- Page 1 Multi Zone Wall Thermostat Instruction Manual Model: FACW12ZA-BL...
-
Page 2: Welcome
Welcome Thank you for purchasing this Furrion ® Multi Zone Wall Thermostat. Before operating your new product, please read these instructions carefully. This instruction manual contains information for safe use, installation and maintenance of the product. Please keep this instruction manual in a safe place for future reference. This will ensure safe use and reduce the risk of injury. -
Page 3: Table Of Contents
Contents Welcome .................... 1 Contents .................... 2 About your Thermostat ..............3 Product Features .....................3 Control Buttons .......................3 LCD Icons ........................4 Installation ..................5 What’s in the Box ....................5 Thermostat Installation ..................5 Operation ................... 7 Turn On/Off the Thermostat ..................7 Temperature Format ....................7 Operation Mode .......................7 Clock Setting ......................9... -
Page 4: About Your Thermostat
About your Thermostat Product Features Your Multi Zone LCD thermostat is equipped with a liquid crystal display (LCD) to indicate the temperature set-point in Fahrenheit(°F)/Centigrade(°C) and fan speed. It is also equipped with LCD to indicate the system available operation modes. NOTE: The available operation modes will be different depending on the system installed in your RV. -
Page 5: Lcd Icons
About your Thermostat LCD Icons Room Temperature or Error Code Time of Day Sleep Icon Operation Mode Program Zone Fan Speed... -
Page 6: Installation
Installation What’s in the Box Make sure you have all the following items included in the packaging. If any item is damaged or missing, contact your dealer. – Thermostat x 1 – Instruction Manual x 1 Fig. 2 Thermostat Cables –... - Page 7 Installation 5. Connect the cables to thermostat. Rotate the thermostat clockwise until it clips into place. (Fig. 4 and Fig. 5) Thermostat cables Fig. 4 Fig. 5...
-
Page 8: Operation
Operation Temperature Format Your Furrion wall thermostat has been preprogrammed with factory default settings. Review the settings below and adjust to your comfort level. FACTORY DEFAULT SETTINGS HEATING 68ºF / 20ºC COOLING 72ºF / 22ºC FAN SPEED AUTO MODE AUTO FURNACE DIFFERENTIAL 2ºF... - Page 9 Operation Depending on the system installed, there COOL MODE are 5 available modes (AUTO, COOL, ● The system will cycle the HEAT, FAN and DRY) for you to select. compressor on and off based on See the following tables for detailed the room temperature and the information of each mode.
-
Page 10: Clock Setting
Operation HEAT MODE FAN MODE ● The temperature set-point is not NOTE: The HEAT mode is only available when furnace is enabled. available. ● The system will cycle the furnace ● There are 3 fan speed selections in on and off based on the room this mode. -
Page 11: Program Setting
Operation When in OFF mode, you will be NOTE: You may press and hold the requested to set the time on the clock PROGRAM button anytime for 3 seconds after the power turns on. to cancel the program setting. 1. Press PROGRAM button for 3 seconds Zone Selection to enter the clock setting mode. -
Page 12: Set The Fan Speed
Operation toggle to your desired mode. distribution box. 1. Press LIGHT button on the 2. Press button to increase or decrease the temperature set-point thermostat to turn on the mood light. to your comfort level. 2. Press LIGHT button to toggle to your NOTE: The temperature set-point is not desired mood light. -
Page 13: Special Features
Special Features Auto Fan LCD Error Code When the auto fan mode is selected, The following error code will be the fan speed will vary depending on displayed on the LCD when the system the temperature difference between the detects one of the following faults has temperature set-point and the room occurred. -
Page 14: Wiring Diagram
Wiring Diagram COMPRESSOR GRN/YEL INDOOR OUTDOOR GRN/YEL MOTOR MOTOR PASSED GRN/YEL DIELECTRIC 6PIN CONN GRN/YEL CAPACITOR FUSE HEAT ELEMENT 3PIN CONN LIMMITED SWITCH HEAT ELEMENT TO UPPER COIL SENSOR UNIT ROOM SENSOR Elect.Heater Optional* 115VAC ∅ 60Hz 1 GRN/YEL HIGH RED BLK BRN BRN BLU BLK YEL RED... -
Page 15: Specifications
Specifications DC Input Power DC 12V Power Consumption <0.5W Baud Rate 9600bps Dimension 3 x 3 x 15/16” (75 x 75 x 22.5mm) Weight 0.11kg LCD Viewing angle 12 o’clock LCD Backlight Blue... -
Page 16: Warranty
Warranty FURRION WARRANTS FOR A PERIOD OF 1 YEAR FROM DATE OF RETAIL PURCHASE BY THE ORIGINAL END-USE PURCHASER, THAT THIS PRODUCT, WHEN DELIVERED TO YOU IN NEW CONDITION, IN ORIGINAL PACKAGING, FROM A FURRION AUTHORIZED RESELLER AND USED IN NORMAL CONDITIONS, IS FREE FROM ANY DEFECTS IN MANUFACTURING, MATERIALS, AND WORKMANSHIP. - Page 17 TO LOST PROFITS, DOWNTIME, GOODWILL, DAMAGE TO OR REPLACEMENT OF ANY EQUIPMENT OR PROPERTY, ANY COSTS OF RECOVERING, REPROGRAMMING, OR REPRODUCING ANY PROGRAM OR DATA STORED IN OR USED WITH FURRION PRODUCTS. FURRION’S TOTAL LIABILITY IS LIMITED TO THE REPAIR OR REPLACEMENT OF THIS PRODUCT PURSUANT TO THE TERMS OF THIS WARRANTY.
- Page 20 ● 52567 Independence Ct., Elkhart, IN 46514, USA ● Toll free:1-888-354-5792 ● Email: support@furrion.com ©2007-2018 Furrion Ltd. Furrion ® and the Furrion logo are trademarks licensed for use by Furrion Ltd. and registered in the U.S. and other countries. FURRION.COM IM-FHA00029 V1.0...
