- Page 1 1U Rackmount LCD Keyboard Drawer User Manual SNK117 / 119 Series 17 / 19 LCD Optional KVM 8, 16 Ports USB Single Console...
-
Page 3: Table Of Contents
1. Table Of Content 1. Table of Content 2. Read Before Installation 3. Introduction 4. Features 5. Package Contents 6. Optional Accessories 7. Peripheral Products 8. Important Safeguards 9. Structure Diagram 10. Dimension Diagram SNK117-8/1601 SNK119-8/1601 11. LCD Session LCD Membrane Diagram P.11 LCD OSD Control P.11... -
Page 4: Read Before Installation
2. Read Before Installation Technical Notes For Windows 98/98 SE systems HID (Human Interface Device) driver must be installed prior to using the USB KVM switch. To install the HID driver, first connect a USB keyboard and mice directly to computer (before installing KVM switch) then follow the Windows installation instructions, this will install the HID device driver and allow the use of the KVM switch. -
Page 5: Introduction
3. Introduction S Solutions is total compatible with Solaris. The LCD screen support SUN native 1152 x 900 & standard resolutions. SUN-compatible keyboard incor- porates SUN system administration commands keys. It is a combination of keyboard, mouse and monitor into a drawer, with features such as flip-up design, adjustable brackets, built in LCD OSD to provide ef- fective assistant for an administrator to control SUN/ PC system. -
Page 6: Package Contents
5. Package Contents LCD Monitor Drawer (optional USB KVM Switch) 1 Piece User Manual 1 Piece DC Power Adapter 1 Piece Power Cord 1 Piece Mounting Bracket 1 Pair Fasteners 4 Pieces CB-6 2-in-1 KVM cable (without KVM) 1 Piece CB-6 2-in-1 KVM cable (with KVM) 8 Pieces Before Unpacking... -
Page 7: Optional Accessories
6. Optional Accessories KVM Cable CB-6 / 10 / 15 6ft / 10ft / 15ft USB 2-in-1 cable Cascade Cable 6ft USB Cascade cable Others Video Input 12V / 24V / 48V DC Power Supply 7. Peripheral Products CV-S801 8-Port USB KVM switch CV-S1601 16-Port USB KVM switch CV-S1602... -
Page 8: Important Safeguards
8. Important Safeguards Please read all of these instructions carefully before you use the device. Save this manual for future reference. Unplug the LCD Keyboard Drawer from the power outlet before cleaning. Do not spray liquid cleaners or aerosol directly on the device. Wet a cloth with a neutral detergent (e.g. -
Page 9: Structure Diagram
9. Structure Diagram USB SUN compatible keyboard 3 Buttons trackball mouse SUN keys Aluminium front panel Class A active matrix TFT LCD panel LCD membrane Ball bearing telescopic slides with stopper Adjustable mounting bracket USB KVM switch ( Optional ) Rev. -
Page 10: Dimension Diagram
10. Dimension Diagram SNK117- 8/1601 1U 17! LCD Keyboard Drawer with USB KVM 17" LCD Rev. : 1.0... -
Page 12: Lcd Session
Session Rev. : 1.0 P.10... -
Page 13: Lcd Membrane Diagram
11. LCD Session LCD Membrane Diagram Power Menu/Selection Exit Right Left MAIN MENU BRIGHT/CONTRAST AUTO ADJUST PHASE/CLOCK H/V POSITION MISC RESET Main Menu Bright / Contrast To enter into the Bright, Black level & Contrast sub-menu Auto Adjust To perform automatic optimisations of all functions An “... - Page 14 11. LCD Session Bright / Contrast 1. Brightness To perform brightness adjustment of the input RGB signal Use the Left & Right button to adjust and button to “Brightness” 2. Contrast To adjust the contrast level of the input signal Use the Left &...
- Page 15 11. LCD Session MISC 1. Information The first header row shows the current resolution setup The second header row shows the horizontal frequency of the current input signal The third header row shows the vertical frequency of the current input signal 2.
-
Page 16: Resolution Settings
11. LCD Session Resolution Settings For Microsoft Windows Step 1 – Press right click on the desktop Step 2 – Choose “Properties” Step 3 – Change the “Screen Resolution” Step 4 – Change the “Screen refresh rate” Rev. : 1.0 P.14... -
Page 17: Kvm Session
Session Rev. : 1.0 P.15... -
Page 18: Front View
12. KVM Session Front View Bank No. Selected Channel Bank Button Online Channel Channel Select Button Shift Button LED Indication Selected Channel - Displayed channel on monitor & red in LED. Channel select button - Press to select channel from 1 – 8. Shift button - Press &... -
Page 19: Rear View
12. KVM Session Rear View Cascade Channel Power Port Port RKP1XX-S801 RKP1XX-S1601 DC Power -connect to external 12V DC power adapter. Cascade Port -connect to additional KVM switch for channel expansion. Console Port - connect to monitor, PS/2 keyboard & mouse. Channel Port - connect to PC computer with CB-6 2-in-1 KVM cable. -
Page 20: Installation Steps
12. KVM Session Installation Steps Before installation, please make sure all computers are turned on and its operating system are running properly with keyboard and mouse. Connect the 2-in-1KVM cable to the one of your server. USB Type A Male connector to the USB Port HDDB 15-pin Male connector to the VGA Port PC I/O windows diagram To VGA port... -
Page 21: Cascading
12. KVM Session Cascading Using a USB KVM cable to connect from Bank 1’s “Cascade port” to Bank 2’s “Console port”. After connected please press “Bank” & “Channel” button on the front of the USB KVM switch to reset the USB KVM switch. Bank 1 USB Cascade cable Bank 2... -
Page 22: Start Up
13. Start Up The channels that have PC connected and it is switch on will have a green LED on that channel. The red LED will indicate the selected channel. 7 segments LED will display the bank number. Press channel button to select the channel. Enter the password, default is “00000000”... -
Page 23: Hotkey Command Operation
13. Start Up Hot-key Command Operation Calling OSD Menu Scroll Scroll Space Bar Switch to Previous Port (powered on PC only) Scroll Scroll Switch to Next Power On Port (powered on PC only) Scroll Scroll Switch to Previous Bank First digit of Port Number: Scroll Scroll 0 for Port 0-9... - Page 24 13. Start Up HotKey Command Operation Switch to Next Bank Scroll Scroll PgDn Enable / Disable beeper sound Scroll Scroll Note: The default Beeper function is ON and beeper control is only for available for Scan Mode. Auto Scan for Powered on PC Scroll Scroll Reset to factory Default Setting...
-
Page 25: Kvm Osd Operation
13. Start Up KVM OSD Operation Note: When using the keyboard arrow key to move the cursor, the keypad arrow key (Up, Down, Right, Left) is unable to work at this menu. “MAIN CONTROLS” - OSD Menu of USB KVM switch To pop up MAIN CONTROLS—OSD menu of USB KVM switch, please use hot keys command . - Page 26 13. Start Up LANGUAGE Menu LANGUAGE CHOOSE A LANGUAGE : ENGLISH Mouse Operation : Move mouse and click the left button to choose a language, and click left key again to save. Keyboard Operation : Press to choose a language and press ENTER to save. Rev.
- Page 27 13. Start Up PORTNAME Menu PORTNAME Bank Session Bank SYSTEM 01 ☼ SYSTEM 02 ☼ SYSTEM 03 ☼ SYSTEM 04 PC Name Session ☼ SYSTEM 05 ☼ SYSTEM 06 ☼ SYSTEM 07 ☼ SYSTEM 08 SYSTEM 09 Use “Tab” key to select session like Bank, PC, OSD, SCAN, CHANGE PASS- WORD, CONSOLE ON/OFF, etc…...
- Page 28 13. Start Up TIMEVIEW Menu TIMEVIEW SCAN : OSD TIME means the display period of OSD windows or PC system name on your monitor. You can modify it from 05 sec to 99 sec. The factory default value is 10 sec... SCAN TIME means the scan interval from one PC port to next PC port.
- Page 29 13. Start Up SECURITY Menu SECURITY ENTER PASSWORD _ _ _ _ _ _ _ _ ENTER NEW PASSWORD _ _ _ _ _ _ _ _ RETYPE NEW PASSWORD _ _ _ _ _ _ _ _ To CHANGE PASSWORD for avoiding all PC systems to be intruded by the others.
- Page 30 13. Start Up FINDPORT Menu FINDPORT ENTER NAME : _ _ _ _ _ _ _ _ _ _ “FINDPORT“ option helps you to find the PC system by its name. Enter PC system name and press ENTER, it will search the matching PC system and given the message for searching result.
- Page 31 13. Start Up CONSOLE Menu CONSOLE ENABLE DISABLE ENABLE – any user can use the console DISABLE – user is not allowed to use the console port, unless password is entered.When password is entered already and pass the KVM switch authentication, the CONSOLE will be set to ENABLE.
-
Page 32: Keyboard & Key Pad Layout
14. Keyboard & Key Pad Layout Press the Fn/Num button to switch the color of Num LED. The Num LED in Blue color: The Num LED in Green color: The key pad behaves as a SUN Solaris system The key pad behaves as a normal key pad mode administration commands mode below below Compose LED always off when on or off compose key. -
Page 33: Faq
15. FAQ Keyboard or mouse dose not work or not be compatible with the PC. Please make sure the keyboard or mouse works when directly plug into the computer. If the problem persists, please try another keyboard or mouse. Mouse doesn’t work in Auto Scan mode You can press any key on the keyboard or the front button on the face plate for returning standard mode and then use the Keyboard or Mouse again. -
Page 34: Technical Specification
16. Technical Specifications Item Specification KVM Channel Port S11X-801: 8 port / S11X-1601: 16 port KVM Channel Interface HDDB 15 pin Female USB Port : Type A Female PC Computer Interface VGA : HDDB 15pin Female Cascade Port Connector HDDB 15pin Female KVM Cable Connection 2-in-1 HDDB 15-pin KVM Cable (CB-6/ 10/ 15) PC selection... - Page 35 16. Technical Specifications L CD Item Description LCD Origin Panel 17" TFT 19" TFT Resolution 1,280 x 1,024 1,280 x 1,024 350 cd/m2 500 cd/m2 Brightness Color 16.2 Million 16.7 Million Contrast Ratio 350:1 500:1 Viewing Angle 140' x 120' 170' x 170' Display Area 337 x 270 mm...
