Related Manuals for Candy FCP405W/E
Summary of Contents for Candy FCP405W/E
- Page 1 USER INSTRUCTIONS OVENS CANDY HOOVER GROUP S.R.L. • Via Comolli 16 • 20861 Brugherio (MB) - Italy...
- Page 2 Safety Indications • During cooking, moisture may condense inside the oven cavity or on the glass of the door. This is a normal condition. To reduce this effect, wait 10-15 minutes after turning on the power before putting food inside the oven. In any case, the condensation disappears when the oven reaches the cooking temperature.
- Page 3 • Do not use a steam cleaner for cleaning operations. • Connect a plug to the supply cable that is able to bear the voltage, current and load indicated on the tag and having the earth contact. The socket must be suitable for the load indicated on the tag and must be having the earth contact connected and in operation.
-
Page 4: Table Of Contents
Summary General Instructions 1.1 Safety indications 1.2 Electrical safety 1.3 Recommendations 1.4 Installation 1.5 Waste management 1.6 Conformity declaration Product Description 2.1 Overview 2.2 Accessories 2.3 First use Use of the Oven 3.1 Display description 3.2 Using the end of cooking timer 3.3 Setting the correct time 3.4 Cooking modes Oven Cleaning and Maintenance... -
Page 5: General Instructions
1. General Instructions We thank you for choosing one of our products. For the best results with your oven, you should read this manual carefully and retain it for future reference. Before installing the oven, take note of the serial number so that you can give it to customer service staff if any repairs are required. -
Page 6: Recommendations
NOTE: as the oven could require maintenance work, it is advisable to keep another wall socket available so that the oven can be connected to this if it is removed from the space in which it is installed. The power cable must only be substituted by technical service staff or by technicians with equivalent qualifications. -
Page 7: Product Description
2. Product Description 2.1 Overview 1. Control panel 2. Shelf positions (lateral wire grid if included) 3. Metal grill 4. Drip pan 5. Fan (behind the steel plate) 6. Oven door 2.2 Accessories (According to model) Lateral wire grids Drip pan It located at both sides of the oven cavity. -
Page 8: Use Of The Oven
3. Use of the Oven 3.1 Display description 1 10 1 00 WARNING! 1. Minute minder The first operation to carry out after installation, or after a 2. Clock setting power cut, is to set the time of day (a power cut has occured 3. - Page 9 FUNCTION HOW TO USE HOW TO DEACTIVATE WHAT IT DOES WHY IT IS NEEDED •Child Lock function is •Child Lock function is activated by touching Set deactivated by touching (+) for a minimum of 5 touchpad Set (+) again seconds. From this for a minimum of 5...
-
Page 10: Cooking Modes
3.4 Cooking Modes Function T °C T °C Function (Depends on the oven model) Dial Suggested Range LAMP: Turns on the oven light. GRILL + FAN : use the turbo-grill with the door closed. The top heating element is used with the fan circulating the air inside the oven. -
Page 11: Oven Cleaning And Maintenance
4. Oven cleaning and maintenance 4.1 General notes on cleaning The lifecycle of the appliance can be extended through regular cleaning. Wait for the oven to cool before carrying out manual cleaning operations. Never use abrasive detergents, steel wool or sharp objects for cleaning, so as to not irreparably damage the enamelled parts. -
Page 12: Removal And Cleaning Of The Glass Door
REMOVAL AND CLEANING OF THE GLASS DOOR 1. Open the oven door. 2.3.4. Lock the hinges, remove the screws and remove the upper metal cover by pulling it upwards. 5.6. Remove the glass, carefully extracting it from the oven door (NB: in pyrolytic ovens, also remove the second and third glass (if present)). -
Page 13: Changing The Bulb
CHANGING THE BULB 1. Disconnect the oven from the mains supply. 2. Undo the glass cover, unscrew the bulb and replace it with a new bulb of the same type. 3. Once the defective bulb is replaced, replace the glass cover. 5. - Page 14 INSTALLATION Opening 460 mm x 15 mm 560 mm 595 mm 580 mm 546 mm 595 mm 22 mm If the furniture is coverage with a bottom at the back part, 560 mm x 45 mm provide an opening for the power supply cable. If the mounting of the plinth does not allow air circulation, to obtain the maximum performance of the oven it is necessary to create an opening of 500x10mm or...
