PART 2 - DETAILED SYSTEM DESCRIPTION

TX-1 BASE STATION TRANSMITTER

FIELD WIDTH CONTROL
CABLE BREAK ALARM
10
POWER BOOST SWITCH
ON / OFF SWITCH
SYSTEM STATUS DISPLAY
Figure 3
General Description
The Model TX-1 Base Station Transmitter contains numerious advanced
features not found on competing systems. The TX-1 emits a radio signal
that contains a special, digital code. This code must be received and
recognized by the receiver collar before the collar will administer any
stimulus to your pet. The TX-1 weather sealed and is designed for indoor
or OUTDOOR use. The many super advanced features of your TX-1
Transmitter are as follows.
System Status Display
The fully illuminated display panel gives you the complete status of your
Base Station. On the display, the left column tells you the function being
monitored. The middle and right columns tell you the status of that function.
