READ AND SAVE THESE INSTRUCTIONS
Ceiling Fan Owner's Manual
CF901BS00 -
CF901GES00 -
CF901ORB00 -
CF901SW00 -
CF901VNB00 -
Questions, problems, missing parts: Before returning to the store call
Part No. F40BP74460001
Revision: 131015
PRIMA
Model Numbers
Brushed Steel
Golden Espresso
Oil Rubbed Bronze
Satin White
Venetian Bronze
20.3
Net Weight:
Emerson Electric Customer Service
8 a.m. - 6 p.m., Eastern, Monday-Friday
1-800-654-3545
www.emersonfans.com
™
Lbs.
Form No. BP7446-1
U.L. Model No.: CF901
Advertisement
Table of Contents
Related Manuals for Emerson PRIMA CF901GES00
Summary of Contents for Emerson PRIMA CF901GES00
- Page 1 Satin White CF901VNB00 - Venetian Bronze 20.3 Net Weight: Lbs. Questions, problems, missing parts: Before returning to the store call Emerson Electric Customer Service 8 a.m. - 6 p.m., Eastern, Monday-Friday 1-800-654-3545 Part No. F40BP74460001 Form No. BP7446-1 www.emersonfans.com Revision: 131015...
-
Page 2: Table Of Contents
Rhine Electric Co., Ltd. come to a complete stop. WARNING: To avoid fire, shock or injury, do not use an Emerson or any other brand of control not specifically approved for this fan. Additional Safety Instructions for Installation WARNING: This product is designed to use only those 1. -
Page 3: Unpacking Instructions
Hanger Ball/Downrod Assembly accessories not designated for use with this product Switch Housing Assembly by Emerson Electric Co. could result in personal injury or property damage. One 4-speed fan speed control 1. Check to see that you have received the following... -
Page 4: Electrical Requirements
1. Unpacking Instructions (continued) This Manual Is Designed to Make it as Easy as Possible for You to Assemble, Install, Operate and Maintain Your Ceiling Fan Tools Needed for Assembly WARNING One Phillips head screwdriver One stepladder Before assembling your ceiling fan, refer to section on One 1/4”... -
Page 5: Ceiling Fan Assembly
3. Ceiling Fan Assembly 1. Remove the hanger ball by loosening the setscrew in the hanger ball until the ball falls freely down the downrod (Figure 1). Remove the pin from the HANGER BALL downrod, then remove the hanger ball. Retain the pin and hanger ball for reinstallation in step 4. - Page 6 3. Ceiling Fan Assembly (continued) 5. The fan comes with blue, black and white leads that are 80” long. Before installing fan, measure up approximately 6 to 9-inches above top of hanger ball/downrod assembly. Cut off excess leads and strip back insulation 1/2-inch from end of leads. 6.
- Page 7 3. Ceiling Fan Assembly (continued) 11. Engage the connector of the switch housing assembly with the motor connector (Figure 7). The two connectors are keyed and color-coded and must be mated correctly (color-to-color) before they can be engaged. Make sure the connector latch closes properly.
-
Page 8: How To Hang Your Ceiling Fan
4. How to Hang Your Ceiling Fan WARNING CEILING The fan must be hung with at least 7' of clearance from floor to blades (Figure 9). WARNING AT LEAST The outlet box and joist must be securely mounted and capable of supporting at least 50 lbs. Use only a U.L. outlet box listed as “Acceptable for Fan Support of 22.7 kg. -
Page 9: How To Wire Your Ceiling Fan
OMITTED FOR CLARITY. insulation). Securely connect wires with wire connectors supplied. Figure 12 NOTE: If you are using an Emerson Light Fixture with your fan, see Light Fixture Owner’s Manual for wiring. 2. Securely connect the fan motor white wire to the supply white (neutral) wire using wire connector supplied (Figure 12). -
Page 10: Wall Control Installation
5. How to Wire Your Ceiling Fan (continued) WARNING CEILING COVER Check to see that all connections are tight, including ground, and that no bare wire is visible at the wire connectors, except for the ground wire. Do not operate fan until blades are in place. Noise and fan damage could result. - Page 11 6. Wall Control Installation (continued) 5. Connect one BLACK wire from the fan speed control STANDARD ON-OFF to the fan/motor lead with a wire connector WALL LIGHT SWITCH (provided). (Figure 15.) TO FAN LIGHT NEUTRAL TO FAN MOTOR LOAD 6. Connect the other BLACK wire from the fan speed 120-VOLT LIGHT control to the 120VAC hot wire with a wire connector...
-
Page 12: Operation Of Reverse Switch
Emerson Electric Co. Substitution of parts or WARNING accessories not designated for use with this product by Emerson Electric Co. could result in personal injury The use of any other control not specifically approved or property damage. for this fan could result in fire, shock and personal injury. -
Page 13: Maintenance
10. Maintenance Abrasive cleaning agents are not required and should IMPORTANT CARE INSTRUCTIONS be avoided to prevent damage to finish. for your Ceiling Fan Periodic cleaning of your new ceiling fan is the only WARNING maintenance that is needed. Do not use water when cleaning your ceiling fan. It When cleaning, use only a soft brush or lint free cloth to could damage the motor or the blades and create the avoid scratching the finish. -
Page 14: Repair Parts
12. Repair Parts ETL Model No.: CF901... - Page 15 12. Repair Parts Listing Model Numbers Description CF901BS00 CF901GES00 CF901ORB00 CF901SW00 CF901VNB00 Hanger Ball Assembly, 761655-17 761655-35 761655-32 761655-92 761655-89 Consisting of: Hanger Bracket — — — — — Hanger Ball — — — — — Downrod (4.5”) — — —...
- Page 16 Notes ETL Model No.: CF901...
- Page 17 Notes U.L. Model No.: CF901...
- Page 18 Notes ETL Model No.: CF901...
-
Page 19: Ceiling Fan Limited Warranty
What We Will Do To Correct Problems: If during the one (1) year warranty period the motor or any component or accessory of your Emerson Ceiling Fan is defective in materials or workmanship, or if during the expected lifetime of the Emerson Ceiling Fan (when used in accordance with the User Manual or other instructions) the motor is defective in materials or workmanship, you must contact Emerson during the applicable warranty period. - Page 20 Air Comfort Products DIVISION OF EMERSON ELECTRIC CO. 8100 W. Florissant • St. Louis, MO 63136 Questions, problems, missing parts: Before returning to the store call Emerson Electric Customer Service 8 a.m. - 6 p.m., Eastern, Monday-Friday 1-800-654-3545 www.emersonfans.com Retain this manual for future use.
