Instruction Manual
®
Instruction Manual
Thank you for purchasing the FM-2022 parallel remover.
Please read this manual before operating the FM-2022.
Keep this manual readily accessible for reference.
• The FM-2022 cannot function by itself. It must be connected
to an FM-202 soldering station.
• Specific information can be found in the instruction manual
for your FM-202 soldering station.
1. PACKING LIST ........................................................ 1
2. SPECIFICATIONS ................................................... 1
3. WARNINGS, CAUTIONS AND NOTES .................. 2
4. PART NAMES ......................................................... 3
5. SETTING UP THE FM-2022 ................................... 3
6. OPERATION ........................................................... 4
7. TIP IDENTIFICATION NUMBER ............................. 6
8. MAINTENANCE ...................................................... 7
9. TROUBLESHOOTING GUIDE ................................ 8
10. PARTS LIST .......................................................... 10
11. WIRING DIAGRAM ............................................... 11
PARALLEL REMOVER
CAUTION
TABLE OF CONTENTS
Advertisement
Table of Contents
Related Manuals for Hakko Electronics FM-2022
Summary of Contents for Hakko Electronics FM-2022
-
Page 1: Table Of Contents
Please read this manual before operating the FM-2022. Keep this manual readily accessible for reference. CAUTION • The FM-2022 cannot function by itself. It must be connected to an FM-202 soldering station. • Specific information can be found in the instruction manual for your FM-202 soldering station. -
Page 2: Packing List
Tip (not included) FM-2022 Parallel remover Heat resistant pad Cleaning sponge Holder clip Applicable Models In order to function, the FM-2022 must be connected to the FM-202 soldering station. 2. SPECIFICATIONS FM-2022 Parallel remover Power consumption 140W (24V) Temperature range 200 –... -
Page 3: Warnings, Cautions And Notes
Do not use the unit for applications other than those specifically described in the instruction manual. Do not set the tip temperature higher than 400°C/750°F. Do not rap the FM-2022 against the work bench to shake off residual solder, or otherwise subject the iron to severe shocks. Do not modify the unit. -
Page 4: Part Names
No.2 3. Connections 1. Connect the plug to the FM-202. When the plug ‘clicks’, 2. Place the FM-2022 in the iron holder. it is fully inserted. Receptacle 3. Plug the power cord into the power supply. Be sure to ground the unit. -
Page 5: Operation
6. OPERATION Controls and displays Please refer to the FM-202 instruction manual. FM-202 NOTE: Soldering station If the buzzer sounds three times when the tip is inserted into the process gate, there has been a reading error. Reinsert the tip. If the Process gate Tip ID is torn or damaged the process gate Receptacle... - Page 6 6. When the set temperature is reached, NOTE: the buzzer sounds and the heater Once the two tips are inserted into the hand- piece, heat control begins. lamp at the lower right of the temper- Both tips of the set must be inserted or the ature display starts blinking.
-
Page 7: Tip Identification Number
Control card and changing the temperature setting Please refer to the FM-202 Instruction manual. Replacing the tip Removing and inserting the tip: Removing the tip: Hold this part to insert into the tweezer. Hold the handle and pull the tip out of the handpiece with the heat resistant pad. -
Page 8: Maintenance
Pin 1 – Red Pin 2 – Green B side socket Green Black Pin 3 – Black Pin 5 – White If any value exceeds 0Ω or is ∞, replace the FM-2022. White (inside) -
Page 9: Troubleshooting Guide
Pin 7 - (1) Pin 2 - (3) Pin 4 - (4) Pin 8 - (2) If any value exceeds 0Ω or is ∞, replace the FM-2022. (2)(inside) 9. TROUBLESHOOTING GUIDE WARNING: Disconnect the power plug before servicing. Failure to do so may result in electric shock. - Page 10 : Is the connection cord broken? ACTION : See “Checking the connection cord is displayed. for breakage”. CHECK : Is the FM-2022 plug disconnected? ACTION : Connect the FM-2022. The low-temperature CHECK : Is the tip too small for the items to be...
-
Page 11: Parts List
10. PARTS LIST NOTE: Replacement parts do not include mounting screws if they are not listed on the description. Screws must be ordered separately. Parallel remover Item No. Part No. Part Name Specifications B2783 Handle A & B with screws B2784 LED Holder B2300... -
Page 12: Wiring Diagram
11. WIRING DIAGRAM A side socket + – P.W.B./LED LED1 B side socket Green Black White HEAD OFFICE 4-5, SHIOKUSA 2-CHOME, NANIWA-KU, OSAKA, 556-0024 JAPAN TEL:+81-6-6561-3225 FAX:+81-6-6561-8466 http://www.hakko.com AMERICAN HAKKO PRODUCTS, INC. 28920 N. AVENUE WILLIAMS VALENCIA CA 91355, U.S.A. TEL: (661) 294-0090 FAX: (661) 294-0096 Toll Free (800)88-HAKKO www.hakkousa.com 4 2 5 5 6...
