- Page 1 Single Zone Basic Wall Thermostat Instruction Manual Model: FACW12SA-BL...
-
Page 2: Welcome
Welcome Thank you for purchasing this Furrion ® Single Zone Basic Wall Thermostat. Before operating your new product, please read these instructions carefully. This instruction manual contains information for safe use, installation and maintenance of the product. Please keep this instruction manual in a safe place for future reference. This will ensure safe use and reduce the risk of injury. -
Page 3: Table Of Contents
Contents Welcome .................... 1 Contents .................... 2 About your Thermostat ..............3 Product Features .....................3 Control Buttons .......................3 LCD Icons ........................4 Installation ..................5 What’s in the Box ....................5 Thermostat Installation ..................5 Operation ................... 7 Turn On/Off the Thermostat ..................7 Temperature Format ....................7 Operation Mode .......................7 Set the Temperature ....................9... -
Page 4: About Your Thermostat
About your Thermostat Product Features Your Single Zone LCD thermostat is equipped with a liquid crystal display (LCD) to indicate the temperature set-point in Fahrenheit(°F)/Centigrade(°C) and fan speed. It is also equipped with LCD to indicate the system available operation modes. NOTE: The available operation modes will be different depending on the system installed in your RV. -
Page 5: Lcd Icons
About your Thermostat LCD Icons Room Temperature or Operation Mode Error Code Fan Speed... -
Page 6: Installation
Installation What’s in the Box Make sure you have all the following items included in the packaging. If any item is damaged or missing, contact your dealer. – Thermostat x 1 – Instruction Manual x 1 Fig. 2 Thermostat Cables –... - Page 7 Installation 5. Connect the cables to thermostat. Rotate the thermostat clockwise until it clips into place. (Fig. 4 and Fig. 5) Thermostat cables Fig. 4 Fig. 5...
-
Page 8: Operation
Operation Temperature Format Your Furrion wall thermostat has been preprogrammed with factory default settings. Review the settings below and adjust to your comfort level. FACTORY SETTINGS HEATING 68ºF / 20ºC COOLING 72ºF / 22ºC FAN SPEED AUTO MODE COOL FURNACE DIFFERENTIAL 2ºF... - Page 9 Operation are 4 available modes (COOL, HEAT, HEAT MODE FAN and DRY) for you to select. See the NOTE: The HEAT mode is only following tables for detailed information available when furnace is enabled. of each mode. ● The system will cycle the furnace NOTE: The HEAT mode is only available on and off based on the room after the furnace is enabled.
-
Page 10: Set The Temperature
Operation The temperature set-point ranges from FAN MODE 60ºF~86ºF (16ºC~30ºC). ● The temperature set-point is not 1. Press button to toggle to your available. desired mode. ● There are 3 fan speed selections in 2. Press button to increase or this mode. -
Page 11: Special Features
Special Features Auto Fan LCD Error Code When the auto fan mode is selected, The following error code will be the fan speed will vary depending on displayed on the LCD when the system the temperature difference between the detects one of the following faults has temperature set-point and the room occurred. -
Page 12: Wiring Diagram
Wiring Diagram COMPRESSOR GRN/YEL INDOOR OUTDOOR GRN/YEL MOTOR MOTOR PASSED GRN/YEL DIELECTRIC 6PIN CONN GRN/YEL CAPACITOR FUSE HEAT ELEMENT 3PIN CONN LIMMITED SWITCH HEAT ELEMENT TO UPPER COIL SENSOR UNIT ROOM SENSOR Elect.Heater Optional* 115VAC ∅ 60Hz 1 GRN/YEL HIGH RED BLK BRN BRN BLU BLK YEL RED... -
Page 13: Specifications
Specifications DC Input Power DC 12V Power Consumption <0.5W Baud Rate 9600bps Dimension 3 x 3 x 15/16” (75 x 75 x 22.5mm) Weight 0.06kg LCD Viewing angle 12 o’clock... -
Page 14: Warranty
Warranty FURRION WARRANTS FOR A PERIOD OF 1 YEAR FROM DATE OF RETAIL PURCHASE BY THE ORIGINAL END-USE PURCHASER, THAT THIS PRODUCT, WHEN DELIVERED TO YOU IN NEW CONDITION, IN ORIGINAL PACKAGING, FROM A FURRION AUTHORIZED RESELLER AND USED IN NORMAL CONDITIONS, IS FREE FROM ANY DEFECTS IN MANUFACTURING, MATERIALS, AND WORKMANSHIP. - Page 15 TO LOST PROFITS, DOWNTIME, GOODWILL, DAMAGE TO OR REPLACEMENT OF ANY EQUIPMENT OR PROPERTY, ANY COSTS OF RECOVERING, REPROGRAMMING, OR REPRODUCING ANY PROGRAM OR DATA STORED IN OR USED WITH FURRION PRODUCTS. FURRION’S TOTAL LIABILITY IS LIMITED TO THE REPAIR OR REPLACEMENT OF THIS PRODUCT PURSUANT TO THE TERMS OF THIS WARRANTY.
- Page 16 ● 52567 Independence Ct., Elkhart, IN 46514, USA ● Toll free:1-888-354-5792 ● Email: support@furrion.com ©2007-2018 Furrion Ltd. Furrion ® and the Furrion logo are trademarks licensed for use by Furrion Ltd. and registered in the U.S. and other countries. FURRION.COM IM-FHA00025 V1.0...
