Summary of Contents for Russell Hobbs RHOFR5003
- Page 1 Oil Filled Radiator Model Number: RHOFR5003 (B) 2500W 220-240V AC 50Hz This product is only suitable for well insulated spaces or occasional use For Customer Services & Spare Parts please call 0345 209 7461 Or visit us at mda.russellhobbs.com PLEASE RETAIN...
-
Page 2: Table Of Contents
CONTENTS Page(s) Unpacking your appliance Safety Instructions Feature Diagram Base Assembly Using your Oil Filled Radiator 9 - 11 Cleaning and Care Problem Solving Guarantee and Customer Services Spare Parts Connection to the Mains Supply Specification 17-18 Notes Disposable Information... -
Page 3: Unpacking Your Appliance
UNPACKING YOUR APPLIANCE Before you use your appliance 1. Remove all the packaging. 2. Check the appliance after unpacking for any visual damage such as: • Misaligned or damaged parts • Damage to the controls • Damage to the plug or cable •... - Page 4 SAFETY INSTRUCTIONS • Do not operate any appliance with a damaged cord or plug, or after the appliance malfunctions or is dropped or damaged in any manner. The supply cord can not be replaced. If the cord is damaged the appliance should be scrapped. •...
- Page 5 SAFETY INSTRUCTIONS • Do not insert any foreign objects into the ventilation. • Keep all ventilation clear of any draped fabric or curtains. • The appliance must not be located immediately below a mains socket. Do not use the appliance with a programmer, timer or any other device that switches the appliance on automatically.
- Page 6 SAFETY INSTRUCTIONS • Warning: Children of less than 3 years should be kept away unless continuously supervised. • Warning: Children aged from 3 years and less than 8 years shall only switch on/off the appliance provided that it has been placed or installed in its intended normal operating position and they have been given supervision or instruction concerning use of the appliance in a safe way and understand the hazards...
-
Page 7: Feature Diagram
FEATURE DIAGRAM 1. Display 5. Power button 2. Fins 6. Power Switch & indicator light 3. Castors/Wheels 7. Power cable storage 4. Power/heat setting switches For Customer Services & Spare Parts please call 0345 209 7461 Or visit us at mda.russellhobbs.com... -
Page 8: Base Assembly
BASE ASSEMBLY 1. Attach the castors to the base plate and secure using the 4 x nuts supplied. 2. Then turn the heater upside down and position between the end fins. 3. Attach the base plates by hooking the 2 x U-bolts through the fins and securing with the 4 x wing nuts. -
Page 9: Using Your Oil Filled Radiator
USING YOUR OIL FILLED RADIATOR • Before connecting your appliance to the mains socket, position the appliance upright on the floor, at least 100cm away from the wall, away from curtains, furniture or wall coverings. • Insert the mains plug into a suitable 13 amp mains socket. •... - Page 10 USING YOUR OIL FILLED RADIATOR Timer Settings Auto-Off Setting To set the heater to automatically switch off after a period of time, follow the below instructions: 1. Press the ‘MODE’ button to go into ‘Timer – AUTO OFF’ setting 2. Press the ‘+’ or ‘-’ buttons to set a time between 1-24 hours. 3.
- Page 11 USING YOUR OIL FILLED RADIATOR Safety Protective Devices - The appliance is fitted with an over heat and tip over protection system. 1. Overheat protection - the power to the heating elements will automatically cut off if the temperature of the heating elements exceeds a certain limit.
-
Page 12: Cleaning And Care
CLEANING AND CARE WARNING: Electrical Shock Hazard. Before you clean the appliance, disconnect the mains plug from the wall socket. • Allow the appliance to cool down completely before cleaning. • Do not immerse cord, plug or appliance in any liquid or allow moisture to come into contact with electrical parts. -
Page 13: Problem Solving
PROBLEM SOLVING My appliance does not work when I turn it on: 1. Check that your appliance is plugged in and the power is turned on at the mains socket. 2. Try another mains socket. 3. Check the appliance is in an upright position. 4. -
Page 14: Guarantee And Customer Services
GUARANTEE AND CUSTOMER SERVICES At Russell Hobbs, we take all our customer feedback seriously. Feel free to contact our Customer Service Team, on 0345 209 7461, who will be more than happy to assist you. This product is guaranteed for 12 months from the date of the original purchase. -
Page 15: Spare Parts
SPARE PARTS To check the availability of the following spare parts, simply contact our friendly Customer Services team using the details provided at the bottom of this page. Castors U-bolts Base Plate For Customer Services & Spare Parts please call 03452097461 Or visit us at mda.russellhobbs.com... -
Page 16: Connection To The Mains Supply
CONNECTION TO THE MAINS SUPPLY This appliance is designed to operate from a mains supply of 220-240V~50Hz/60Hz. Check that the voltage marked on the product corresponds with your supply voltage. How to change the fuse 1. Slot the end of a screwdriver into the recess in the fuse holder of the plug. -
Page 17: Specification
SPECIFICATION Model number RHOFR5003 (B) Rated voltage 220V - 240V ~ 50Hz/60Hz Power consumption 2500W Product dimensions (CMS) (H)63.5 x (W)49 x (D)24 Model number RHOFR5003 (B) Item Symbol Value Unit Item Unit Heat output Type of heat input, for electric storage local space heaters only... - Page 18 NOTES...
-
Page 19: Notes
NOTES... -
Page 20: Disposable Information
Russell Hobbs is a registered trademark used under license from Spectrum Brands (UK) Ltd. Made under license by G2S Limited, Wigan, WN2 4AY/G2S (NI) Ltd, Belfast, BT5 5AD. Russell Hobbs Support: call 0345 209 7461 or visit: mda.russellhobbs.com The ‘wheelie bin’ symbol is known as the 'Crossed-out wheelie bin Symbol'.
