Service Manual
Drum Washing Machine
Model: DWD-L1212
✔
Caution
: In this Manual, some parts can be changed for improving, their
performance without notice in the parts list. So, if you need the
latest parts information, please refer to PPL(Parts Price List) in
Service Information Center (http://svc.dwe.co.kr).
S/M No. :
Oct. 2009

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DWD-L1212 and is the answer not in the manual?

Questions and answers

Related Manuals for DAEWOO ELECTRONICS DWD-L1212

Summary of Contents for DAEWOO ELECTRONICS DWD-L1212

  • Page 1 S/M No. : Service Manual Drum Washing Machine Model: DWD-L1212 ✔ Caution : In this Manual, some parts can be changed for improving, their performance without notice in the parts list. So, if you need the latest parts information, please refer to PPL(Parts Price List) in Service Information Center (http://svc.dwe.co.kr).

  • Page 2: Washer Specification

    2. WASHER SpECIfICATIoN 1. Product Specification ■ 1st Model ■ 2st Model MODEL DWC-LU1011/1211 DWD-L1212 Dimension (mm) 600 X 645 X 850 Maximum mass of textile (kg) 9 Kg Unit Weight (net/gross) 78/82 71/75 Standard Water Consumption 65 ℓ DWC(DWD)-LU10XX : MAX 1000...

  • Page 3: Parts List By Ass'y

    3. pARTS LIST by ASS'y 1. pANEl AS ■ 1st Model...

  • Page 4: Parts Name

    PARTS NAME CODE SPECIFICATIONS Q’TY REMARK A01 pANEl *f 36142T2000 A02 DECoRAToR WINDoW CoURSE 3611696000 A03 WINDoW CoURSE 3615509200 C-LU1011 A04 DECoRAToR WINDoW DISplAy 3611696100 A05 bUTToN fUNCTIoN 3616644000 A06 bUTToN pS 3616644100 A07 WINDoW DISplAy 3615509300 C-LU1011 A08 bUTToN lED 3616644200 C-LU1011 A09 pCb boARD...
  • Page 5 3. INlET boX AS...
  • Page 6 PARTS NAME CODE SPECIFICATIONS Q’TY REMARK NoZZlE *T 3618111100 NoZZlE *U 3618111000 boX INlET 3610526500 HoSE INlET 3613274600 EpDM ClAMp AS 3611203200 ID=60, WIRE+GUIDE+bolT+NUT VAlVE INlET 3615416820 220-240V.VDE.BITRON. 3613268900 HoSE WATER SUpply EpDM ID9.5 oD14.5, WASHING 3613268900 HoSE WATER SUpply EpDM ID9.5 oD14.5, pRE.WASH ClAMp HoSE 3611205800...
  • Page 7 4. CAbINET f ASSy ■ 1st Model...
  • Page 8 PARTS NAME CODE SPECIFICATIONS Q’TY REMARK CAbINET *f 3610814000 SECD 0.8T SWITCH DooR loCK 3619047200 DL-S1.250V16A.BITRON plATE HINGE SUppoRT 3614539800 SPG 0.8T, DWD-T110R fRAME DooR *o 36122UD800 DOOR AS: 36117ACE01 pRoTECToR GlASS 3618345500 PUERTA COMPLETA DECoRAToR DooR *o 3611695900 HooK DooR 3613100900 ZNDC SpRING HooK...
  • Page 9 6. TUb ASSy(UNIVERSAl)
  • Page 10 PARTS NAME CODE SPECIFICATIONS Q’TY REMARK bAlANCER WEIGHT l 3616110600 PP, D-LU1011, 6.6KG NO DISPON PARA ESTRE MODELO SpECIAl SCREW 3616029400 SWCH 8.5X30 NO DISPON PARA ESTRE MODELO bAlANCER WEIGHT R 3616110500 PP, D-LU1011, 6.6KG NO DISPON PARA ESTRE MODELO 3611207000 ClAMp GASKET AS C-LU1011...
  • Page 11 9. CAbINET AS...

  • Page 12: Frame Lower

    PARTS NAME CODE SPECIFICATIONS Q’TY REMARK CAbINET 3610813300 SGCC 0.8T,l'S NO DISPONIBLE NO DISPONIBLE fRAME loWER 36122UD700 SGCC 1.2T NO DISPONIBLE fRAME Top *l 36122UDA00 SGCC 1.6T NO DISPONIBLE fRAME Top *R 36122UDb00 SGCC 1.6T NO DISPONIBLE bASE U l 3610393800 SGCC T2.0 bASE U R...

  • Page 13: Test Mode

    5. TEST MoDE 5-1. Testing Mode PCB and other electronic parts will be tested without water supply whether they are normal or not. 1) Process Press power button → Press "SPIN" button 3 times with pressing "OPTION" button → 'L d' will be shown on LED →...
  • Page 14 6-1. Error Display 6-1. IE (Input Error) - Error in water supply 1) Conditions of Occurrence ① In case the designated water level is not reached in 5 minutes during water supply or re-supply 2) All LEDs are turned off and 'IE' blinks in18:88 display. 3) Error buzzer alarm is sounded for 10 seconds per every 10 minutes.
  • Page 15 6-4. LE (Lock Error) - Door opening error 1) Conditions of Occurrence ① When intending to begin cycle by pressing start/ temporary stop button while door is opened 2) All LEDs are turned off and 'LE' blinks in 18:88 display. 3) Error buzzer alarm is sounded for 10 seconds per every 10 minutes.
  • Page 16 6-7. E4 - Water leakage during washing 1) Conditions of Occurrence ① In case water level falls below re-supply even after 15 times of re-supply prior to finishing of water heating 2) All LEDs are turned off and 'E4' blinks in 18:88 display. 3) Error buzzer alarm is sounded for 10 seconds per every 10 minutes.
  • Page 17 6-9. Motor-related Error 1) E5 (DC-Link High Voltage) Error ① In case DC-link voltage to IPM increases to 450V or higher ② Motor operation is stopped and 'E5' is shown in display window. ③ Error buzzer alarm is sounded for 10 seconds per every 10 minutes. ④...
  • Page 18 3) H5 Error - Water temperature error in wool/ delicate course ① In case water temperature in wool/ delicate course is 45℃ or higher ② Error buzzer alarm is sounded for 10 seconds per every 10 minutes. ③ Error display is cleared when turning off/ on power. 4) H6 Error - Abnormality in washing heater ①...
  • Page 19 ■ DWD-LU'S...
