Instruction Manual
Thank you for purchasing the FM-2022 parallel remover.
Please read this manual before operating the FM-2022.
Keep this manual readily accessible for reference.
• The FM-2022 cannot function by itself. It must be connected
to an FM-202 soldering station.
• Specific information can be found in the instruction manual
for your FM-202 soldering station.
1. PACKING LIST ........................................................ 1
2. SPECIFICATIONS ................................................... 1
3. WARNINGS, CAUTIONS AND NOTES .................. 2
4. PART NAMES ......................................................... 3
5. SETTING UP THE FM-2022 ................................... 3
6. OPERATION ........................................................... 4
7. TIP IDENTIFICATION NUMBER ............................. 6
8. MAINTENANCE ...................................................... 7
9. TROUBLESHOOTING GUIDE ................................ 8
10. PARTS LIST .......................................................... 10
11. WIRING DIAGRAM ............................................... 11
PARALLEL REMOVER
CAUTION
TABLE OF CONTENTS
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Hakko Electronics FM2022-02
Summary of Contents for Hakko Electronics FM2022-02
-
Page 1: Table Of Contents
® PARALLEL REMOVER Instruction Manual Thank you for purchasing the FM-2022 parallel remover. Please read this manual before operating the FM-2022. Keep this manual readily accessible for reference. CAUTION • The FM-2022 cannot function by itself. It must be connected to an FM-202 soldering station. -
Page 2: Packing List
1. PACKING LIST Parallel remover ......... 1 Heat resistant pad ......1 Tip (not included) FM-2022 Parallel remover Heat resistant pad Cleaning sponge Holder clip Applicable Models In order to function, the FM-2022 must be connected to the FM-202 soldering station. 2. -
Page 3: Warnings, Cautions And Notes
3. WARNINGS, CAUTIONS AND NOTES Warnings, cautions and notes are placed at critical points in this manual to direct the operator’s attention to significant items. They are defined as follows: WARNING: Failure to comply with a WARNING may result in injury or death. CAUTION: Failure to comply with a CAUTION may result in injury to the operator, or damage to the items involved. -
Page 4: Part Names
4. PART NAMES Button Fixing flange Tip ID Plug Handle Cord Tip (not included) Plug Cleaning sponge Heat resistant pad Holder clip 5. SETTING UP THE FM-2022 1. Connector cord Pass the connector cord through the hole in the heat resistant pad. 2. -
Page 5: Operation
6. OPERATION Controls and displays Please refer to the FM-202 instruction manual. FM-202 NOTE: Soldering station If the buzzer sounds three times when the tip is inserted into the process gate, there has been a reading error. Reinsert the tip. If the Process gate Tip ID is torn or damaged the process gate Receptacle... - Page 6 6. When the set temperature is reached, NOTE: the buzzer sounds and the heater Once the two tips are inserted into the hand- piece, heat control begins. lamp at the lower right of the temper- Both tips of the set must be inserted or the ature display starts blinking.
-
Page 7: Tip Identification Number
Control card and changing the temperature setting Please refer to the FM-202 Instruction manual. Replacing the tip Removing and inserting the tip: Removing the tip: Hold this part to insert into the tweezer. Hold the handle and pull the tip out of the handpiece with the heat resistant pad. -
Page 8: Maintenance
8. MAINTENANCE Tip maintenance Please refer to the FM-202 Instruction manual. Checking Procedure WARNING: Unless otherwise directed, carry out these procedures with the power switch OFF and the power UNPLUGGED. Verify the electrical integrity 1. Check for a broken heater or sensor of the heater and sensor Measure the resistance across this position Tip ID... -
Page 9: Troubleshooting Guide
Checking the connection 1. Remove the soldering tip and the handle. cord for breakage (Refer to 2. Measure the resistance values between the P.11 WIRING DIAGRAM of A connector and the lead wires at the socket side. ) as follows: A side socket Pin 7 - (1) Pin 2 - (3) - Page 10 The tip temperature is CHECK : Is the tip contaminated with oxide? ACTION : Remove the oxide by cleaning the tip too low. on a damp sponge of Hakko 599B tip cleaner. CHECK : Is the entered tip identification number correct? ACTION : Enter the correct value.
-
Page 11: Parts List
10. PARTS LIST NOTE: Replacement parts do not include mounting screws if they are not listed on the description. Screws must be ordered separately. Parallel remover Item No. Part No. Part Name Specifications B2783 Handle A & B with screws B2784 LED Holder B2300... -
Page 12: Wiring Diagram
11. WIRING DIAGRAM A side socket + – P.W.B./LED LED1 B side socket Green Black White HEAD OFFICE 4-5, SHIOKUSA 2-CHOME, NANIWA-KU, OSAKA, 556-0024 JAPAN TEL:+81-6-6561-3225 FAX:+81-6-6561-8466 http://www.hakko.com AMERICAN HAKKO PRODUCTS, INC. 28920 N. AVENUE WILLIAMS VALENCIA CA 91355, U.S.A. TEL: (661) 294-0090 FAX: (661) 294-0096 Toll Free (800)88-HAKKO www.hakkousa.com 4 2 5 5 6...
