INSTRUCTIONS FOR USE & MAINTENANCE MANUAL
Barbas wishes you many cosy evenings with your new appliance
This document is an essential part of your appliance.
Read it carefully before use of the appliance and keep it in a safe place!
Version number: 04 - 340650
Date: 07-05-2019
UNILUX-6 40
Wood-burning
appliance
Serial number:
Production date:

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the UNILUX-6 40 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for barbas UNILUX-6 40

Summary of Contents for barbas UNILUX-6 40

  • Page 1 UNILUX-6 40 Wood-burning appliance Barbas wishes you many cosy evenings with your new appliance This document is an essential part of your appliance. Read it carefully before use of the appliance and keep it in a safe place! Version number: 04 - 340650...
  • Page 3 Name, registered trade name or registered trade mark Barbas Bellfires BV; Hallenstraat 17; 5531 AB Bladel; The Netherlands and contact address of the manufacturer as required pursuant to Article 11(5)
  • Page 4 UNILUX-6 40 Instructions for use...

  • Page 5: Table Of Contents

    UNILUX-6 40 CONTENTS Page 1. INTRODUCTION ..................2. SAFETY ...................... 3. OPERATION ....................4. USING THE APPLIANCE FOR THE FIRST TIME ........5. USE ......................6. FUEL ......................7. MAINTENANCE ..................8. FREQUENTLY ASKED QUESTIONS ............9. TECHNICAL DATA ..................
  • Page 6 UNILUX-6 40 Instructions for use...

  • Page 7: Introduction

    UNILUX-6 40 INTRODUCTION Congratulations on your purchase of this modern Barbas appliance. This quality product will provide you with many years of enjoyment due to the fl ame effect and warmth that it provides. This appliance is exempted or recommended for exemption under section 21 of the Clean Air Act 1993 and can be used in accordance with the intended use as described in this manual in smoke control areas in the UK.

  • Page 8: Safety

    Ensure that the room in which the appliance is situated has adequate ventilation. It is essential that the appliance, the fl ue and combustion air supply are cleaned and inspected annually by a Barbas dealer/specialist. The safe operation of the appliance will thus remain guaranteed. Instructions for use...
  • Page 9 UNILUX-6 40 The appliance must never be used with the door open or the door glass removed. Wood and wood briquettes may be stoked in the appliance. Coals can’t be burned in the appliance. Avoid over-loading (white burning glow), caused, for example, by lengthy burning with a fully open primary air vent (combustion air supply slider all the way to “...

  • Page 10: Operation

    UNILUX-6 40 OPERATION Handle Ceramic heat-proof glass Outlet opening (2x grate) (chimney breast) ventilation air chimney breast Grate Ashtray Inlet opening (2x grate)(chimney breast) ventilation air chimney breast Combustion air-supply slider (Combined operation for the primary, secondary and tertiary combustion air-supply)

  • Page 11: Using The Appliance For The First Time

    UNILUX-6 40 USING THE APPLIANCE FOR THE FIRST TIME GENERAL Allow your home to dry properly, after you have had your chimney breast modifi ed or newly built. Walls which have not been allowed to dry properly are a magnet for dust such as any smoke particles created when stoking up the appliance or suddenly opening the door.
  • Page 12 UNILUX-6 40 4.3 INSPECTION OF THE APPLIANCE BEFORE FIRST USE Check all available functions before using the appliance for the fi rst time. • Check the opening and closing operation of the door. Turn the handle all the way down: Door is locked.
  • Page 13 UNILUX-6 40 • Check whether the 2 baffl e plates are located correctly in the supports. • Check the operation of the slider for the regulation of the combustion air intake (middle below the window). • Check whether the ashtray is completely empty.

  • Page 14: Use

    UNILUX-6 40 5.1 VENTILATION If wood is to burn, it needs air. For each kilo of wood that you put on the appliance (door closed), 10 - 15 m of extra air is needed. That means about 35 m per hour! Depending on how the appliance has been installed, the combustion air will either be drawn directly from outside or from the living room itself.
  • Page 15 UNILUX-6 40 5.2.2 Burning coal or briquetted smokeless fuels *) Load the appliance with approx. 2 kg of coal or smokeless fuel briquettes, together with a suitable fi restarter (e.g. wood kindlings) and light it with a small fi re starter block and close the door.
  • Page 16 UNILUX-6 40 Control range of primary air supply (by grate) Control range of secondary and tertiary air supply Combustion air supply slider Centre position We recommend that you maintain a substantial layer of ash (2 - 3 cm). This not only forms a protective layer for the base of the appliance but also signifi...
  • Page 17 UNILUX-6 40 Smoke development Your appliance has been designed to be used with the load/observation door closed. Should you use it with the door open, under certain circumstances (presence of mechanical ventilation, draught, differences in barometric pressure) smoke may enter the room in which the appliance is situated.
  • Page 18 UNILUX-6 40 Your appliance is at its most economical when: • Using dry and clean wood (as described further in Chapter 6). • Always ensure even combustion. Stoke with the primary air regulator closed. To do this, place the combustion air supply slider in the centre position.
  • Page 19 UNILUX-6 40 GENERAL HEATING TIPS • Burn dry wood only. Damp wood not only burns poorly, it causes more pollution in the appliance (window), the chimney, your room (when opening the door of the appliance, for instance) and the environment. Wood can only be classifi ed as dry if it has been stored under a Dutch barn for at least two years (not covered with plastic).
  • Page 20 UNILUX-6 40 OUTPUT In practice, combustion is all about loss. This entails: • Loss through excess heat leaving the chimney, rather than going into the room. • Loss through insuffi cient combustion, such as CO (carbon monoxide) and soot particles.

  • Page 21: Fuel

    UNILUX-6 40 FUEL The appliance has been recommended as suitable for use in smoke control areas when burning clean wood logs as stated hereunder. All suitable fuels listed hereunder can be used outside smoke control areas. WOOD Suitable fuels are: •...
  • Page 22 If this happens, there is a risk of fi re. It may also damage your appliance and chimney. BARBAS will not assume liability for damage caused by overheating. Burning one layer of wood can lead to varying outputs. When used correctly, one load will burn in around 45 minutes.

  • Page 23: Maintenance

    * Replace panels as necessary • Grate Check annually for cracks / breakage • Sliders/dampers Check function annually • Paint Check annually, if necessary touch up with BARBAS heat-resistant paint (do not paint when the appliance is in use!) Instructions for use...
  • Page 24 UNILUX-6 40 • Parts Individual parts for replacement/accessories are available from your BARBAS dealer Use only original parts • Modifi cations Introduced modifi cations to the appliance are not permitted • House Ensure that as little dust, and as few particles of...

  • Page 25: Frequently Asked Questions

    UNILUX-6 40 FREQUENTLY ASKED QUESTIONS How often should I have my chimney swept? At least once a year. If you use your appliance more than three times a week on average, have your chimney swept more often. Have the chimney swept by a recognised company.
  • Page 26 Can a wood-burning appliance/fi replace insert be connected to a central heating installation? The Barbas range does not have any appliances that can be connected to central heating installations. We do not advise attempting it!! How do I know if I’m heating correctly? Follow the instructions in this manual.
  • Page 27 UNILUX-6 40 Can I leave my appliance unattended? Only do this when the appliance is burning quietly, with just a little wood, with a closed door and with the combustion air supply slider in the centre position between “ + ” and “...
  • Page 28 UNILUX-6 40 Decomposition At moderate - high temperatures (150°C - 350°C), the decomposition process can be discerned. This is when the chemical structure of the fuel breaks down. This process involves the creation of volatile compounds such as carbon monoxide (CO), water...

  • Page 29: Technical Data

    UNILUX-6 40 TECHNICAL DATA Combustion: Measured in compliance with EN 13229 : 2001 and EN 13229 - A2 : 2004 Fuel Wood Nominal output 5 kW Effi ciency Emissions (dry, at 13% O , 273 K, 1013 hPa): Carbon monoxide (CO) 0.09%;...

  • Page 30: Warranty Terms

    1.1. If Barbas Bellfi res B.V. determines that the Barbas appliance you have purchased is defective as a result of a fl aw in the construction or material, Barbas Bellfi res B.V. guarantees to repair or replace the appliance free of charge, without charging any costs for labour or spare parts.
  • Page 31 Article 5: Warranty period 5.1. This warranty will only be granted during the warranty period. 5.2. The body of the Barbas appliance is guaranteed for a period of 10 years against construction and/or material faults, starting from the moment of purchase.
  • Page 32 Your Barbas dealer 04 - 070519 - 340650...
