Mounting Dream MD2126-24 Installation Instruction

Hide thumbs

Advertisement

Quick Links

Download this manual
INSTALLATION INSTRUCTION
Please read this instruction carefully before installation .
Fits for most 42-70 inches Plasma, LCD and LED TVs .
Weight capacity: 45.5 kg (100 LBS) .
Thank you for purchase!We strive to provide products and services of exceptional quality.
We sincerely invite you to write an unbiased review. For parts missed or installation problems,
please contact us at telephone (626) 604-9048 (USA) Mon - Fri 10am - 6pm (Pacific time) or email
us by customerservice@mountingdream.com , so that we may solve the issue for you.
Max VESA:
600X400 mm/24X16"
MODEL : MD2126-24
(A1)

Advertisement

loading
Need help?

Need help?

Do you have a question about the MD2126-24 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Mounting Dream MD2126-24

Summary of Contents for Mounting Dream MD2126-24

  • Page 1 INSTALLATION INSTRUCTION Max VESA: 600X400 mm/24X16" MODEL : MD2126-24 Please read this instruction carefully before installation . Fits for most 42-70 inches Plasma, LCD and LED TVs . Weight capacity: 45.5 kg (100 LBS) . Thank you for purchase!We strive to provide products and services of exceptional quality.
  • Page 2 Avertissement de sécurité: bienvenue à choisir le support suspendu de téléviseur de la Vue Aérienne, pour garantir un usage sécurité du produit MD2126-24, préserver le risque contre vous-même et des tiers et éviter ledommage des biens, veuillez lire soigneusement ce manuel avant l'usage. Si vous ne pouvez pas comprendre cette notice ou en cas de doute sur la sécurité...
  • Page 3 Before getting started, let's make sure this mount is perfect for you! Is your TV VESA equal to/greater than 200x100mm/8x4in and equal to /less than VESA 600x400mm/24x16in ? MAX:600mm/24" Yes --- Perfect! MAX: 400mm/16" No --- This mount is NOT compatible. Does your TV (including accessories) weigh more than 100 lbs (45.5kg)? NO --- Perfect!

  • Page 4: Part List

    For parts shortage or damage, please contact us directly by customerservice@mountingdream.com. Attention: New delivery will be timely arrange d to replace missed or defective parts. Installation tools: 2M 2M Band tape Bubble level Stud finder Pencil Screwdriver Socket wrench 3/8" 7/32"...
  • Page 5 Wall mounting and TV bracket assembly hardware: --Lag bolt --M8 Washer --4mm Allen key --M6X15 Bolt 4pcs 4pcs 2pcs TV mounting hardware: a--M4X12 bolt b--M5X12 bolt c--M6X12 bolt d--M8X25 bolt 4pcs 4pcs 4pcs 4pcs e--M4X30 bolt f--M5X30 bolt g--M6X35 bolt h--M8X50 bolt 4pcs 4pcs...
  • Page 6 Step 1 Wall plate installation : Option 1 Wall plate installation in wood stud To avoid potential body injury or property damage: 1. Wall mount must be installed into wood stud's center, not drywall alone. 2. Drywall covering the wood stud must not exceed 16 mm (5/8 in.). 3.
  • Page 7 ③ ④ ⑤ 24" 24" wood stud 7/32" side holes on two studs Make sure the BOLT HEAD on the wall plate is upward Place Mounting template Use 7/32" diameter drill bit to Take down the Mounting template, put 4 lag bolts along the centerlines, level it drill 4 pilot holes at marked through the washers...
  • Page 8 Step 2 Select TV hardware (diameter / length / combination) Bolt diameter: hand thread bolts into threaded inserts on the back of TV to determine correct bolt diameter (M4, M5, M6, M8). Bolt length: verify adequate thread engagement with bolts or bolts/spacers combination.
  • Page 9 Step 3 Attach brackets to the back of the TV: ① For the TV with flat back, mount the brackets with bolt/washer/spacer combination. Tips: Make sure the ends of TV brackets with round holes are facing upward. Round hole is for upper VESA hole, and long slot hole for lower VESA hole.
  • Page 10 ② For TV with inset mounting holes, mount the brackets with bolt/washer/spacer combination. (Spacers are highly recommended to be added, thus enlarge the space between TV and brackets for better functionality.) Tips: Make sure the ends of TV brackets with round holes are facing upward.
  • Page 11 Step 4 Hang the pre-assembled TV unit onto the horizontal bars of the wall plate unit. Two people are recommended to hold and position the TV. And cables are recommended to plug in before hanging the TV. Step 5 Fasten the tube clips with brackets by using bolts with a screwdriver.
  • Page 12 Step 7 Adjust the tilting angle with spring loaded handle: Hold the TV and adjust it to your desired position, and fasten the handle and the bolt opposite to the handle. Handle Bolt To fasten the handle: Push Pull Step A Step B Step C Step D...

  • Page 13: Product Dimensions

    Step 8 Manage TV cables orderly and tie them with velcro cable ties. Product dimensions: 671mm MAX:600mm 430mm +5° MAX: 400mm -15° 372mm 62mm +45°/-45° If you have any questions about the installation,please feel free to contact us at telephone (626) 604-9048 (USA) Mon - Fri 10am - 6pm (Pacific time) or email us by customerservice@mountingdream.com .
