Summary of Contents for Maxon SP-120 Series

  • Page 1 SP -120 Series Synthesized Scanning Radio Operating Instructions...
  • Page 2 We urge you to thoroughly read this manual before operating the radio. Application of some of the functions described in this manual is determined by the system you use. Your Maxon Dealer will program your radio so that you have the greatest number of functions possible relative to your needs.
  • Page 3: Table Of Contents

    Table of Contents Safety Information..............Unpacking Information............SP-120 Series Features............Description of Radio Components......... Antenna Installation............... Installing and Removing the Battery Pack /Attaching and Removing the Belt Clip............Battery Charging and Care............. SP-120 Series Operation............Power On-Volume..........Transmit..............Receive..............Power Off..............
  • Page 4: Safety Information

    General Docket 79-144, March 13, 1985, has adopted a safety standard for human exposure to Radio Frequency (RF) electromagnetic energy emitted by FCC regulated equipment. Maxon subscribes to the same safety standard for the use of its products. Proper operation of this radio will result in user exposure far below the Occupational Safety and Health Act and Federal Communications Commission limits.
  • Page 5: Unpacking Information

    Unpacking Information Remove and carefully inspect the contents of your package(s) for the following items: Radio Battery Pack Antenna Belt Clip Wall Charger Operating Instructions If any items are missing, please contact your Dealer or Maxon.
  • Page 6: Sp-120 Series Features

    SP-120 Series Features • Wideband frequency separation • 2 Watts output power • Channel scan • Priority channel scan • Look back channel • CTCSS/DCS tone signalling • Busy channel lockout • Time-out timer...
  • Page 7: Description Of Radio Components

    Description of Radio Components 1) Antenna Receptacle 2) Channel Selector Knob 3) On/Off - Volume Control 4) Busy/TX/BT Indicator 5) Battery Latch 6) Monitor Button 7) Push-To-Talk (PTT) 8) Microphone 9) Speaker 10) Accessory Connector 11) Belt Clip 12) Battery 13) Battery Charge Contacts...
  • Page 9: Antenna Installation

    Antenna Installation Fasten the antenna to the radio by turning the antenna clockwise into the receptacle on top of the radio. Installing and Removing the Battery Pack To Install: Position the guides of the battery in line with the radio battery guide rails and slide the battery into position until a click is heard.
  • Page 10: Battery Charging And Care

    Battery Charging and Care To ensure peak performance from your radio, the battery pack must be fully charged. Proper care and charging will allow maximum performance and life of your battery pack. The SP-120 comes standard with a wall charger. Turn radio off and insert charging adapter into lower hole of accessory connector.
  • Page 11: Sp-120 Series Operation

    SP-120 Series Operations Power On-Volume Turn the radio on by rotating the on /off - volume control clockwise until you hear a click and the self test "alert" tone. Transmit CAUTION OPERATION OF THE TRANSMITTER WITHOUT A PROPER ANTENNA INSTALLED MAY RESULT IN PERMANENT DAMAGE TO THE RADIO 1) Press the monitor button to monitor the channel for activity.
  • Page 12: Power Off

    Status Indicators and Audible Alert Tones Your SP-120 Series has a sophisticated microprocessor control which provides a series of audible alert tones. Upon initial power up, a quick melody indicates that the self-test of the microprocessor functions has been completed satisfactorily.
  • Page 13: Scan Modes

    Scan Modes Scanning is a Dealer programmable feature that allows you to monitor a number of channels. Your Dealer will help you define a channel "scan list" to be programmed into a scan channel (any channel, 1- 4). Once that channel location is selected, scan is initiated. Normal Channel Scan Once the scan list is programmed you can initiate scan.
  • Page 14: Other Scanning Features

    Other Scanning Features • Look Back: Any channel, when not in the scan mode, can be programmed to "look back" at the "Priority" channel. This feature is ideal for those who do not need scan as defined above, but want to make sure that they never miss a call on the "Priority"...
  • Page 15: Licensing And Service Information

    Do not tamper with internal adjustments. Damage to the equipment and/or improper operation may result. There are no user serviceable items inside the radio. It is recommended that you return your radio to a qualified Maxon Dealer for any service or repairs. Recycling/Disposal of Batteries The U.S.
  • Page 16: Software Copyrights

    Maxon software programs stored in semi- conductor memories or other media. Laws in the United States and other countries preserve for Maxon certain exclusive rights for copy- righted software programs, including the exclusive right to copy or reproduce in any form the copyrighted software program.
  • Page 17: Maintenance

    Maintenance Your SP-120 Series Radio is designed to be maintenance free. To keep your radio in good working condition: Clean external surfaces with a clean cloth dampened in a solution of dishwasher detergent diluted in water. Apply the solution sparingly to avoid any moisture leaking into cracks and crevices.
  • Page 18: Limited Warranty

    Maxon is not responsible for any ancillary equipment which is attached or used in connection with this product. Maxon shall have no obligation to make repairs or to cause replace- ment required which result from normal wear and tear or necessitated...
  • Page 19 Maxon America, Inc. Business Radio Division 10828 NW Air World Drive Kansas City, Missouri 64153 816/891-6320, FAX: 816/891-8815 P/N: 680-090-0048...
