Textron Greenlee Gator EK1240CL Operation Manual
Battery-powered crimping tools
Hide thumbs
Also See for Greenlee Gator EK1240CL:
- Service manual (31 pages) ,
- Operation manual (12 pages)
Table of Contents
Advertisement
Quick Links
OPERATION MANUAL
Serial Number
GATOR
®
EK1240L and EK1240CL
Battery-powered
Crimping Tools
Read and understand all of the instructions and
safety information in this manual before operating
or servicing this tool.
Register this product at www.greenlee.com
52047660 REV 4
© 2014 Greenlee Textron Inc.
3/14
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Textron Greenlee Gator EK1240CL
Summary of Contents for Textron Greenlee Gator EK1240CL
- Page 1 ® EK1240L and EK1240CL Battery-powered Crimping Tools Read and understand all of the instructions and safety information in this manual before operating or servicing this tool. Register this product at www.greenlee.com 52047660 REV 4 © 2014 Greenlee Textron Inc. 3/14...
-
Page 2: Table Of Contents
For recycling information, go to www.greenlee.com. All specifications are nominal and may change as design improvements occur. Greenlee Textron Inc. shall not be liable for damages resulting from misapplication or misuse of its products. GATOR is a registered trademark of Textron Innovations Inc. -
Page 3: Important Safety Information
Failure to observe this warning could result in severe injury or death. Greenlee / A Textron Company 4455 Boeing Dr. • Rockford, IL 61109-2988 USA • 815-397-7070... - Page 4 • Use this tool for the manufacturer’s intended purpose only. Failure to observe these precautions may result in injury or property damage. Greenlee / A Textron Company 4455 Boeing Dr. • Rockford, IL 61109-2988 USA • 815-397-7070...
-
Page 5: Identification
18 V, 3 Ah lithium-ion battery 52054992 Li (18 V) to NiCd, NiMH (12 V) charger adapter 52049201 120 VAC, 18 V charger 50122746 Carrying strap Greenlee / A Textron Company 4455 Boeing Dr. • Rockford, IL 61109-2988 USA • 815-397-7070... -
Page 6: Operation
• If the tool is unable to reach the required crimp force, the red LED, work light, and an audible beep will pulse until after the trigger is released. Greenlee / A Textron Company 4455 Boeing Dr. • Rockford, IL 61109-2988 USA • 815-397-7070... - Page 7 SIDE A complete. Failure to observe these warnings could result in severe injury or death. 1ST COMPRESSION SIDE B CRIMPING DIRECTION SIDE A Greenlee / A Textron Company 4455 Boeing Dr. • Rockford, IL 61109-2988 USA • 815-397-7070...
-
Page 8: Die Selection
YA-A ACL/ACN 60176; 400 to Aluminum VACL BLUA number provided with YA-ATN 2ACL/2ACN 60230 to 750 kcmil: Lugs the connector. 60278 3 crimps Greenlee / A Textron Company 4455 Boeing Dr. • Rockford, IL 61109-2988 USA • 815-397-7070... -
Page 9: Maintenance
Failure to observe these warnings could result in severe injury or death. Relief valve adjustments must be done by an authorized service center. Greenlee / A Textron Company 4455 Boeing Dr. • Rockford, IL 61109-2988 USA • 815-397-7070... -
Page 10: Troubleshooting
Tool loses oil. Damaged internal seal. Return tool to a Greenlee Authorized Service Center. Note: For Warranty Service or Repair, contact Greenlee customer service at 800-435-0786. Greenlee / A Textron Company 4455 Boeing Dr. • Rockford, IL 61109-2988 USA • 815-397-7070... - Page 11 EK1240L and EK1240CL Crimping Tools Greenlee / A Textron Company 4455 Boeing Dr. • Rockford, IL 61109-2988 USA • 815-397-7070...
- Page 12 4455 Boeing Drive • Rockford, IL 61109-2988 • USA • 815-397-7070 USA Tel: 800-435-0786 Canada Tel: 800-435-0786 International Tel: +1-815-397-7070 An ISO 9001 Company • Fax: 800-451-2632 Fax: 800-524-2853 Fax: +1-815-397-9247 Greenlee Textron Inc. is a subsidiary of Textron Inc. www.greenlee.com...
