Service Manual
The service information is designed for experienced repair technicians only and is not designed for use by the general
public. It does not contain warnings or cautions to advise non-technical individuals of potential dangers in attempting
to service a product. Products powered by electricity should be serviced or repaired only by experienced professional
technicians. Any attempt to service or repair the product or products dealt within this service information by anyone
else could result in serious injury or death.
There are special components used in this equipment which are important for safety. These parts are marked by
in the Schematic Diagrams, Circuit Board Diagrams, Exploded Views and Replacement Parts List. It is essential that
these critical parts should be replaced with manufacturer's specifi ed parts to prevent shock, fi re or other hazards. Do
not modify the original design without permission of manufacturer.
Fully Automatic Washing Machine
WARNING
IMPORTANT SAFETY NOTICE
[Revision : Au ust 201 ]
© Panasonic Appliances (Thailand) Co., Ltd. 201 .
All rights reserved. Unauthorized copying and
distribution is a violation of law.
Order No.
PAPTH171101CE
NA-FS95A1
NA-F95A1
NA-F85A1
Product Colour
White (W)
Destination
Australia
New Zealand

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the NA-FS95A1 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Panasonic NA-FS95A1

Summary of Contents for Panasonic NA-FS95A1

  • Page 1 fi re or other hazards. Do not modify the original design without permission of manufacturer. © Panasonic Appliances (Thailand) Co., Ltd. 201 . All rights reserved. Unauthorized copying and...

  • Page 2: Parts Exploded View And Replacement Parts List

    2 PARTS IDENTIFICATION 3 SPECIFICATIONS 4 TECHNICAL INFORMATION 4.1 Standard Wash Capacity 4.2 Standard Water Supply 5 INSTALLATION 6 OPERATION PANEL 6.1 NA-FS95A1 6.2 NA-F95A1,NA-F85A1 7 WASHING 7.1 NA-FS95A1 7.2 NA-F95A1,NA-F85A1 8 WASHING OPTIONS 14~15 9 CONVENIENT FUNCTION & MAINTENANCE...

  • Page 3: Attention In The Repair Work Security

    1. ATTENTION IN THE REPAIR WORK SECURITY In order to prevent any accident during repair work and ensure security of the product after repair work, somethings surely followed are explained below. The level of the arised damages or dangers, when indicated contents are ignored, are classified by following indications and explained.

  • Page 4: Parts Identification

    2. PARTS IDENTIFICATION Operation Drain hose Panel Leveller Lint fi lter Power cord and plug Softener case Detergent Pulsator inlet Adjustable leg Water supply valve ●COLD ●HOT Accessories ● Water supply ● Water supply ● Bottom cover (1) hose for HOT hose for COLD ●...

  • Page 5: Specifications

    3. SPECIFICATIONS Countries Australia / New Zealand Model F85A1 F95A1 FS95A1 WD1V WD1X WD1Z Australia Model Code WD1W WD1Y WD20 Newzealand Colour white white white Body Code Power cord unit Rate voltage and Frequency 220240V/50Hz 220240V/50Hz 220240V/50Hz Wash 580W 590W 590W Rate Power Consumption...

  • Page 6: Technical Information

    160 min 12 min 3 times 7 min TUB HYGIENE 150 min 12 mim Refill 2 times 7 mim 4.3 Standard Water Supply FOR NA-FS95A1 TOTAL TIME PROGRAM WASH RINSE SPIN (APPROX.) COTTON 60 min 12 min Refill 2 times...

  • Page 7: Installation

    5. INSTALLATION COLD Water supply COLD hose for COLD (Grey) Elbow Water supply valve screw Holes for the hose holder Water supply hose for HOT (white) Bottom cover Drain hose 1. Check the location. ■ Avoid the following locations for installation. •...
  • Page 8 ■ Make sure to ask a service person for installation. Do not install by yourself. ■ If the installation, test run and inspection of the washing machine are not carried out following this installation method, Panasonic will not be liable for any accident or damage caused. 3. Attach the drain hose.

  • Page 9: Connect The Water Supply Hose

    4. Connect the water supply hose. Water supply Attach one end of the valve screw water supply hose to the Water faucet COLD HOT water supply valve screw. 1 Hold the elbow and tighten the Water supply hose Elbow nut. 2 Check that the elbow is not CAUTION loose.

  • Page 10: Operation Panel

    6. OPERATION PANEL 6.1 NA-FS95A1 Change water Water amount/remaining time Water level/water amounts amount Extra High Level 10-8 During the wash process, press “Water Detergent * After starting operation, indicates Level” to change the the water amount according to the water amount.
  • Page 11 6.2 NA-F95A1, NA-F85A1 Change water Water amount/remaining time Water level/water amounts amount Extra High Model Level 10-8 During the wash process, press “Water Level” to Detergent * After starting operation, indicates change the water amount. the water amount according to the ●...

  • Page 12: Put In Detergent

    7. WASHING 7.1 NA-FS95A1 Preparation: ● Check if the washing machine is properly installed. ● Turn on the water faucet. ● When using Temp Setting, turn on both hot and cold water faucets. Temp setting Quick Wash Bedding Timer preset After loading laundry Press to select Hot/Warm/Cold for Turn the power on.

  • Page 13: Select A Program

    7.2 NA-F95A1, NA-F85A1 Preparation: ● Check if the washing machine is properly installed. ● Turn on the water faucet. ● When using Temp Setting, turn on both hot and cold water faucets. Temp setting Timer preset After loading laundry Press to select Hot/Warm/Cold for Turn the power on.

  • Page 14: Washing Options

    8. WASHING OPTIONS Bedding Delicate ■ Use this program to gently wash delicate Washable blankets clothes and stylish garments. ● Material: 100 % synthetic fi bre or 100 % ■ cotton Load laundry evenly ● Weight: 4.2 kg or less (King size bed) ●...
  • Page 15 Bedding Cotton Eco ■ With the “Cotton Eco” cycle the washing Washable blankets machine consumes less energy and water. ● Material: 100 % synthetic fi bre or 100 % ■ cotton About Detergent ● Weight: 4.2 kg or less (King size bed) ●...

  • Page 16: Setting Child Lock

    9. CONVENIENT FUNCTIONS & MAINTENANCE Cancelling end buzzer Lint fi lter After each operation Pressing down, Lint fi lter press. Then hold on for 2 short 3 seconds. beeps 4 short Remove the ● To reset, do the same procedure. beeps fi...
  • Page 17 Water supply fi lter If water does not fl ow smoothly Once a week <Air Dry> ● Follow the procedure below to prevent After operation ends splashing of water. Run the Air Dry program After turning off both hot and without loading laundry.

  • Page 18: Test Mode

    10. TEST MODE NA-FS95A1 Fig-1 - Set the power switch to "off" as. - Press and hold both the "Water level" and Air Dry with one hand. - Press the power swith to "ON". - Release your fingers from the buttons and power switch which you pressed same as Fig-1.
  • Page 19 ●Spinning operation ●The spinning operation, ●Lid / SF switch Check lid & SF switch operation / PUMP UNIT. / PUMP UNIT. ●“Light up” lid switch working. ●Adjust the water ●Press the “Wash” button to amount against adjust L0 (initial mode) amount detection L1 (1-rank higher water level).

  • Page 20: Troubleshooting

    11. TROUBLESHOOTING Symptoms Points to be checked Time indication increases ● Time indication is approximate. Remaining time is corrected or does not decrease. during operation and displayed. Operation time is longer ● The operation time may be longer if laundry is concentrated than the time indication.
  • Page 21 12. TABLE OF ERRORS 12.1 U-Error indication ● If there is an operation error or if there is a problem with the washing machine, such as faulty draining, spining etc; operation will stop, the warning buzzer will sound, and an error indication will be displayed. - All the switchs cannot be operated.
  • Page 22 12.2 H-Error indication ● If there is an operation error or if there is a problem with the washing machine, - All the switchs cannot be operated. - An error indication will be displayed. Indication Content Check Point Method to clear Water level sensor ●Check at condition of the connector ●Disconnect the power...

  • Page 23: Wiring Diagram

    13. WIRING DIAGRAM 13.1 NA-FS95A1 13.2 NA-F95A1, NA-F85A1 - 23 -...

  • Page 24: Disassembly And Assembly Instruction

    14. DISASSEMBLY AND ASSEMBLY INSTRUCTION 14.1 Controller unit replacement 1 Use a screw driver (Phillips type) remove 4 screws rear side of Panel A. 2 Lift up panel A 3 Unhook and remove insulation spacer A. <Used screw driver (Flash Type) loose from hook> 4 Remove 7 screws and remove all connector.
  • Page 25 14.3 MECHA CASE UNIT REPLACEMENT 1 Follow the procedure content of 14.2 <Need to lift up Body B> 2 Set the Body B against the product and wall for support. 3 Remove the outer tub cover <8 Hooks> Remove the Pulsator. *Remove the screw cap.
  • Page 26 Remove the shaft bush,the Spin-dry shaft nut,and D-shaft washer B. *When attaching,make sure to insert the Shaft bush the right way. <Inside with the hole should face upwards> *When removing the Spin-dry shaft nut,the tools listed below are necessary. HW-25K (Flange nut remover tool) How to use? 1.Attach the "Fixer"...

  • Page 27: Motor Replacement

    6 Remove 4 screws of Spinner plate B. Spinner Plate B 7 Remove 4 screws of Mecha case unit. Reassemble : Tighten 4 screws in cross direction Mecha case unit *Note* : After replacing the Mecha case unit, Run WASH&SPIN dry operation, Purpose to make sure they are operation properly well.
  • Page 28 PRECAUTION 1.Warning Statement Follow the procedure below for the lead wire connection. → Be sure to swage the lead wire connection by using the insulated close-end connector. <Be sure to use the specifi ed parts and criming pliers> → Cover the connection section completely with a chemical cover and close up the openings with tapes. <Re-use the chemical cover provided with the product>...
  • Page 29 14.6 GEARED MOTOR REPLACEMENT 1 Pull the product forward and down. 2 Remove 3 screws and the connectors of the Geared motor. 3 Remove part of the Geared motor slider from cock and remove the Geared motor. *After replacing the Geared motor,run the spin-dry operation and check to make sure it is operating properly. Geared motor 14.7 VALVE UNIT AND GEARED MOTOR REPLACEMENT 1 Remove screws of the Geared motor.
