INSTRUCTIONS FOR USE & MAINTENANCE MANUAL
Barbas wishes you many cosy evenings with your new appliance
This document is an essential part of your appliance.
Read it carefully before use of the appliance and keep it in a safe place!
Version number: 01 - 340184
Date: 01-05-2015
UNILUX-6 65
Wood-burning appliance
Serial number:
Production date:

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the UNILUX-6 65 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for barbas UNILUX-6 65

Summary of Contents for barbas UNILUX-6 65

  • Page 1 INSTRUCTIONS FOR USE & MAINTENANCE MANUAL UNILUX-6 65 Wood-burning appliance Barbas wishes you many cosy evenings with your new appliance This document is an essential part of your appliance. Read it carefully before use of the appliance and keep it in a safe place!
  • Page 3 UNILUX-6 65 Instructions for use...
  • Page 4 UNILUX-6 65 Instructions for use...

  • Page 5: Table Of Contents

    UNILUX-6 65 CONTENTS Page 1. INTRODUCTION ..................2. SAFETY ...................... 3. OPERATION ....................4. USING THE APPLIANCE FOR THE FIRST TIME ........5. USE ......................6. FUEL ......................7. MAINTENANCE ..................8. FREQUENTLY ASKED QUESTIONS ............9. TECHNICAL DATA ..................
  • Page 6 UNILUX-6 65 Instructions for use...

  • Page 7: Introduction

    UNILUX-6 65 INTRODUCTION Congratulations on your purchase of this modern Barbas appliance. This quality product will provide you with many years of enjoyment due to the fl ame effect and warmth that it provides. Study this manual carefully before using the fi replace. We recommend you keep this manual in a safe place for reference purposes.
  • Page 8 It is essential that the appliance, the fl ue and combustion air supply are cleaned and inspected annually by a Barbas dealer/specialist. The safe operation of the appliance will thus remain guaranteed. The appliance must never be used with the door open or the door glass removed.

  • Page 9: Operation

    UNILUX-6 65 OPERATION Handle Ceramic heat-proof glass Convection air outlet opening (appliance) *) Outlet opening (2x grate) (chimney breast) ventilation air chimney breast Outlet opening (2x grill convection set) (chimney breast) convection air *) Grate Ashtray Inlet opening (2x grate)(chimney breast) ventilation air chimney breast...

  • Page 10: Using The Appliance For The First Time

    UNILUX-6 65 USING THE APPLIANCE FOR THE FIRST TIME GENERAL Allow your home to dry properly, after you have had your chimney breast modifi ed or newly built. Walls which have not been allowed to dry properly are a magnet for dust such as any smoke particles created when stoking up the appliance or suddenly opening the door.
  • Page 11 UNILUX-6 65 4.3 INSPECTION OF THE APPLIANCE BEFORE FIRST USE Check all available functions before using the appliance for the fi rst time. • Check the opening and closing operation of the door. Turn the handle all the way down: Door is locked.
  • Page 12 UNILUX-6 65 • Check whether the 2 baffl e plates are located correctly in the supports. • Check the operation of the slider for the regulation of the combustion air intake (middle below the window). • Check whether the ashtray is completely empty.

  • Page 13: Use

    UNILUX-6 65 5.1 VENTILATION If wood is to burn, it needs air. For each kilo of wood that you put on the appliance (door closed), 10 - 15 m of extra air is needed. That means about 35 m per hour! Depending on how the appliance has been installed, the combustion air will either be drawn directly from outside or from the living room itself.
  • Page 14 UNILUX-6 65 5.3 INSTRUCTIONS WHILE STOKING Using the air supply slider you can adjust the air supply for further combustion. Make sure the appliance burns quietly. Note: Once you have got the appliance going, leave the air supply slider in the centre position for optimal combustion.
  • Page 15 UNILUX-6 65 Control range of primary air supply (by grate) Control range of secondary and tertiary air supply Combustion air supply slider Centre position We recommend that you maintain a substantial layer of ash (2 - 3 cm). This not only forms a protective layer for the base of the appliance but also signifi...
  • Page 16 UNILUX-6 65 Modifi cation Do not make modifi cations to your appliance. Any alteration to your appliance, of whatever nature, will also invalidate your warranty. Only open the door for fi lling and lighting the appliance and for removing the ash. Keep the door shut at all other times.
  • Page 17 UNILUX-6 65 5.6 INCREASE THE FLUE DRAUGHT Attention: Not possible if the appliance is equipped with a 45 degrees chimney connection. If there is too much fl ow resistance in the chimney, causing insuffi cent fl ow of of the fl ue gasses, one can increase the chimney draught.
  • Page 18 UNILUX-6 65 5.7 GENERAL HEATING TIPS • Burn dry wood only. Damp wood not only burns poorly, it causes more pollution in the appliance (window), the chimney, your room (when opening the door of the appliance, for instance) and the environment. Wood can only be classifi ed as dry if it has been stored under a Dutch barn for at least two years (not covered with plastic).
  • Page 19 UNILUX-6 65 5.8 OUTPUT In practice, combustion is all about loss. This entails: • Loss through excess heat leaving the chimney, rather than going into the room. • Loss through insuffi cient combustion, such as CO (carbon monoxide) and soot particles.

  • Page 20: Fuel

    If this happens, there is a risk of fi re. It may also damage your appliance and chimney. BARBAS will not assume liability for damage caused by overheating. Burning one layer of wood can lead to varying outputs. When used correctly, one load will burn in around 45 minutes.
  • Page 21 UNILUX-6 65 Per fi lling: (= for 45 minutes) Wood: 2 blocks each around 1.0 kg Briquettes: 2 blocks each around 0.75 kg Dimensions wood block: c. 30 cm long and 25 cm perimeter ê The maximum burning load is based on a nominal capacity of 8 kW and a effi...

  • Page 22: Maintenance

    UNILUX-6 65 MAINTENANCE • Emptying the ashtray • Regularly check how much ash is in the ashtray. • Make sure the ashtray is never more than ¾ full. If the ashtray is more than ¾ full, it can obstruct the fl ow of air to the appliance.
  • Page 23 UNILUX-6 65 • Paint Check annually, if necessary touch up with BARBAS heat-resistant paint (do not paint when the appliance is in use!) • Parts Individual parts for replacement/accessories are available from your BARBAS dealer Use only original parts • Modifi cations Introduced modifi...

  • Page 24: Frequently Asked Questions

    UNILUX-6 65 FREQUENTLY ASKED QUESTIONS How often should I have my chimney swept? At least once a year. If you use your appliance more than three times a week on average, have your chimney swept more often. Have the chimney swept by a recognised company.
  • Page 25 Can a wood-burning appliance/fi replace insert be connected to a central heating installation? The Barbas range does not have any appliances that can be connected to central heating installations. We do not advise attempting it!! How do I know if I’m heating correctly? Follow the instructions in this manual.
  • Page 26 UNILUX-6 65 Can I leave my appliance unattended? Only do this when the appliance is burning quietly, with just a little wood, with a closed door and with the combustion air supply slider in the centre position between “ + ” and “...
  • Page 27 UNILUX-6 65 Decomposition At moderate - high temperatures (150°C - 350°C), the decomposition process can be discerned. This is when the chemical structure of the fuel breaks down. This process involves the creation of volatile compounds such as carbon monoxide (CO), water...

  • Page 28: Technical Data

    UNILUX-6 65 TECHNICAL DATA Combustion: Measured in compliance with EN 13229 : 2001 and EN 13229 - A2 : 2004 Fuel Wood Nominal output 8 kW Effi ciency Emissions (dry, at 13% O , 273 K, 1013 hPa): Carbon monoxide (CO) 0.08%;...
  • Page 29 UNILUX-6 65 Combustion air supply: At least 150 cm opening in the room where the fi re is located or a outside air supply opening of Ø125 mm in wall/fl oor. Options: • Convection set *) *) Not available if the appliance is equipped with a 45 degrees chimney connection.

  • Page 30: Warranty Terms

    2.3. Complaints will only be accepted if they are reported to the Barbas dealer, together with the serial number of the Barbas appliance which is stated on the front of the instructions for use. 2.4. In addition, the original receipt (invoice, receipt, cash receipt) showing the date of purchase must also be submitted.
  • Page 31 Article 5: Warranty period 5.1. This warranty will only be granted during the warranty period. 5.2. The body of the Barbas appliance is guaranteed for a period of 10 years against construction and/or material faults, starting from the moment of purchase.
  • Page 32 Your Barbas dealer 01 - 010515 - 340184...
