USER MANUAL
Thank you very much for choosing the
iiyama LCD monitor.
We recommend that you take a few
minutes to read carefully through this
brief but comprehensive manual
before installing and switching on the
monitor. Please keep this manual in a
safe place for your future reference.
ENGLISH
ENGLISH
DEUTSCH
FRANCAIS
NEDERLANDS
Advertisement
Table of Contents
Related Manuals for Iiyama ProLite E1902WSV
Summary of Contents for Iiyama ProLite E1902WSV
- Page 1 ENGLISH DEUTSCH FRANCAIS NEDERLANDS Thank you very much for choosing the iiyama LCD monitor. We recommend that you take a few minutes to read carefully through this brief but comprehensive manual before installing and switching on the monitor. Please keep this manual in a...
- Page 2 Congratulations! The product you have just purchased carries the TCO’06 Media Displays label. This means that your display is designed and manufactured according to some of the strictest performance and environmental criteria in the world. The manufacturer of this display has selected it to be certified to TCO’06 Media Displays as a sign of usability, high performance and reduced impact on the natural environment.
- Page 3 Congratulations! The display you have just purchased carries the TCO’03 Displays label. This means that your display is designed, manufactured and tested according to some of the strictest quality and environmental requirements in the world. This makes for a high performance product, designed with the user in focus that also minimizes the impact on our natural environment.
- Page 4 To meet the FCC requirements, you should use a signal cable with ferrite core at both ends. CAUTION Changes or modifications not expressly approved by iiyama could void the users authority to operate the device under FCC compliance regulations. CANADIAN DEPARTMENT OF COMMUNICATIONS COMPLIANCE...
-
Page 5: Table Of Contents
For disposal or recycling information, please contact your local authorities or the Electronic Industries Alliance (www.eiae.org). This information is only for U.S.A.. We recommend recycling of used product. Please contact your dealer or iiyama service center. Recycle information is obtained via the Internet, using the address: http://www.iiyama.com... -
Page 6: For Your Safety
STOP OPERATING THE MONITOR WHEN YOU SENSE TROUBLE If you notice any abnormal phenomena such as smoke, strange sounds or fumes, unplug the monitor and contact your dealer or iiyama service center immediately. Further use may be dangerous and can cause fire or electric shock. - Page 7 CAUTION INSTALLATION LOCATION Do not install the monitor where sudden temperature changes may occur, or in humid, dusty or smoky areas as it may cause fire, electric shock or damage. You should also avoid areas where the sun shines directly on the monitor. DO NOT PLACE THE MONITOR IN A HAZARDOUS POSITION The monitor may topple and cause injury if not suitably located.
-
Page 8: Special Notes On Lcd Monitors
Power Switch for hours. Contact your dealer or iiyama service center for the backlight replacement when the screen is dark, flickering or not lighting up. Never attempt to replace it by yourself. -
Page 9: Before You Operate The Monitor
BEFORE YOU OPERATE THE MONITOR [Stopper] : ProLite B1902S Please stand the monitor and then remove the stopper on the back of the stand slowly. FEATURES 48cm (19") TFT Color LCD Monitor Supports Resolutions up to 1280 × 1024 : ProLite E1902S / B1902S Supports Resolutions up to 1440 ×... -
Page 10: Checking The Contents Of The Package
CHECKING THE CONTENTS OF THE PACKAGE The following accessories are included in your package. Check to see if they are enclosed with the monitor. If anything is missing or damaged, please contact your local iiyama dealer or regional iiyama office. -
Page 11: Fitting And Removal Of Base : Prolite E1902S / E1902Ws / E1902Wsv
FITTING AND REMOVAL OF BASE : ProLite E1902S / E1902WS / E1902WSV CAUTION Install the stand on a stable surface. The monitor may cause injury or damage if it falls or is dropped. Do not give a strong impact to the monitor. It may cause damage. Unplug the monitor before installation to avoid electric shock or damage. -
Page 12: Controls And Connectors : Prolite E1902S / E1902Ws / E1902Wsv
CONTROLS AND CONNECTORS : ProLite E1902S / E1902WS / E1902WSV <Front> <Back> A Menu Button (MENU) B + Button ( C Power Switch ( D – Button ( E Auto Button (AUTO) F Power Indicator Blue: Normal operation NOTE Orange: Power Management Auto (Signal Select) When no signal is received from the system, the display enters into its Power Management Mode reducing power consumption to <... -
Page 13: Controls And Connectors : Prolite B1902S
CONTROLS AND CONNECTORS : ProLite B1902S <Front> <Back> A Menu Button (MENU) B + Button ( C Power Switch ( D – Button ( E Auto Button (AUTO) F Power Indicator Blue: Normal operation NOTE Orange: Power Management Auto (Signal Select) When no signal is received from the system, the display enters into its Power Management Mode reducing power consumption to <... -
Page 14: Connecting Your Monitor : Prolite E1902S / E1902Ws / E1902Wsv
The cable supplied with the monitor is for a standard 15 pin D-Sub connector. If a special cable is required please contact your local iiyama dealer or regional iiyama office. For connection to Macintosh computers, contact your local iiyama dealer or regional iiyama office for a suitable adaptor. -
Page 15: Connecting Your Monitor : Prolite B1902S
The cable supplied with the monitor is for a standard 15 pin D-Sub connector. If a special cable is required please contact your local iiyama dealer or regional iiyama office. For connection to Macintosh computers, contact your local iiyama dealer or regional iiyama office for a suitable adaptor. -
Page 16: Computer Setting
Change to the desired signal timing listed on page 33: COMPLIANT TIMING. Windows 95/98/2000/Me/XP/Vista Plug & Play The iiyama LCD monitor complies with DDC2B of VESA standard. The Plug & Play function runs on Windows 95/98/2000/Me/XP/Vista by connecting the monitor to DDC2B compliant computer with the Signal Cable supplied. -
Page 17: Adjusting The Height And The Viewing Angle : Prolite B1902S
ADJUSTING THE HEIGHT AND THE VIEWING ANGLE : ProLite B1902S For optimal viewing it is recommended to look at the full face of the monitor, then adjust the monitor's Height and angle to your own preference. Hold the stand so that the monitor does not topple 110mm when you change the monitor’s angle. -
Page 18: Operating The Monitor
OPERATING THE MONITOR To create the best picture, your iiyama LCD monitor has been preset at the factory with the COMPLIANT TIMING shown on page 33. You are also able to adjust the picture by following the button operation shown below. For more detailed adjustments, see page 22 for SCREEN ADJUSTMENTS. -
Page 19: Adjustment Menu Contents
ADJUSTMENT MENU CONTENTS Direct You can skip the Menu pages and display an adjustment scale directly by using the following button operations. Brightness / Contrast / Volume: To display direct menu press either of the +/- Buttons. Continue to use the +/- Buttons to select the adjustments required. Auto Set-up: Press the Auto Button when the Menu is not displayed. - Page 20 Analog Input Menu : 1 (Analog) Menu:1 1280 × 1024 H : 8 0 . 0 K H z V : 7 5 . 0 H z Adjustment Item Problem / Option Button to Press Too dark Direct Brightness * Too bright Too dull Direct...
-
Page 21: Screen Adjustments
Menu : 2 M e n u : 2 (Analog) 1280 × 1024 H : 8 0 K H z V : 7 5 . 0 H z Adjustment Item Problem / Option Button to Press Return to Menu. Auto Set-up * Adjust Clock, Phase, V-Position and H-Position Direct automatically. - Page 22 Menu : 2 (Analog) Adjustment Item Problem / Option Normal Gamma Mode1 High contrast Mode2 Dark Normal Economy Mode Mode1 Brightness of back-light is reduced. Mode2 Brightness of back-light is reduced more than Mode1. NOTE is displayed while Economy Mode is active. Return to Menu Highlight “Menu : 2”...
- Page 23 Menu : 3 M e n u : 3 (Analog) 1280 × 1024 H : 8 0 . 0 K H z V : 7 5 . 0 H z Problem / Option Button to Press Adjustment Item Too soft Direct Volume Too loud...
- Page 24 Digital Input : Available for ProLite E1902S / E1902WS / B1902S only. Menu : 1 Menu:1 (Digital) 1280 × 1024 H : 8 0 . 0 K H z V : 7 5 . 0 H z Adjustment Item Problem / Option Button to Press Too dark Direct...
- Page 25 Menu : 1 (Digital) Adjustment Item Problem / Option Normal Economy Mode Mode1 Brightness of back-light is reduced. Mode2 Brightness of back-light is reduced more than Mode1. NOTE is displayed while Economy Mode is active. Return to Menu Highlight “Menu : 1” again. OPERATING THE MONITOR...
- Page 26 Menu : 2 M e n u : 2 (Digital) 1280 × 1024 H : 8 0 . 0 K H z V : 7 5 . 0 H z Problem / Option Button to Press Adjustment Item Too soft Direct Volume Too loud...
-
Page 27: Screen Adjustments
If the screen has a flicker or blur, or the picture does not fit in the display area after performing the Auto Set-up, manual adjustments are required. Both adjustments should be made by using the screen adjustment pattern (Test.bmp) obtained via the IIYAMA web site (http:// www.iiyama.com). - Page 28 C C C C C Press the Auto Button. (Auto Set-up) D D D D D Adjust the image manually by following procedure below when the screen has a flicker or blur, or the picture does not fit in the display area after performing the Auto Set-up.
- Page 29 G G G G G Adjust the Phase to correct horizontal wavy noise, flicker or blur in the zebra pattern. – In case the strong flicker or blurs remain on a part of the screen, repeat steps F and NOTE NOTE G because the Clock may not be adjusted correctly.
-
Page 30: Power Management Feature
POWER MANAGEMENT FEATURE The power management feature of this product complies with power saving requirement of E NERGY ® and VESA DPMS. When activated, it automatically reduces unnecessary power consumption of the monitor when your computer is not in use. To use the feature, the monitor needs to be connected to a VESA DPMS compliant computer. - Page 31 2. Consult the following items if you cannot find an appropriate adjustment item in OPERATING THE MONITOR or if the problem persists. If you are experiencing a problem which is not described below or you cannot correct the problem, discontinue using the monitor and contact your dealer or iiyama service center for further assistance. Problem...
- Page 32 Problem Check No sound. The audio equipment (computer etc.) is ON. The Audio Cable is properly connected. The Volume is turned up. The Mute is OFF. The audio output level of the audio equipment is within the specification of the monitor. The sound is too The audio output level of the audio equipment is within the specification of the monitor.
-
Page 33: Specifications: Prolite E1902S
APPENDIX SPECIFICATIONS: ProLite E1902S LCD Panel a-Si TFT Active Matrix Driving system Size Diagonal: 48cm / 19" Pixel pitch 0.294mm H × 0.294mm V Brightness 300cd/m (Typical) Contrast ratio 1000 : 1 (Typical) Viewable angle Right / Left / Up / Down: 80 degrees each 5ms (Black, white, black), 2ms (Gray to Gray) Response time Display Colors... -
Page 34: Specifications: Prolite E1902Ws
SPECIFICATIONS: ProLite E1902WS LCD Panel Driving system a-Si TFT Active Matrix Size Diagonal: 48cm / 19" Pixel pitch 0.285mm H × 0.285mm V Brightness 400cd/m (Typical) Contrast ratio 1000 : 1 (Typical) Viewable angle Right / Left: 85 degrees each, Up / Down: 80 degrees each Response time 5ms (Black, white, black), 2ms (Gray to Gray) Display Colors... -
Page 35: Specifications: Prolite E1902Wsv
SPECIFICATIONS: ProLite E1902WSV LCD Panel Driving system a-Si TFT Active Matrix Size Diagonal: 48cm / 19" Pixel pitch 0.285mm H × 0.285mm V Brightness 400cd/m (Typical) Contrast ratio 1000 : 1 (Typical) Viewable angle Right / Left: 85 degrees each, Up / Down: 80 degrees each... -
Page 36: Specifications: Prolite B1902S
SPECIFICATIONS: ProLite B1902S LCD Panel Driving system a-Si TFT Active Matrix Size Diagonal: 48cm / 19" Pixel pitch 0.294mm H × 0.294mm V Brightness 300cd/m (Typical) Contrast ratio 1000 : 1 (Typical) Viewable angle Right / Left / Up / Down: 80 degrees each Response time 5ms (Black, white, black), 2ms (Gray to Gray) Display Colors... -
Page 37: Dimensions : Prolite E1902S
DIMENSIONS : ProLite E1902S 407.5mm/16.0" 60.0mm/2.4" 378.5mm/14.9" 204.0mm/8.0" DIMENSIONS : ProLite E1902WS / E1902WSV 438.5mm/17.3" 61.0mm/2.4" 412.5mm/16.2" 204.0mm/8.0" DIMENSIONS : ProLite B1902S 407.5mm/16.0" 60.0mm/2.4" 378.5mm/14.9" 300.5mm/11.8" ( ): Maximum adjustment range APPENDIX... -
Page 38: Compliant Timing
COMPLIANT TIMING Horizontal Vertical Dot Clock Video Mode Frequency Frequency 31.469kHz 59.940Hz 25.175MHz 37.500kHz 75.000Hz 31.500MHz 640 × 480 37.861kHz 72.809Hz 31.500MHz 35.156kHz 56.250Hz 36.000MHz 37.879kHz 60.317Hz 40.000MHz SVGA 800 × 600 49.500MHz 46.875kHz 75.000Hz VESA 50.000MHz 48.077kHz 72.188Hz 65.000MHz 48.363kHz 60.004Hz 1024 ×... -
Page 39: Connector Pin Assignment
CONNECTOR PIN ASSIGNMENT D-Sub mini 15pin Input Signal Input Signal Connector Red video Ground Green video Blue video Reserved port Data line (SDA)* Reserved port Ground Ground H-Sync Red video ground V-Sync Green video ground Clock line (SCL)* Blue video ground * Compliant to VESA DDC.
