serious injury or property damage, or cause death. Make sure the regulator/hose and valve connections are securely fastened to the burner and the tank. Please refer to Figures 1 and 2 for proper installation.
  • Page 20 Operation (continued) TANK/GAS LINE CONNECTION LEAK TEST Make 2-3 oz. of leak detection solution by mixing one part liquid dishwashing soap with three parts water. Make sure the control knob is in the “OFF” position. Connect LP gas tank per “CONNECTING LP GAS TANK” SECTION. Turn LP gas tank valve to “OPEN”.
  • Page 21 Operation (continued) INSERTING THE BATERRY Insert the AAA battery (P) into the manual electric igniter (N) and twist the button cover on to igniter housing. Do not over tighten. CAUTION: Do not put batteries into the re or trash. Please treat batteries as hazardous waste and recycle properly.
  • Page 22 Operation (continued) CLOSING THE DOOR...
  • Page 23 Operation (continued) Failure to follow these instructions CAUTION: could cause a fire or an explosion which can cause death, serious bodily injury or damage to property. WARNING: CAUTION: Keep outdoor gas appliance area clear and free from combustible materials, gasoline and other ammable vapors and liquid. CAUTION: CAUTION: LIGHTING...
  • Page 24 Operation (continued) LIGHTING (CONTINUED) 11. If igniter does not light burner: a. Wearing heat-resistant gloves, position a long, lit match or long, lit butane lighter near the pilot housing. b. Push and turn control knob to “ON”. c. Remove match/lighter once burner is lit. 12.

  • Page 25: Care And Maintenance

    Care And Maintenance Cleaning Surfaces 1. Wipe surfaces clean with mild dishwashing detergent or baking soda mixed with water. 2. For stubborn stains, use a citrus-based cleaner and a nylon scrubbing brush. 3. Rinse clean with water. 4. Allow to air dry. Before Storing 1.

  • Page 26: Troubleshooting

    Troubleshooting Make sure that the regulator is securely attached to the The LP gas tank valve is closed. LP gas tank per the "Installing the Gas Tank" section. Then turn the LP gas tank valve to "OPEN." The LP gas tank is low or empty. Exchange, refill or replace LP gas tank.
  • Page 27 Troubleshooting (continued) Exchange, refill or replace LP gas tank. The tank is out of gas. 1. Turn control knob to “OFF”. 3. If flames are still too low, reset the overfilling prevention device: a. Turn control knob to “OFF”. There is a sudden b.
