READ AND SAVE THESE INSTRUCTIONS
52" Ceiling Fan Owner's Manual
CF901BS00 -
CF901ORB00 -
CF901SW00 -
CF901VNB00 -
Questions, problems, missing parts: Before returning to the store call
Emerson Electric Customer Service - 8 a.m. - 6 p.m., Eastern, Monday-Friday
Part No. F40BP74460002
Revision: 180404
PRIMA
Model Numbers
Brushed Steel
Oil Rubbed Bronze
Satin White
Venetian Bronze
20.3
Net Weight:
1-800-654-3545
www.emersonfans.com
™
Lbs.
4
3
2
1
0
Form No. BP7446-2
U.L. Model No.: CF901
