GZ-MS90EK/REK
INSTRUCTIONS
MEMORY CAMCORDER
LYT2049-001B-M
Dear Customer
Thank you for purchasing this
camcorder. Before use, please
read the safety information and
precautions contained in pages 2
and 3 to ensure safe use of this
product.
Contents
Accessories .....................................5
Getting Started.................................6
Recording Files ................................8
- Checking Remaining Battery
Power
Playing Back Files .........................10
Watching Images on TV.................11
Installing Software to the PC ........12
PC ..................................................13
File Backup ....................................14
File Upload to YouTube™ ..............15
Further Information ................17 - 20
EN
Advertisement
Table of Contents
Related Manuals for JVC GZ-MS90EK
Summary of Contents for JVC GZ-MS90EK
-
Page 1: Table Of Contents
LYT2049-001B-M GZ-MS90EK/REK INSTRUCTIONS MEMORY CAMCORDER Dear Customer Thank you for purchasing this camcorder. Before use, please read the safety information and precautions contained in pages 2 and 3 to ensure safe use of this product. Contents Accessories ........5 Getting Started.........6... - Page 2 Safety Precautions IMPORTANT (for owners in the U.K.) When the equipment is installed in a cabinet or on Connection to the mains supply in the United a shelf, make sure that it has sufficient space on Kingdom. all sides to allow for ventilation (10 cm or more on DO NOT cut off the mains plug from this both sides, on top and at the rear).
- Page 3 If you wish to dispose of this product, please visit our • NEVER guess or take chances with electrical web page www.jvc-europe.com to obtain information equipment of any kind — it is better to be safe than about the take-back of the product.
- Page 4 Make a backup of important Touch Sensor recorded data An example screen in English is used for the JVC will not be responsible for any lost guidance below. data. It is recommended to copy your E.g. Selecting an item from the menu list...
-
Page 5: Accessories
Accessories AC Adapter Power Cord Battery Pack AP-V14E/V20M BN-VF808U Audio/Video Cable USB Cable CD-ROM Core Filter (Z pg. 13) (Z pg. 12) (for USB Cable) * The core filter reduces interference. NOTE Make sure to use the provided cables for connections. Do not use any other cables. Attaching the Core Filter to the USB Cable Attach the core filter to the USB cable. -
Page 6: Getting Started
Getting Started NOTES Charging the Battery Pack • You can also use the camcorder with just the AC adapter. • Please do not pull or bend the AC adapter Close the LCD monitor to turn off the plug and cable. This may damage the AC camcorder. -
Page 7: Date/Time Setting
Firmly insert the card with its clipped Date/Time Setting edge first. Clipped Bottom of the Open the LCD monitor to turn on the Edge Camcorder camcorder. When [SET DATE/TIME!] appears, select [YES] within 10 seconds. SET DATE/TIME! Close the SD card cover. To remove an SD card Push the SD card once. -
Page 8: Recording Files
RECORDING Recording Files • Preparation: Insert an SD card. • Open lens cover. • Open the LCD monitor to turn on the camcorder. Slide the mode switch to select Press the SELECT PLAY/REC (video) or (still image) button to select recording mode. mode. - Page 9 OK button to recover the video there may be a problem with your battery. In management file. such a case, consult your nearest JVC dealer. • The recordable time display should only be used as a guide. It is displayed in 10 minute Manual Recording Mode units.
-
Page 10: Playing Back Files
Playback Playing Back Files To check the file information Slide the mode switch to select Press the INFO button when playback is (video) or (still image) mode. paused. To adjust the sound volume of videos Turn down Turn up the Press the SELECT PLAY/REC button the volume volume... -
Page 11: Watching Images On Tv
Watching Images on TV Preparation: Turn off all units. AV Jack DC Jack AV Cable To AC Outlet AC Adapter AV Input Jack NOTE This camcorder is designed to be used with PAL-type colour television signals. It cannot be used with a television of a different standard. -
Page 12: Installing Software To The Pc
PC OPERATION Installing Software to the PC Please read the “JVC SOFTWARE LICENSE Click [Easy Installation]. AGREEMENT” in the CD-ROM instruction before you install software. The following software is included in the CD- ROM that came with your camcorder. •... -
Page 13: Connecting The Camcorder To The Pc
Connecting the Camcorder to the PC Preparation: Close the LCD monitor to turn off the camcorder. DC Jack USB Jack USB Cable AC Adapter To AC Outlet USB Port NOTES • Never disconnect the USB cable while the access/charge lamp on the camcorder lights or blinks. -
Page 14: File Backup
File Backup File Backup (Windows ) Using File Backup (Windows ® ® Software Macintosh) without Using Software Preparation: Video files that have never been backed up onto the connected PC are automatically Connect the camcorder to the PC with the selected from the back up history and backed USB cable. -
Page 15: File Upload To Youtube
File Upload to YouTube™ This method uses software on the provided Select video category and broadcast CD-ROM to perform quick video clip upload to option. Click [Next]. YouTube™ with a simple one touch operation. The Video Title is automatically filled in during uploading process with the File name, and The presence of YouTube™... - Page 16 Contact us for Information on the Provided Software Use of this software is authorised according to the terms of the software licence. When contacting the nearest JVC office or agency in your country (refer to the JVC Worldwide Service Network at http://www.jvc-victor.co.jp/english/worldmap/index-e.html) about this software, please have the following information ready.
-
Page 17: Further Information
(Z below) • If the problem persists, please consult your The following phenomena are not nearest JVC dealer. malfunctions. To reset the camcorder • The camcorder heats up when it is used 1) Close the LCD monitor to turn off the for a long time. - Page 18 Cautions Battery Packs Recording Medium (SD Card) • Be sure to follow the guidelines below The supplied battery Terminals to prevent corruption or damage to your pack is a lithium-ion recorded data. battery. Before using • Do not bend or drop the recording medium, or the supplied battery subject it to strong pressure, jolts or vibrations.
- Page 19 Dear Customer, This apparatus is in conformance with the valid European directives and standards regarding electromagnetic compatibility and electrical safety. European representative of Victor Company of Japan Limited is: JVC Technical Services Europe GmbH Postfach 10 05 04 61145 Friedberg Germany...
- Page 20 Specifications For video/Audio Camcorder Format SD-VIDEO For general Recording/Playback format Power supply Video: MPEG-2 DC 11 V (Using AC adapter) Audio: Dolby Digital (2 ch) DC 7.2 V (Using battery pack) Signal format Power consumption PAL standard Approx. 2.3 W* Recording mode (video) * When the monitor backlight is set to ULTRA FINE: 720 x 576 pixels, 8.5 Mbps...
