MAK LIG24FM Quick Start Manual

Specification
LIG24FM
Model
1/3"CMOS
Pick up Element
Effective Picture Elements
720(H)X576(V)
(H×V)
800TV Line
Horizontal Resolution
0.01Lux/F1.2
Minimum Illumination
More than 50dB
S/N Ratio
2:1 interface
Scanning System
Internal, Negative sync.
Synchronous System
NTSC: 1/60s~1/100, 000s, PAL: 1/50s~1/100,000s
Auto Electronic Shutter
0.45
Gama Characteristic
20 Meters (with ￠5X24PCS Infrared LED)
IR Distance
Under 10Lux by CDS
IR Status
CDS AUTO Control
IR Power On
1Vpp, 75Ω
Video Output
Auto
Auto Gain Control
DC12V (+/-10%)/350mA
Power/Current
Board Lens 3.6mm/F2.0
Lens
208(W) x66(H) x65(D)
Dimension (mm)
500
Weight (g)
-30~+60℃ RH95% MAX
Storage Temperature
-10~+50℃ RH95% MAX
Operating Temperature
Packing List
No Name
1. Weatherproof IR Color Camera LIG24FM
2. User Guide LIG24FM
Franchiser：
Model Number
1
1
LIG24FM Color Camera
Weatherproof IR Color Camera
Notes:
Before providing power for the
camera, please read this User Guide in
detail!
Do not attempt to disassemble the camera.
If the camera can not work, please contact
local franchiser or our company.
