- Page 1 USER MANUAL PD32M www.aoc.com ©2022 AOC. All rights reserved...
-
Page 2: Table Of Contents
Safety ....................................1 National Conventions ..............................1 Power ..................................2 Installation ................................. 3 Cleaning ..................................4 Other ..................................5 Setup ....................................6 Contents in Box ................................. 6 Setup Stand & Base ..............................7 Adjusting the monitor ..............................8 Connecting the Monitor ............................. 9 Wall Mounting................................ -
Page 3: Safety
Safety National Conventions The following subsections describe notational conventions used in this document. Notes, Cautions, and Warnings Throughout this guide, blocks of text may be accompanied by an icon and printed in bold type or in italic type. These blocks are notes, cautions, and warnings, and they are used as follows: NOTE: A NOTE indicates important information that helps you make better use of your computer system. -
Page 4: Power
Power The monitor should be operated only from the type of power source indicated on the label. If you are not sure of the type of power supplied to your home, consult your dealer or local power company. The monitor is equipped with a three-pronged grounded plug, a plug with a third (grounding) pin. This plug will fit only into a grounded power outlet as a safety feature. -
Page 5: Installation
Installation Do not place the monitor on an unstable cart, stand, tripod, bracket, or table. If the monitor falls, it can injure a person and cause serious damage to this product. Use only a cart, stand, tripod, bracket, or table recommended by the manufacturer or sold with this product. -
Page 6: Cleaning
Cleaning Clean the cabinet regularly with cloth. You can use soft-detergent to wipe out the stain, instead of strong-detergent which will cauterize the product cabinet. When cleaning, make sure no detergent is leaked into the product. The cleaning cloth should not be too rough as it will scratch the screen surface. -
Page 7: Other
Other If the product is emitting a strange smell, sound or smoke, disconnect the power plug IMMEDIATELY and contact a Service Center. Make sure that the ventilating openings are not blocked by a table or curtain. Do not engage the LCD monitor in severe vibration or high impact conditions during operation. Do not knock or drop the monitor during operation or transportation. -
Page 8: Setup
Power Cable DP Cable HDMI Cable Not all signal cables will be provided for all countries and regions. Please check with the local dealer or AOC branch office for confirmation. For use only with the attached power adapter Manufacturers: LITE-ON Technology Corp. -
Page 9: Setup Stand & Base
Setup Stand & Base Please setup or remove the base following the steps as below. Setup: Remove: Note: When the Monitor is rotated vertically, the quick release button is no effect, the stand/ base cannot be removed. -
Page 10: Adjusting The Monitor
Adjusting the monitor For optimal viewing it is recommended to look at the full face of the monitor, then adjust the monitor’s angle to your own preference. Hold the stand so you will not topple the monitor when you change the monitor’s angle. You are able to adjust the monitor as below: 150mm NOTE:... -
Page 11: Connecting The Monitor
Connecting the Monitor Cable Connections In Back of Monitor and Computer: 1. Microphone in 2. Earphone (Combined with Microphone) 3. USB C 4. USB UP 5. USB3.2 Gen1+fast charging 6. USB3.2 Gen1 7. DC IN 8. DP 9. HDMI1 10. HDMI2 11. -
Page 12: Wall Mounting
4. Reconnect the cables. Refer to the user’s manual that came with the optional wall mounting arm for instructions on attaching it to the wall. Noted: VESA mounting screw holes are not available for all models, please check with the dealer or official department of AOC. 0° 90°... -
Page 13: Adaptive-Sync Function
Adaptive-Sync function 1. Adaptive-Sync function is working with DP/HDMI/USB C. 2. Compatible Graphics Card: Recommend list is as the below, also could be checked by visiting www.AMD.com Graphics Cards • Radeon RX Vega series • Radeon RX 500 series • Radeon RX 400 series •... -
Page 14: Hdr
It is compatible with input signals in HDR10 format. The display may automatically activate the HDR function if the player and content are compatible. Please contact the device manufacturer and the content provider for information on the compatibility of your device and content. Please select “OFF”... -
Page 15: Adjusting
Adjusting Hotkeys Source/Up Dial Point/Down Game Mode/Left Light FX /Right Power/ Menu/Enter Power/Menu/Enter Press the Power button to turn on the monitor. When there is no OSD, Press to display the OSD or confirm the selection. Press about 2 seconds to turn off the monitor. Dial Point/Down When there is no OSD, press Dial Point button to show / hide Dial Point. -
Page 16: Quick Switch
Quick Switch When the OSD is not displayed, press to open the game mode to adjust the menu. When the OSD is not displayed, press to open the gaming ambient light to adjust the menu. Menu/ : When the OSD is not displayed, press this button to display the OSD menu or confirm the option. When the display is in standby mode, press and hold this button to turn on/off the display power. -
Page 17: Osd Setting
OSD Setting Basic and simple instruction on the control keys. 1). Press the MENU-button to activate the OSD window. 2). OSD Lock/Unlock Function: To lock or unlock the OSD, press and hold the Down–button for 10s while OSD function is not active. Notes: 1). -
Page 18: Game Setting
Game Setting Game Setting Game Mode Shadow Control Game Color Adaptive-Sync Overdrive Low Input lag Frame Counter HDMI1 120Hz HDMI2 120Hz No optimization by Smart image game For playing FPS (first Person Shooters) games. Improves dark theme black level details. For playing RTS (Real Time Strategy). -
Page 19: Luminance
Luminance Luminance Contrast Brightness Eco Mode Standard Gamma Gamma1 Contrast 0-100 Contrast from Digital-register. Brightness 0-100 Backlight Adjustment Standard Standard Mode Text Text Mode Internet Internet Mode Eco Mode Game Game Mode Movie Movie Mode Sports Sports Mode Reading Reading Mode Gamma1 Adjust to Gamma 1 Gamma... -
Page 20: Image Setup
Image Setup Image Setup HDR Mode Luminous Max High Main Source HDMI2 Sub Source USB C Audio Swap Off / DisplayHDR / HDR Picture / Disable or Enable HDR HDR Movie / HDR Game Off / HDR Picture / HDR Movie / HDR Mode Disable or Enable HDR Mode HDR Game... - Page 21 4）When PBP is On, the Main source / Sub-source input source compatibility is as follow: Main source HDMI1 HDMI2 USB-C HDMI1 HDMI2 Sub source USB-C Note: When PBP is On, the DP / HDMI / USB C signal source supports maximum resolution 3840x2160@60Hz.
-
Page 22: Color Setup
Color Setup Color Setup LowBlue Mode Color Temp. Warm DCB Mode DCB Demo Green Blue Off / Multimedia / LowBlue Mode Internet / Office / Decrease blue light wave by controlling color temperature. Reading Warm Recall Warm Color Temperature from EEPROM. Normal Recall Normal Color Temperature from EEPROM. -
Page 23: Audio
Audio Audio Volume DTS Sound Game TruVolume HD Boot Sound 200Hz 500Hz 2.5KHz 7KHz 10KHz Volume 0-100 Adjust volume setting Game / Rock / Classical Select DTS Sound mode. DTS Sound Note: It may take up to 2 seconds to switch modes. / Live / Theater / Off TruVolume HD On / Off... -
Page 24: Light Fx
Light FX Light FX Light FX Medium Light FX Mode Breathing Pattern Rainbow Foreground R Foreground G Foreground B Foreground R Foreground G Foreground B Light FX Off / Low / Medium / Strong Select the intensity of Light FX. Audio/Static/Simple Shift/Gradient Shift/Simple Filling/1 Way Filling/2 Light FX Mode... -
Page 25: Extra
Extra Extra Input Select Auto Logo Projector Medium Green Blue O Timer Image Ratio Wide DDC/CI Reset Resolution: 3840 H x 2160 V SDR H.Frequency: 89 KHz V.Frequency: 60 Hz Input Select AUTO/HDMI1/HDMI2/DP/USB C Select Input Signal Source Logo Projector Off/Low/Medium/Strong It’s projection logo function. -
Page 26: Osd Setup
OSD Setup OSD Setup Language English Timeout H. Position Transparence Break Reminder USB Selection Auto Language Select the OSD language Timeout 5-120 Adjust the OSD Timeout H. Position 0-100 Adjust the horizontal position of OSD Transparence 0-100 Adjust the transparence of OSD Break Reminder On /Off Break reminder if the user continuously work for more than 1hrs... -
Page 27: Led Indicator
LED Indicator Status LED Color Full Power Mode White Active-off Mode White(Breathing) -
Page 28: Troubleshoot
Press to auto-adjust. Please refer to Regulation & Service Information which is in the CD manual Regulation & Service or www.aoc.com (to find the model you purchase in your country and to find Regulation & Service Information in Support page. -
Page 29: Specification
Specification General Specification Model name PD32M Driving system TFT Color LCD Panel Viewable Image Size 80.0 cm diagonal Pixel pitch 0.181mm(H) x 0.181mm(V) Display Color 1.07B Horizontal scan range 30~330kHz Horizontal scan Size(Maximum) 697.3056 mm 23-120Hz(USB C) Vertical scan range 48-144Hz(HDMI/DP) Vertical Scan Size(Maximum) 392.2344 mm... - Page 30 [1] Color Bit table: USB C USB C USB C USB C HDMI2.1 DP1.4 @USB @USB @USB @USB 3.2Gen1 3.2Gen1 YCbCr422 YCbCr444 YCbCr422 YCbCr444 YCbCr422 YCbCr444 Color Bit YCbCr420 YCbCr420 YCbCr420 UHD 144Hz 10 bpc UHD 144Hz 8 bpc UHD 120Hz 10 bpc UHD 120Hz 8 bpc UHD 100Hz 10 bpc UHD 100Hz 8 bpc...
-
Page 31: Preset Display Modes
Preset Display Modes HORIZONTAL VERTICAL STANDARD RESOLUTION FREQUENCY(kHz) FREQUENCY(Hz) 640x480@60Hz 31.469 59.94 640x480@67Hz 66.667 640x480@72Hz 37.861 72.809 640x480@75Hz 37.5 640x480@100Hz 51.08 99.769 640x480@120Hz 61.91 119.518 DOS MODE 720x400@70Hz 31.469 70.087 DOS MODE 720x480@60Hz 29.855 59.710 720x576@50Hz 31.25 SVGA 800x600@56Hz 35.156 56.25 SVGA 800x600@60Hz... -
Page 32: Pin Assignments
Pin Assignments 19-Pin Color Display Signal Cable Pin No. Signal Name Pin No. Signal Name Pin No. Signal Name TMDS Data 2+ TMDS Data 0- DDC/CEC Ground TMDS Data 2 Shield TMDS Clock + +5V Power TMDS Data 2- TMDS Clock Shield Hot Plug Detect TMDS Data 1+ TMDS Clock-... -
Page 33: Plug And Play
Plug and Play Plug & Play DDC2B Feature This monitor is equipped with VESA DDC2B capabilities according to the VESA DDC STANDARD. It allows the monitor to inform the host system of its identity and, depending on the level of DDC used, communicate additional information about its display capabilities.
