Washing Machine Instruction Manual
INSTRUCTION MANUAL
Economic wash system
Using artificial intelligence, the washer uses minimum energy and water by
selecting optimal water level and washing time.
Low noise system
The washer minimizes the washing and spinning noises by sensing the
amount of laundry and balancing the load before the spin.
Child-Lock
The Child-Lock system is used to prevent children from pressing any buttons
to change the program during operation.
CONTENTS
WASHER SAFETY...........................................................................................................................2
PARTS AND FEATURES.................................................................................................................4
INSTALLATION INSTRUCTIONS ....................................................................................................5
INLET HOSE CONNECTION ...........................................................................................................6
ELECTRICAL REQUIREMENTS .....................................................................................................7
OPERATING YOUR WASHER ........................................................................................................8
THE FUNCTIONS OF THE CONTROL PANEL.............................................................................10
WASHING PROCEDURE AND PROGRAM SELECTION.............................................................11
PRODUCT INFORMATION ...........................................................................................................25
MAINTENANCE ............................................................................................................................26
HOW TO CLEAN THE FILTER ......................................................................................................27
REMOVING STAINS ......................................................................................................................28
TROUBLE SHOOTING ..................................................................................................................29
SPECIFICATION & WIRING DIAGRAM ........................................................................................30
A NOTE TO YOU
Thank you for buying a DAEWOO appliance.
DAEWOO washers are easy to use, save time, and help you manage your home better.
This manual contains valuable information about how to operate and maintain your washer properly and safely.
Please read it carefully.
Spare Parts : 0844 557 0270 or www.4daewoo.co.uk / DAEWOO ELECTRONICS Web Site www.daewooelectronics.co.uk
DWDHQ1421D
Customer Helpline Number : 01189252577
Page
Advertisement
Table of Contents
Related Manuals for DAEWOO ELECTRONICS DWDHQ1421D
Summary of Contents for DAEWOO ELECTRONICS DWDHQ1421D
-
Page 1: Table Of Contents
DAEWOO washers are easy to use, save time, and help you manage your home better. This manual contains valuable information about how to operate and maintain your washer properly and safely. Please read it carefully. Customer Helpline Number : 01189252577 Spare Parts : 0844 557 0270 or www.4daewoo.co.uk / DAEWOO ELECTRONICS Web Site www.daewooelectronics.co.uk... -
Page 2: Washer Safety
WASHER SAFETY Save these instructions Your safety is important to us. To reduce the risk of fire, electrical shock, or injury when using your washer, adhere to the following basic precautions. Read all instructions before using your washer • Flammable fluids (dry-cleaning solvents, kerosene, gasoline, etc.) should not be used or stored in or near your washer. - Page 3 WASHER SAFETY Understanding your responsibilities • Do not use chlorine bleach and ammonia or acid(such as vinegar or rust remover) in the same wash. Hazardous fumes can form. • Unplug power supply cord before attempting to service your washer. • Do not wash fiberglass material. Small particles can stick to fabrics washed in following loads and cause skin irritation.
-
Page 4: Parts And Features
PARTS AND FEATURES The parts and features of your washer are illustrated on this page. Become familiar with all parts and features before using your washer. NOTE The drawings in the book may vary from your washer model. They are designed to show the different features of all models covered by this book, Your model may not include all features. -
Page 5: Installation Instructions
INSTALLATION INSTRUCTIONS Removing transit bolts 1. Before operating the washer, remove the 2. Unscrew the 3 bolts with a 10mm hex transit bolts(x3) along with the rubber around wrench or spanner or cross-tip screwdriver. them. Do not discard the bolts. •... -
Page 6: Inlet Hose Connection
INLET HOSE CONNECTION The washer should be connected to the water mains using new hose sets, old hose sets should not be reused. If in using only one water tap or in case of only one water inlet valve, connect the inlet hose to the cold water inlet valve. -
Page 7: Electrical Requirements
ELECTRICAL REQUIREMENTS Electrical shock hazard : Failure to follow these instructions could result in WARNING death or serious injury. • Electrical earth is required on this washer. • Don't earth to a gas pipe. • If it does not fit the outlet, have a proper outlet •... -
Page 8: Operating Your Washer
2 Adjust the level of washer. • Adjust the level of washer by turning the adjustable legs. • Please check if there is any gap between the four adjustable legs and the floor. Fixing Nut • After the adjustment is finished, turn the adjustable leg fixing nuts up tightly so that the washer maintains the adjustment. - Page 9 Sorting • Separate heavily soiled items from lightly soiled ones, even if they would normally be washed together. • Separate dark colours from light colours, colourfast items from non-colourfast item. Soil (Heavy, Normal, Light) Separate clothes according to amount of soiling. Colour (White, Lights, Darks) Separate white clothes from coloured clothes.
-
Page 10: The Functions Of The Control Panel
THE FUNCTIONS OF THE CONTROL PANEL Press this switch to turn the power on or off. Operation and temporary stop is repeated as it is pressed. When you want to change program in operation; Press the ‘Start/Pause’ button Select the program that you want to change Press the ‘Start/Pause’... -
Page 11: Washing Procedure And Program Selection
WASHING PROCEDURE AND PROGRAM SELECTION 1. COTTON IS AUTOMATICALLY SELECTED UPON POWER ON • Press the Power button to start. • Press the Start/Pause button. • Initial condition. - Program : Cotton - Wash : main wash - Rinse : 3 times - Spin : 800 rpm - Water temperature : 40˚C 2. - Page 12 4. FUNCTION • Recommended programs according to the laundry type. Fabirc Proper Maximum Program Option Detergent Type Temp. Load First check if laundry is machine Cotton 60°C (95°C) Pre-Wash Standard detergent Rating washable.(white cotton, linen towel Rinse+ containing bleach and and sheets, ...) Water+ optical brighteners...
- Page 13 * COTTON PROGRAM Put the laundry in the drum, and close the door. • Put detergent into the main wash and prewash (if applicable) compartments in the detergent case. Softener should be below the MAX level. • Put detergent into the prewash compartment only if you want to add Pre-Wash option.
- Page 14 * COLOUR PROGRAM Put the laundry in the drum. Put detergent and softener into the detergent case. Then close the door. • Put detergent into the main wash compartment in the detergent case. Softener should be below the ‘MAX’ level. •...
- Page 15 * INTENSIVE PROGRAM Put the laundry in the drum and close the door. • Put detergent into the main wash compartment in the detergent case. Softener should be below the ‘MAX’ level. • When you want to use bleach, put it into the main wash compartment with detergent.
- Page 16 * COTTON ECO PROGRAM Put the laundry in the drum and close the door. • Put detergent into the main wash compartment in the detergent case. Softener should be below the ‘MAX’ level. • When you want to use bleach, put it into the main wash compartment with detergent.
- Page 17 * BABY CARE PROGRAM Put the laundry in the drum and close the door. • Put detergent into the main wash and prewash compartments in the detergent case. Softener should be below the ‘MAX’ level. • Put detergent into the prewash compartment only if you want to add Pre-Wash option.
- Page 18 * TUB CLEAN PROGRAM Put 250ml of chlorine bleach mixed with 500ml of detergnet into the detergent case. Then close the door. Press the Power button. • The LED shows only '---' and all Program Lights turn on. Select the ‘Tub Clean’ program using program selection dial. •...
- Page 19 * SPORTS WEAR PROGRAM Put the laundry in the drum and close the door. • Put detergent into the main wash compartment in the detergent case. Softener should be below the ‘MAX’ level. • When you want to use bleach, put it into the main wash compartment with detergent.
- Page 20 * SPEED WASH PROGRAM Put the laundry in the drum, and colse the door. • Put detergent into the main wash compartment in the detergent case. Softener should be below the ‘MAX’ level. • When you want to use bleach, put it into the main wash compartment with detergent.
- Page 21 * WOOL PROGRAM Put the laundry in the drum, and colse the door. • Put detergent into the main wash compartment in the detergent case. Softener should be below the ‘MAX’ level. • When you want to use bleach, put it into the main wash compartment with detergent.
- Page 22 * SYNTHETIC PROGRAM Put the laundry in the drum, and colse the door. • Put detergent into the main wash and prewash compartments in the detergent case. Softener should be below the ‘MAX’ level. • Put detergent into the prewash compartment only if you want to add Pre-Wash option.
- Page 23 * ECO SHOWER PROGRAM Put the laundry in the drum, and colse the door. • Put detergent into the main wash compartment in the detergent case. Softener should be below the ‘MAX’ level. • When you want to use bleach, put it into the main wash compartment with detergent.
- Page 24 * RINSE + SPIN Press the Power button. • The LED shows only '---' and all Program Lights turn on. Select the ‘Rinse + spin’ program using program selection dial. • Spin '800' rpm and rinse '1' times are selected automatically. •...
-
Page 25: Product Information
PRODUCT INFORMATION Most efficient programs for cotton laundry The following programme are suitable for cleaning normally soiled cotton texiles and are the most efficient with respect to combined energy and water consumption. Program Load (kg) Energy (kWh) Water (L) RMC (%) Duration (min) 1.07 53.5 60˚C... -
Page 26: Maintenance
MAINTENANCE Proper care of your washer will extend its life. This section explains how to care for your washer properly and safely. Cleaning your washer Exterior Interior Wipe up detergent, bleach, and other spills with Clean interior with 250ml of chlorine bleach a soft, damp cloth or sponge as they occur. -
Page 27: How To Clean The Filter
HOW TO CLEAN THE FILTER Cleaning the water inlet filter • Clean the filter if water leaks from the water inlet. 1 Pull the power 2 Turn off the water 3 Pull the inlet filter 4 Remove the dirt plug out before supply to the out. -
Page 28: Removing Stains
REMOVING STAINS Stained, heavily-soiled, or greasy items may need to be prewashed or soaked for best results. Soaking helps remove protein-type stains like blood, milk or grass. Prewashing helps loosen dirt before washing. Stain removal rules • Use warm water for soaking or prewashing stained laundry. Hot water can set stains. •... -
Page 29: Trouble Shooting
TROUBLE SHOOTING Most problems are easily solved if you understand the cause. Check the following list for problem before calling for service. If an error code such as IE, OE, UE is displayed on the control panel, first try turning off the power of the washing machine and then turn back on Power button. -
Page 30: Specification & Wiring Diagram
SPECIFICATION MODEL DWDHQ1421D Dimension (mm) 595 X 634 X 850 (W X D X H) Wash Capacity (kg) Unit Weight (kg) 62(Net) / 65(Gross) Standard Water Consumption Spin Speed (RPM) 400/800/1000/1400 Operating Water Pressure 0.05MPa ~ 0.8MPa (0.5kgf/cm ~ 8kgf/cm... - Page 31 Designing Excellence PRODUCT FICHE Supplier : DONGBU DAEWOO ELECTRONICS Model : DWDHQ1421D Capacity : 9.0 kg Energy efficiency class : A+++ Energy consumption 208 kWh per year, based on 220 standard washing cycles for cotton programmes at 60 °C and 40 °C at full and partial load, and the consumption of the low-power modes.
- Page 32 English Português Disposal of Used Electrical & Electronic Equipment Eliminação de Equipamento Eléctrico e Electrónico Usado The meaning of the symbol on the product, its accessory or packaging indicates that this product shall O símbolo no aparelho, nos seus acessórios ou na embalagem indica que este aparelho não deve ser not be treated as household waste.
- Page 33 » » esky Italiano Trattamento del dispositivo elettrico od Likvidace pouû û it˝ ˝ ch elektrick˝ ˝ ch a elektronick˝ ˝ ch za¯ ¯ ízení elettronico a fine vita (Applicabile in tutti i paesi Tento symbol na v˝robku, jeho p¯ísluöenství nebo obalu dell’Unione Europea e in quelli con sistema di oznaËuje, ûe s tímto v˝robkem nesmí...
- Page 34 Svenska Dansk Omhändertagande av gamla elektriska och Håndtering af udtjente elektriske og elektroniske elektroniska produkter (Användbar i den produkter (Gælder for den Europæiske Union og Europeiska Unionen och andra Europeiska andre europæiske lande med separate länder med separata insamlingssystem) indsamlingssystemer) Symbolen på...
