ASSEMBLY RATING
The Assembly Rating is a 5-point system that
shows the degree of effort needed in
assembling a specific product (with 1 being
easy and 5 being difficult). For some
products, two persons are recommended.
EASY
Assembly Instructions
CM7365Q
DIFFICULT
Tools Required For Assembly:
Allen Wrench
Wrench
Phillips Screwdriver
2 PERSONS RECOMMENDED
Page 1 of 7
(Included)
(Included)
(Not Included)
Rev: 18-09-17
Advertisement
Related Manuals for Furniture of America CM7365Q
Summary of Contents for Furniture of America CM7365Q
- Page 1 Assembly Instructions For more information contact our team: service.ec@foagroup.com CM7365Q ASSEMBLY RATING Tools Required For Assembly: Allen Wrench The Assembly Rating is a 5-point system that (Included) shows the degree of effort needed in assembling a specific product (with 1 being...
- Page 2 LOOSEN OVER TIME AND MAY CAUSE THE FURNITURE TO BE WOBBLY AND UNABLE TO SUPPORT ITS INTENDED WEIGHT CAPACITY. THIS MAY LEAD TO COLLAPSE AND MAY CAUSE SERIOUS INJURY. FAILURE TO FOLLOW THE GUIDELINES ABOVE MAY RESULT IN INJURY AND/OR PROPERTY DAMAGE. FURNITURE OF AMERICA.ALL RIGHTS RESERVED. Page 2 of 7...
- Page 3 Before you begin, please read Page 2 of "Assembly and Care Advice". And remember, do not tighten until each step is completed or instructed. Parts List Hardware List #1 x 1pc #A x 6pcs Headboard Bolt Ø5/16" x 1-3/8" #B x 14pcs #2 x 2pcs Lock Washer Ø5/16"...
-
Page 4: Exploded View
Exploded View Align HB legs (#2R/L) to the headboard (#1), then secure by using bolts (#A) with washers (#B,C). #A x 6pcs #B x 6pcs #C x 6pcs Page 4 of 7... - Page 5 Attach support legs (#6) to the footboard (#4). Adjust the leveler on the support legs (#6) according to ground level. Attach threaded bolts (#E) to the headboard (#1) and footboard (#4), then align side rails (#3) to the threaded bolts (#E) of the headboard (#1) and footboard (#4). Secure by using half moon washers (#F), washers (#B,C), and hex nuts (#G).
- Page 6 Attach support legs (#7) to the slat kit (#5), then adjust levelers on the support legs (#7) according to ground level. Align slat kit (#5) to the side rails (#3), then secure by using screws (#I). #I x 10pcs Page 6 of 7...
- Page 7 Place dusty panel (#8) to the bottom end of the slats (#5), then secure by using screws (#J). #J x 6pcs Remove handles from the inside of drawers, then secure handles to the outside of drawers. ASSEMBLY IS COMPLETED Page 7 of 7...
- Page 8 Assembly Instructions For more information contact our team: service.ec@foagroup.com CM7365CK ASSEMBLY RATING Tools Required For Assembly: Allen Wrench The Assembly Rating is a 5-point system that (Included) shows the degree of effort needed in assembling a specific product (with 1 being Wrench easy and 5 being difficult).
- Page 9 LOOSEN OVER TIME AND MAY CAUSE THE FURNITURE TO BE WOBBLY AND UNABLE TO SUPPORT ITS INTENDED WEIGHT CAPACITY. THIS MAY LEAD TO COLLAPSE AND MAY CAUSE SERIOUS INJURY. FAILURE TO FOLLOW THE GUIDELINES ABOVE MAY RESULT IN INJURY AND/OR PROPERTY DAMAGE. FURNITURE OF AMERICA.ALL RIGHTS RESERVED. Page 2 of 8...
- Page 10 Before you begin, please read Page 2 of "Assembly and Care Advice". And remember, do not tighten until each step is completed or instructed. Parts List Hardware List #A x 6pcs #1 x 1pc Bolt Ø5/16" x 1-3/8" Headboard #B x14pcs #2 x 2pcs Lock Washer Ø5/16"...
- Page 11 Before you begin, please read Page 2 of "Assembly and Care Advice". And remember, do not tighten until each step is completed or instructed. #9 x 2pcs #I x 10pcs Top Bed Rail Screw #4 x 30mm #J x 6pcs Screw #4 x 10mm #L x 10pcs Lock Washer Ø1/4"...
- Page 12 Align HB legs (#2R/L) to the headboard (#1), then secure by using bolts (#A) with washers (#B,C). #A x 6pcs #B x 6pcs #C x 6pcs Attach support legs (#6) to the footboard (#4). Adjust the leveler on the support legs (#6) according to ground level. Page 5 of 8...
- Page 13 Attach threaded bolts (#E) to the headboard (#1) and footboard (#4), then align side rails (#3) to the threaded bolts (#E) of the headboard (#1) and footboard (#4). Secure by using half moon washers (#F), washers (#B,C), and hex nuts (#G). #B x 8pcs #C x 8pcs #E x 8pcs...
- Page 14 Align slat kit (#5) to the side rails (#3), then secure by using screws (#I). #I x 10pcs Place dusty panel (#8) to the bottom end of the slats (#5), then secure by using screws (#J). #J x 6pcs Remove handles from the inside of drawers, then secure handles to the outside of drawers.
- Page 15 Align top bed rails (#9) to the side rails, then secure by using bolts (#K) with washers (#L,M). #K x 10pcs #L x 10pcs #M x 10pcs ASSEMBLY IS COMPLETED Page 8 of 8...
- Page 16 Assembly Instructions For more information contact our team: service.ec@foagroup.com CM7365EK ASSEMBLY RATING Tools Required For Assembly: Allen Wrench The Assembly Rating is a 5-point system that (Included) shows the degree of effort needed in assembling a specific product (with 1 being Wrench easy and 5 being difficult).
- Page 17 LOOSEN OVER TIME AND MAY CAUSE THE FURNITURE TO BE WOBBLY AND UNABLE TO SUPPORT ITS INTENDED WEIGHT CAPACITY. THIS MAY LEAD TO COLLAPSE AND MAY CAUSE SERIOUS INJURY. FAILURE TO FOLLOW THE GUIDELINES ABOVE MAY RESULT IN INJURY AND/OR PROPERTY DAMAGE. FURNITURE OF AMERICA.ALL RIGHTS RESERVED. Page 2 of 7...
- Page 18 Before you begin, please read Page 2 of "Assembly and Care Advice". And remember, do not tighten until each step is completed or instructed. Parts List Hardware List #A x 6pcs #1 x 1pc Bolt Ø5/16" x 1-3/8" Headboard #B x14pcs #2 x 2pcs Lock Washer Ø5/16"...
- Page 19 Exploded View Align HB legs (#2R/L) to the headboard (#1), then secure by using bolts (#A) with washers (#B,C). #A x 6pcs #B x 6pcs #C x 6pcs Page 4 of 7...
- Page 20 Attach support legs (#6) to the footboard (#4). Adjust the leveler on the support legs (#6) according to ground level. Attach threaded bolts (#E) to the headboard (#1) and footboard (#4), then align side rails (#3) to the threaded bolts (#E) of the headboard (#1) and footboard (#4). Secure by using half moon washers (#F), washers (#B,C), and hex nuts (#G).
- Page 21 Attach support legs (#7) to the slat kit (#5), then adjust levelers on the support legs (#7) according to ground level. Align slat kit (#5) to the side rails (#3), then secure by using screws (#I). #I x 10pcs Page 6 of 7...
- Page 22 Place dusty panel (#8) to the bottom end of the slats (#5), then secure by using screws (#J). #J x 6pcs Remove handles from the inside of drawers, then secure handles to the outside of drawers. ASSEMBLY IS COMPLETED Page 7 of 7...
