Safety Precautions Read and follow these safety precautions. WARNING Do not allow children to use on their own. ● This appliance is not intended for use by persons May cause serious (including children) with reduced physical, sensory injury or death. or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning use of the appliance by a...
Part Names Lint filter (P. 10) CAUTION Power cord and plug Bleach / Liquid (P. 13) detergent inlet (P. 6) May cause injury or property damage. Operation Panel (P. 4) Do not wash, rinse, or spin waterproof sheets or clothes. (To prevent injury, damage to the main unit, walls, floor or laundry, or water leakage if the appliance falls over Softener...
Detergent volume After approx. 5 seconds, indicates the where it was stopped when approximate remaining time (min). the power is recovered. • Operation panel of NA-F80VB7 Start/Pause Wash/Rinse/Spin Program selection (P. 5) (P. 9) Child Lock lamp (P. 10)
Variety of Programs Maximum capacity Purpose Program NA-F80VB7 NA-F75S7 NA-F70S7 Everyday Normal Daily washing 8.0 kg 7.5 kg 7.0 kg (P. 7) clothes Washing Delicate Delicates 3.5 kg 3.5 kg 3.5 kg delicates gently (P. 8) Clothes for babies &...
Detergent Putting in detergent Put in detergent, bleach and softener according to the water ● When powdered detergent is poorly soluble, dissolve level displayed. in warm water before putting in. • Put in the detergent little ● Follow the instructions on each package. by little while stirring to prevent it from getting hard or remaining in a...
Washing Preparation: ● Check if the washing machine is properly installed. (P. 12) ● Turn on the water faucet. • Operation panel of NA-F80VB7 Timer preset After loading laundry Turn the power on. Set how many hours later to finish operation.
Washing Options • Operation panel of NA-F80VB7 Change process settings Select a program Delicate Blanket ■ Use this program to gently wash delicate Washable blankets clothes and stylish garments. • Material: 100 % synthetic fibre or 100 % cotton • Weight: 4.2 kg or less •...
Air Dry Wash / Rinse / Spin Water is removed from clothes by the air Preparation: Turn on the water faucet. blown from the tub rotation. After loading laundry ■ Clothes that can be dried • Material: Synthetic fibre Turn the power on. •...
● Turn the tub by hand if it is difficult to remove the filter. NOTE ● If the filter is broken, purchase a new one at nearest ● If there is water in the tub or “Start” is pressed, the Panasonic Service Centre. tub cannot be turned.
Page 11
Water supply filter If water does not flow smoothly Once a week <Air Dry> ● Follow the procedure below to prevent After operation ends splashing of water. Run the Air Dry program After turning off the water faucet without loading laundry. Turn the power (P.
Installation 1. Check the location. ■ Avoid the following locations for installation. • Locations with a possibility of freezing • Damp locations or locations where it may be exposed to rain, etc. (To prevent electric shock or fire) • Locations exposed to direct sunlight (To prevent malfunction or deformation) •...
Page 13
■ If the installation, test run and inspection of the washing machine are not carried out following this installation method, Panasonic will not be liable for any accident or damage caused. 4. Connect the water tap adaptor and water supply hose.
Troubleshooting Symptoms Points to be checked Time indication ● Time indication is approximate. Remaining time is corrected during increases or does not operation and displayed. change Operation time is longer ● The operation time may be longer if laundry is concentrated on one than the time indication.
Error Display ● The buzzer sounds and “U”/“H” and a number are alternately displayed. ● Cancel Child Lock (P. 10) if it is set. Error display Points to be checked Water cannot drain. Check the drain water hose for the following abnormalities: ●...
Page 17
Arahan Pengendalian & Pemasangan Mesin Basuh Automatik Sepenuhnya (Kegunaan domestik) NA-F80VB7 No. Model NA-F75S7 NA-F70S7 Kandungan Langkah Berjaga-jaga Keselamatan Nama Bahagian Panel Operasi Pelbagai Program Detergen Membasuh Pilihan Membasuh • Delicate (Halus) • Blanket (Selimut) • Air Dry (Kering Udara) •...
Langkah Berjaga-jaga Keselamatan Sila baca dan ikut langkah berjaga-jaga keselamatan ini. AMARAN Jangan benarkan kanak-kanak menggunakannya sendirian. Boleh mengakibatkan Perlengkapan ini bukan untuk kegunaan individu kecederaan serius zikal, deria atau mental, atau kurang pengalaman atau kematian. atau pengetahuan, kecuali jika mereka telah diberikan penyeliaan atau arahan berkaitan penggunaan perlengkapan ini oleh individu yang Jangan lakukan perkara berikut...
Nama Bahagian Penapis rumbai Penutup (H. 10) AWAS Kord dan Tempat masuk palam kuasa cecair pemutih / (H. 13) detergen (H. 6) Mengakibatkan kecederaan atau kerosakan harta benda. Panel Operasi (H. 4) Jangan basuh, bilas atau perah kain atau pakaian yang kalis air. (Untuk mencegah kecederaan, kerosakan kepada unit utama, dinding, lantai atau kain basuhan, atau Inlet...
Isipadu detergen Selepas kira-kira 5 saat, ia menunjukkan semula di mana ia berhenti anggaran baki masa (min). apabila kuasa pulih. • Panel Operasi NA-F80VB7 Basuh / Bilas / Perah Pemilihan program (H. 5) Mula/Jeda (H. 9) Lampu Kunci Kanak-kanak (H. 10)
Pelbagai Program Kapasiti maksimum Tujuan Program NA-F80VB7 NA-F75S7 NA-F70S7 Pakaian Normal (Biasa) Basuhan harian 8.0 kg 7.5 kg 7.0 kg harian (H. 7) Membasuh item Delicate (Halus) Pakaian halus 3.5 kg 3.5 kg 3.5 kg halus dengan lembut (H. 8) Pakaian untuk bayi &...
Detergen Detergen Masukkan detergen, peluntur dan pelembut mengikut jumlah Apabila detergen serbuk adalah kurang larut, air yang dipaparkan. larutkan dalam air suam sebelum letakkan dalam. • Masukkan detergen sedikit Ikut arahan di setiap bungkusan. demi sedikit manakala untuk mencegahnya dari menjadi keras atau baki dalam keadaan serbuk.
Membasuh Persediaan: Periksa untuk menentukan mesin basuh sudah dipasang dengan betul. (H. 12) Buka pili air. • Panel operasi NA-F80VB7 Pratetapan pemasa Selepas memuatkan kain basuhan Tetapkan berapa jam kemudian operasi Hidupkan kuasa. perlu tamat. (H. 4) Pilih program. (H. 5) cth.) program 1...
Pilihan Membasuh • Panel operasi NA-F80VB7 Tukar tetapan proses Pilih program Delicate (Halus) Blanket (Selimut) Gunakan program ini untuk membasuh Selimut boleh basuh pakaian halus dan bergaya dengan lembut. • Bahan: Gentian sintetik 100 % atau Kapas 100 % • Berat: 4.2 kg atau kurang •...
Air Dry (Kering Udara) Wash (Basuh) / Rinse (Bilas) / Wash/Rinse/Spin Spin (Perah) Air disingkirkan daripada pakaian dengan tiupan udara daripada putaran tab. Persediaan: Buka pili air. Pakaian yang boleh dikeringkan Selepas memuatkan kain basuhan • Bahan: Gentian sintetik • Berat: 2.0 kg atau kurang Hidupkan kuasa.
(Mengikut arah jam sahaja) Pusing tab dengan tangan jika sukar untuk menanggalkan penapis. Jika penapis rosak, beli yang baharu di Pusat Servis NOTA Panasonic yang berdekatan. Jika terdapat air di dalam tab atau “Start (Mula.)” ditekan, tab tidak boleh dipusing.
Page 27
Penapis bekalan air Jika air tidak mengalir dengan lancar Sekali seminggu <Air Dry (Kering Udara)> Ikuti prosedur di bawah bagi mencegah Selepas pembasuhan selesai air memercik. Jalankan program Air Dry Selepas menutup pili air (Kering Udara) tanpa Hidupkan memuatkan basuhan. (H.
Pemasangan 1. Periksa lokasi. Elakkan lokasi berikut untuk pemasangan. • Lokasi di mana terdapat kemungkinan pembekuan • Lokasi yang basah atau lokasi yang mungkin terdedah kepada hujan, dll. (Untuk mencegah kejutan elektrik atau kebakaran) • Lokasi terdedah kepada sinaran matahari langsung (Untuk mencegah malfungsi atau kecacatan) Penyesuai pili air •...
Page 29
Pastikan anda meminta juruservis melakukan pemasangan. Jangan pasang sendiri. Sekiranya pemasangan, ujian jalanan dan pemeriksaan mesin basuh tidak dijalankan mengikut kaedah pemasangan ini, Panasonic tidak akan bertanggungjawab atas sebarang kemalangan atau kerosakan yang disebabkan olehnya. 4. Sambungkan penyesuai pili air dengan hos bekalan air.
Penyelesaian Masalah Gejala Perkara perlu diperiksa Penunjuk masa meningkat Petunjuk masa adalah anggaran sahaja. Baki masa diperbetulkan atau tidak menurun semasa operasi dan dipaparkan. Masa operasi lebih lama daripada penunjuk masa. Masa operasi menjadi lebih lama jika basuhan berlonggok ke satu Operasi tidak berhenti sisi atau bekalan air atau saliran tidak baik keadaannya.
Paparan Ralat Pembaz berbunyi dan “U” / “H” dan nombor dipaparkan bersilih ganti. Batalkan Kunci Kanak-Kanak (H. 10) jika ia telah ditetapkan. Paparan ralat Perkara perlu diperiksa Air tidak boleh disalirkan keluar. Periksa hos air saliran untuk menentukan keabnormalan berikut: Adakah ia dihimpit? Adakah ia tersumbat oleh rumbai? Adakah hujung hos di bawah air?
