Washing Machine Instruction Manual
INSTRUCTION MANUAL
Economic washing system
The washing machine determines the water level and washing time
automatically by sensing the amount of laundry and water
temperature in order to minimize energy and water consumption.
Low noise system
The washing machine minimizes the spinning noise level by sensing
the amount of unbalance of laundry.
Nano-silver sterilization washing(Option)
By applying very fine silver particles on essential parts inside, the
washer sterilizes up to 99.9% as is done by boiling wash.
Air bubble washing(Option)
This is an advanced technology that generates millions of air bubbles
inside the drum on washing sequence, and the bubbles dissolve the detergent particles completely and
cleanse all the soil in clothes gently and neatly.
CONTENTS
WASHER SAFETY ..........................................................................................................................2
PARTS AND FEATURES ................................................................................................................4
INSTALLATION INSTRUCTIONS ...................................................................................................5
ELECTRICAL REQUIREMENTS ....................................................................................................7
OPERATING YOUR WASHER .......................................................................................................7
THE FUNCTIONS OF THE CONTROL PANEL ..............................................................................9
PROGRAMS AND FUNCTIONS ...................................................................................................10
WASHING PROCEDURE AND PROGRAM SELECTION ............................................................11
PRODUCT INFORMATION ...........................................................................................................13
MAINTENANCE ............................................................................................................................14
HOW TO CLEAN THE FILTER .....................................................................................................15
REMOVING STAINS .....................................................................................................................16
TROUBLE SHOOTING .................................................................................................................17
SPECIFICATION ...........................................................................................................................18
A NOTE TO YOU
Thank you for buying a DAEWOO appliance.
DAEWOO washers are easy to use, save time, and help you manage your home better.
This manual contains valuable information about how to operate and maintain your washer properly and safely.
Please read it carefully.
DWD-NT122'S
Page
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for DAEWOO ELECTRONICS DWD-NT122'S
Summary of Contents for DAEWOO ELECTRONICS DWD-NT122'S
-
Page 1: Table Of Contents
Washing Machine Instruction Manual DWD-NT122'S INSTRUCTION MANUAL Economic washing system The washing machine determines the water level and washing time automatically by sensing the amount of laundry and water temperature in order to minimize energy and water consumption. Low noise system The washing machine minimizes the spinning noise level by sensing the amount of unbalance of laundry. -
Page 2: Washer Safety
WASHER SAFETY Save these instructions Your safety is important to us. To reduce the risk of fire, electrical shock, or injury when using your washer adhere to the following basic precautions. Read all instructions before using your washer • Flammable fluids (dry-cleaning solvents, kerosene, gasoline, etc.) should not be used or stored in or near your washer. - Page 3 WASHER SAFETY Understanding your responsibilities • Do not use chlorine bleach and ammonia or acid(such as vinegar or rust remover) in the same wash. Hazardous fumes can form. • Unplug power supply cord before attempting to service your washer. • Do not wash fiberglass material. Small particles can stick to fabrics washed in following loads and cause skin irritation.
-
Page 4: Parts And Features
PARTS AND FEATURES The parts and features of your washer are illustrated on the page. Become familiar with all parts and features before using your washer. NOTE The drawings in the book may vary from your washer model. They are designed to show the different features of all models coverd by this book. Your model may not include all features. -
Page 5: Installation Instructions
INSTALLATION INSTRUCTIONS Removing transit bolts 1. Before operating the washer, remove the transit bolts(3ea) along with the rubber. • If the bolts are not removed, it may cause heavy vibration, noise and malfunction. 2. Unscrew the 3 bolts with the 10mm hex wrench or spanner or cross-tip screwdriver. - Page 6 Drain system • Never forget to install drain hose before operating your washer. • Open the packing box, and the drain hose is tied at backside of washer. • If you use the laundry tub, Top of laundry tub must be at least 60cm high and no higher than 100cm from bottom of washer.
-
Page 7: Electrical Requirements
ELECTRICAL REQUIREMENTS Electrical shock hazard : Failure to follow these instructions could result in death WARNING or serious injury. • Electrical earth is required on this washer. • Don’t earth to a gas pipe. • If it does not fit the outlet, have a proper outlet •... - Page 8 Sorting • Separate heavily soiled items from lightly soiled ones, even if they would normally be washed together. • Separate dark colors from light colors, colorfast items from non-colorfast item. Soil (Heavy, Normal, Light) Separate clothes according to amount of soil. Color (White, Lights, Darks) Separate white clothes from colored clothes.
-
Page 9: The Functions Of The Control Panel
THE FUNCTIONS OF THE CONTROL PANEL Program selector Indicator light The respective indicator lights up, when the For switching the washing machine on and off and for selecting the program. required program segment runs. Can be rotated in both direction. Time delay Even if the program selector rotates while the To pre-engage time for washing. -
Page 10: Programs And Functions
PROGRAMS AND FUNCTIONS Programs and functions Proper Degree Max. Program Fabric type Option Remark Temp. of soiling Load Colorfast garments Lightly Rinse+ Rating First Check if Cold (shirts, night dresses, soiled Rinse Hold laundry is 40°C pajamas...) and lightly Super washable. -
Page 11: Washing Procedure And Program Selection
Rinse : Rinse cycle with subsequent spin cycle for rinsing hand-washed items. Spin : Spin cycle after a program with setting ‘Rinse Hold’ is finished or for spinning hand-washed washing. Washing and rinsing water is drained before the spin cycle. Drain : Water is drained after program with setting ‘Rinse Hold’... - Page 12 Changing the program If you have accidentally selected the wrong program, follows next procedure. • Turn the program selector to OFF and reselect the desired program by using the program selector. • Press the Start/Hold button. The selected program stops and the indicator light of Start/Hold button is not twinkle but on.
-
Page 13: Product Information
PRODUCT INFORMATION Most efficient programs for cotton laundry The following programme are suitable for cleaning normally soiled cotton texiles and are the most efficient with respect to combined energy and water consumption. Program Load (kg) Energy (kWh) Water (L) RMC (%) Duration (min) 0.97 52.2 60˚C... -
Page 14: Maintenance
MAINTENANCE Proper care of your washer can extend its life. This section explains how to care for your washer properly and safely. Cleaning your washer Exterior Interior Wipe up detergent, bleach, and other spills Clean interior with 250ml of chlorine bleach with a soft, damp cloth or sponge as they mixed with 500ml of detergent. -
Page 15: How To Clean The Filter
HOW TO CLEAN THE FILTER Cleaning the water inlet filter • Clean the filter when water leaks from the water inlet. 1 Turn off the water 2 Separate the inlet 3 Pull out the inlet filter. 4 Connect the inlet tap. -
Page 16: Removing Stains
REMOVING STAINS Stained, heavily-soiled, or greasy items may need to be prewashed or soaked for best results. Soaking helps remove protein-type stains like blood, milk or grass. Prewashing helps loosen soil before washing. Stain removal rules • Use warm water for soaking or prewashing stained laundry. Hot water can set stains. •... -
Page 17: Trouble Shooting
TROUBLE SHOOTING Most problems are easily solved if you understand the cause. Check the following list for problem before calling for service. Problem Cause Solution Plug is loose or not plugged in. Insert plug tightly. Program dose not Power failure. An interrupted program will be resumed when the start. -
Page 18: Specification
SPECIFICATION MODEL DWD-NT122'S Power Source A.C 220-240V/50Hz Power Consumption 2000 W Dimension (mm) NET : 595X465X850 (WXDXH) Maximum mass of textile (kg) 7 kg Unit Weight (kg) 55(NET) / 58(GROSS) Standard Water Consumption Spin Speed(RPM) 400 / 600 / 800 / 1000 / 1200 Operating Water Pressure 0.05MPA ~ 0.8MPa (0.5kgf/cm... - Page 19 Designing Excellence PRODUCT FICHE Supplier : DONGBU DAEWOO ELECTRONICS Model : DWD-NT122'S Capacity : 7,0 kg Energy efficiency class : A++ Energy consumption 181 kWh per year, based on 220 standard washing cycles for cotton programmes at 60 °C and 40 °C at full and partial load, and the consumption of the low-power modes.
- Page 20 English Português Disposal of Used Electrical & Electronic Equipment Eliminação de Equipamento Eléctrico e Electrónico Usado The meaning of the symbol on the product, its accessory or packaging indicates that this product shall O símbolo no aparelho, nos seus acessórios ou na embalagem indica que este aparelho não deve ser not be treated as household waste.
- Page 21 » » esky Italiano Trattamento del dispositivo elettrico od Likvidace pouû û it˝ ˝ ch elektrick˝ ˝ ch a elektronick˝ ˝ ch za¯ ¯ ízení elettronico a fine vita (Applicabile in tutti i paesi Tento symbol na v˝robku, jeho p¯ísluöenství nebo obalu dell’Unione Europea e in quelli con sistema di oznaËuje, ûe s tímto v˝robkem nesmí...
- Page 22 Svenska Dansk Omhändertagande av gamla elektriska och Håndtering af udtjente elektriske og elektroniske elektroniska produkter (Användbar i den produkter (Gælder for den Europæiske Union og Europeiska Unionen och andra Europeiska andre europæiske lande med separate länder med separata insamlingssystem) indsamlingssystemer) Symbolen på...
