Kramer T-IN2-REC2 Quick Start Manual

Scan to see website
Step 1: Check What's in the Box
The color of the sheet metal box, locking device, and magnet frame are supplied in the same color as selected for
the TBUS.
Enclosure sheet metal
box (identical to
selected TBUS color)
For White or Aluminum frame and/or White locking device, order separately frame and locking device
accordingly.
Step 2: Table Cutout Dimensions
T-IN2-REC2 - 134 X 89mm (5.28" x 3.5")
•
T-IN4-REC2 - 234 X 89mm (9.21" x 3.5")
•
T-IN6-REC2 - 334 X 89mm (13.15" x 3.5")
•
Kramer recommends using the cutout template (packed with device) and a hole saw for maximal accuracy.
T-IN2-REC2, T-IN4-REC2, T-IN6-REC2
Quick Start
T-IN2-REC2, T-IN4-REC2, T-IN6-REC2
Quick Start Guide
This guide helps you install and use your
Go to www.kramerav.com/downloads/T-IN2-REC2, www.kramerav.com/downloads/T-IN4-REC2
www.kramerav.com/downloads/T-IN6-REC2
upgrades are available.
Black/White Magnet frame
locking device
(identical to
selected TBUS
color)
Cutout
T-IN2-REC2, T-IN4-REC2,
to download the latest user manual and check if firmware
(according to
the requested
TBUS color)
template
P/N: 2 9 0 0 - 3 0 1 8 0 7 QS
T-IN6-REC2 for the first time.
&
Rev: 2
