PERLICK RESIDENTIAL INSTALLATION MANUAL
SAFETY
PLEASE READ all instructions completely before attempting
to install or operate the unit. Take particular note of the
DANGER, WARNING and CAUTION information in the
manual. The information is important for the safe and
efficient installation, operation and care of your Perlick unit.
DANGER
Indicates a hazard that WILL result in serious injury or
death if precautions are not followed.
WARNING
Indicates a hazard MAY cause serious injury or death if
precautions are not followed.
CAUTION
Indicates a hazard where minor injury or product
damage may occur if precautions are not followed.

OPERATION

MASTER SWITCH
Signature Series products come equipped with a master
power switch located behind the louvered toe kick.
Remove the toe kick to turn power on or off to the unit.
INTERIOR LIGHT
Door units are equipped with an interior light that
illuminate when the door is opened. The cabinet also
comes equipped with a manual light switch for displaying
the products through a glass door. For Signature Series
(HP) models, it is located in front of the control cradle. For
C-Series (HC), ADA-Compliant (HA) and Shallow-Depth
(HH) models, this is located on the back wall left of the
light.
Always ensure that the manual light switch is in the OFF
position before closing a solid wood or stainless steel
door. If manual light switch is left on for an extended
period of time, it may increase the cabinet temperature,
and cause the refrigeration system to run harder.
4 perlick.com
LOADING PRODUCT
Before storing perishables, turn unit on and allow it to
operate for a minimum of 24 hours to allow temperatures
to stabilize.
When loading items into the unit, do not block internal
louvers and fan guard openings or performance will be
decreased.
CHECKING PRODUCT TEMPERATURE
1). To accurately check the temperature of product stored
in the refrigerated compartment, insert an accurate
thermometer into a plastic unbreakable bottle, partially
filled with water. Tighten bottle cap securely.
2). Place the bottle in the desired area for 24 hours. Refrain
from opening the unit during the testing period. After
24 hours, check the temperature of the water. Adjust the
temperature accordingly using the following procedures:

DIGITAL TEMPERATURE CONTROL

Signature Series Models
Figure 1. Digital Temperature Controller
Perlick Signature Series units come standard with state-
of-the-art digital control. Please note there are two sets
of instructions; one for 24" Signature Series Dual-Zone
models, and another set for 15", 24" Single-Zone, and 48"
Signature Series models.
Programming Button Definitions:
SET button
DEFROST button (melting snowflake)
UP arrow
DOWN arrow
ON/OFF button
