AP61 Hardware Installation Guide
Overview
The Mist AP61 is an IP67 rated outdoor access point which delivers 4x4
MIMO with four spatial streams when operating in multi-user (MU) or single-
user (SU) mode that supports the IEEE 802.11ac Wave 2 specification.
AP61 Hardware Installation Guide
Mist Systems (C) Copyright 2017. All Rights Reserved
1
Advertisement
Table of Contents
Related Manuals for Mist AP61
Summary of Contents for Mist AP61
- Page 1 AP61 Hardware Installation Guide Overview The Mist AP61 is an IP67 rated outdoor access point which delivers 4x4 MIMO with four spatial streams when operating in multi-user (MU) or single- user (SU) mode that supports the IEEE 802.11ac Wave 2 specification.
-
Page 2: Mounting Kit Installation
10/100/1000 BaseT RJ45 interface that supports 802.3at Eth0+PoE PoE PD Eth1 10/100/1000 BaseT RJ45 interface On the AP61E, there are 4 N-type antenna connectors (Ant1-Ant4) Mounting kit installation Mounting kit contents: AP61 Hardware Installation Guide Mist Systems (C) Copyright 2017. All Rights Reserved... - Page 3 How to install the AP61 to the articulation pole: How to install the AP61 to a wall or pole: Install T-form bracket to a wall Install T-form bracket to a pole AP61 Hardware Installation Guide Mist Systems (C) Copyright 2017. All Rights Reserved...
- Page 4 Install the AP61 to the T-form bracket on the wall or pole In a wall mount installation, please use screws that have a 1/4in. (6.3mm) diameter head with a length at least 2 in. (50.8mm). In a pole mount installation, please use the M8x80 screws to attach to the pole mount kit.
-
Page 5: Technical Specifications
Technical Specifications: Feature Description Power options 802.3at PoE AP61 – 12.2in x 12.2in x 4.2in (310mm x 310mm x 107mm) Dimensions AP61E – 12.2in x 13.5in x 4.2in (310mm x 343mm x 107mm) AP61 – 9.85 lbs (4.47 kg) Weight AP61E –... -
Page 6: Warranty Information
Ethernet Surge Protector APOUT-BR1 AP outdoor mounting bracket spare The AP61 product includes an outdoor mounting bracket kit. If you would like a second mounting bracket kit, you can optionally order the spare part. Regulatory Compliance Information: If you need further assistance with purchasing the power source, please contact Mist Systems, Inc. - Page 7 ● This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter. ● For operation within 5.15 ~ 5.25GHz / 5.47 ~5.725GHz frequency range, it is restricted to indoor environment. AP61 Hardware Installation Guide Mist Systems (C) Copyright 2017. All Rights Reserved...
