Compaq Armada 1500 Service Manual Addendum

Compaq Armada 1500 Service Manual Addendum

Maintenance & service guide addendum
Hide thumbs Also See for Armada 1500:
Table of Contents

Advertisement

Quick Links

See also: Maintenance and Service Manual , User Manual
M
AINTENANCE
& S
G
ERVICE
UIDE
A
DDENDUM
Compaq Armada 1500
Family of Personal Computers

Advertisement

Table of Contents
loading

Related Manuals for Compaq Armada 1500

Summary of Contents for Compaq Armada 1500

  • Page 1 AINTENANCE & S ERVICE UIDE DDENDUM Compaq Armada 1500 Family of Personal Computers...
  • Page 2 Product names mentioned herein may be trademarks and/or registered trademarks of their respective companies. Maintenance and Service Guide Addendum Compaq Armada 1500 Family of Personal Computers First Edition (January 1998) Spare Part Number 255011-001 Document Part Number 255318-001...

  • Page 3: Computer Product Description

    ROM drive, and mechanical enhancements to the base enclosure. A list of standard features and supported options are provided in Chapter 1 of the Maintenance and Service Guide, Compaq Armada 1500 Family of Personal Computers. The following computer models are available:...
  • Page 4 ........Addendum to Compaq Armada 1500 Maintenance and Service Guide 1.2 Features...

  • Page 5: Software Fulfillment

    Replacement software may be ordered directly from Compaq Computer Corporation. Both the model and the serial number of the computer are needed to identify the specific software available. Addendum 255318-001 to Guide 284820-001 Addendum to Compaq Armada 1500 Maintenance and Service Guide...

  • Page 6: External Computer Components

    ........Addendum to Compaq Armada 1500 Maintenance and Service Guide 1.4 External Computer Components...

  • Page 7: Illustrated Parts For The Computer

    4.0 Illustrated Parts for the Computer For an illustrated parts breakdown, refer to the Illustrated Parts Map. The following information provides new spare parts descriptions and part numbers. Addendum 255318-001 to Guide 284820-001 Addendum to Compaq Armada 1500 Maintenance and Service Guide...

  • Page 8: Display Assembly

    Addendum to Compaq Armada 1500 Maintenance and Service Guide The following tables are updated to include the new spare parts. For illustrations of spare parts, refer to the Maintenance and Service Guide, Compaq Armada 1500 Personal Computers or Illustrated Parts Map. Description...

  • Page 9: Hard Drive

    1510, 1510DM, 1520, 1520D, 254963-001 1520DM 1530, 1530D, 1530DM, 254964-001 1535DM, 1550T, 1550DMT 1540D, 1560, 1580DT, 255130-001 1580DMT, 1585DMT, 1590DT 1560D, 1560DM, 1592DT, 255248-001 1592DMT All models 254962-001 All models 254959-001 All models 254960-001 Addendum to Compaq Armada 1500 Maintenance and Service Guide...
  • Page 10 ........Addendum to Compaq Armada 1500...

  • Page 11: Standard And Optional Boards

    1520, 1520D, 1520DM, 1550T, 1550DMT 1530, 1530D, 1530DM, 1535DM 1580DT, 1580DMT, 1585DMT 1540D, 1540DM 1560, 1560D, 1560DM 1590DT, 1590DMT 1592DT, 1592DMT Addendum to Compaq Armada 1500 Maintenance and Service Guide Spare Part Number 254958-001 255049-001 255189-001 255190-001 254956-001 254976-001 255161-001...

  • Page 12: Battery Charger

    ........Addendum to Compaq Armada 1500...

  • Page 13: Miscellaneous Parts

    All models with integrated CD-ROM drives All models 255013-001 All models 254982-001 All models 254980-001 All models 254981-001 All models 255011-001 All models 255012-001 All models 255097-001 All models 255180-001 All models 255181-001 Addendum to Compaq Armada 1500 Maintenance and Service Guide...
  • Page 14 ........Addendum to Compaq Armada 1500...
  • Page 15 Table 4-8 Accessories Models Spare Part Number All models 272108-001 All models 272110-001 All models 220583-001 All models 273158-001 All models 254974-001 All models 255215-001 All models 255245-001 All models 255014-001 Addendum to Compaq Armada 1500 Maintenance and Service Guide...

  • Page 16: Specifications

    ........Addendum to Compaq Armada 1500 Maintenance and Service Guide 9.0 Specifications...
  • Page 17 3.24 12.7mm 12.7mm 3.94 x 2.75 4.01 x 2.75 100.2 x 69.85 102 x 69.85 38.1 to 54.8 51.7 to 83.4 16.6 33.3 4,200 4,000 4928 6975 110-180 144-240 4200 6304 Addendum to Compaq Armada 1500 Maintenance and Service Guide...
  • Page 18 ........Addendum to Compaq Armada 1500...
  • Page 19 7.24 in. 9.7 in. 16 million Over 100:1 0.30 x 0.30 mm 800 x 600 RGB Stripe 130 cd/m Addendum to Compaq Armada 1500 Maintenance and Service Guide Metric 184 mm 245 mm 16 million Over 100:1 0.30 x 0.30 mm...

  • Page 20: Modem Commands

    ........Addendum to Compaq Armada 1500...
  • Page 21 (see the &Zn=x command for further information). The range of n is 0—3. Bong tone detection. n=0, 1 Online data character echo enabled (NOT SUPPORTED, ERROR). Online character echo disabled. Addendum to Compaq Armada 1500 Maintenance and Service Guide Continued...
  • Page 22 ........Addendum to Compaq Armada 1500...
  • Page 23 If the modem is on hook in the idle state, or if the modem is a test state, then the “ERROR” result code is returned, and no action is taken Select S-register r, and write value n to S-register r. Limited to writeable S-registers. Addendum to Compaq Armada 1500 Maintenance and Service Guide Continued...
  • Page 24 ........Addendum to Compaq Armada 1500...
  • Page 25 Disable flow control. Same as \Q0 Reserved Reserved Enables hardware flow control (RTS/CTS). Same as \Q3 (default). Enable software flow control (XON/XOFF). Same as \Q1. Asynchronous mode (default). Reserved Reserved Reserved Reserved Addendum to Compaq Armada 1500 Maintenance and Service Guide Continued...
  • Page 26 ........Addendum to Compaq Armada 1500...
  • Page 27 Disable flow control. Same as &K0. XON/XOFF software flow control. Same as &K4. CTS-only flow control. This is not supported and the response is ERROR. Hardware flow control (RTS/CTS) (default). Same as &K3. Addendum to Compaq Armada 1500 Maintenance and Service Guide Continued...
  • Page 28 ........Addendum to Compaq Armada 1500...
  • Page 29 +VIT=? Queries the DCE for the range of supported values. Addendum 255318-001 to Guide 284820-001 Continued Returns the current microphone gain setting. (0-255) Nominal level for receive gain from microphone (0-255) Returns the current value of the timer Addendum to Compaq Armada 1500 Maintenance and Service Guide configurations Continued...
  • Page 30 ........Addendum to Compaq Armada 1500...

  • Page 31: Fax Commands

    V.21 Channel 2 V.27ter 2400 V.27ter 4800 V.29 7200 V.29 9600 V.17 7200 V.17(short train) 7200 V.17 9600 V.17(short train) 9600 V.17 12000 V.17(short train) 12000 V.17 14400 V.17(short train) 14400 Addendum to Compaq Armada 1500 Maintenance and Service Guide Continued...
  • Page 32 ........Addendum to Compaq Armada 1500...
