Dennis Kirk provides instructions to help our customers better understand how to install the
products we sell. The instructions are exact copies of what the manufacturer includes with the
product being sold.
That means the quality and accuracy of the instructions is solely dependent on what the
manufacturer produces. We do our best to make the text legible and the pictures viewable.
However, the end result depends largely on the quality of instructions the manufacturer
provides.
Therefore, you will find that some instructions are not of the highest quality. Sometimes text is
hard to read and pictures are not easy to see. At times you will find the overall look of the
instructions to be less than professional. However, we feel it is better to provide what we have
rather than provide nothing at all.
To the best of our knowledge the instructions and application information contained in the
instructions is accurate. However, Dennis Kirk assumes no liability related to any errors that
may be contained in the copy of the manufacturer's instructions we provide. Buyers are solely
responsible to insure that product use is consistent with their application.
If you have any questions please contact us at
customerservice@denniskirk.com
or
800-969-7501 so we can further assist you regarding additional product information or any other
business related questions.
Thank you for doing business with Dennis Kirk.
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Sena 50S-01
Summary of Contents for Sena 50S-01
- Page 1 Instruction Disclaimer Dennis Kirk provides instructions to help our customers better understand how to install the products we sell. The instructions are exact copies of what the manufacturer includes with the product being sold. That means the quality and accuracy of the instructions is solely dependent on what the manufacturer produces.
- Page 2 SENA Motorcycle Bluetooth ® coMMunication SySteM with MeSh intercoM™ USER’S GUIDE Version 1.0.1 ENGLISH...
- Page 3 LEGEND: Press and hold button/Jog button/Jog Dial the HOLD Dial for the specified amount specified number of times of time rotate Jog Dial clockwise (right) or ROTATE ROTATE ROTATE counterclockwise (left). rotate while Pressing Jog Dial clockwise (right) or ROTATE ROTATE ROTATE counterclockwise (left).
-
Page 4: Table Of Contents
Wired Boom Microphone 2.3.2 Wired Microphone 2.4 Earbuds 2.5 External Mesh Intercom Antenna gETTing STArTEd 3.1 Button 3.2 Downloadable Sena Software 3.2.1 Sena 50 Utility App 3.2.2 Sena Device Manager 3.3 Powering On and Off 3.4 Charging 3.5 Checking the Battery Level 3.6 Volume Adjustment... - Page 5 TABLE OF CONTENTS CONTINUED 4.2 Second Mobile Phone Pairing - Second Mobile Phone, GPS, and SR10 4.3 Advanced Selective Pairing: Hands-Free or A2DP Stereo 4.3.1 Phone Selective Pairing - Hands-Free Profile 4.3.2 Media Selective Pairing - A2DP Profile 4.4 GPS Pairing MOBilE PHOnE USAgE 5.1 Making and Answering Calls 5.2 Siri and Google Assistant...
- Page 6 TABLE OF CONTENTS CONTINUED 7.6 Toggling Open Mesh/Group Mesh 7.7 Enable/Disable Mic (Default: Enable) BlUETOOTH inTErcOM 8.1 Intercom Pairing 8.2 Two-Way Intercom 8.3 Multi-Way Intercom 8.3.1 Starting a Three-Way Intercom Conference 8.3.2 Starting a Four-Way Intercom Conference 8.3.3 Ending Multi-Way Intercom 8.4 Three-Way Conference Phone Call with Intercom Users 8.5 Group Intercom...
- Page 7 TABLE OF CONTENTS CONTINUED 12. FUncTiOn PriOriTy And FirMwArE UPgrAdES 12.1 Function Priority 12.2 Firmware Upgrades 13. cOnFigUrATiOn SETTing 13.1 Headset Configuration Setting 13.1.1 Delete All Pairings 13.1.2 Remote Control Pairing 13.2 Software Configuration Setting 13.2.1 Speed Dial 13.2.2 Channel Setting (Default: channel 1) 13.2.3 Unit Language 13.2.4...
-
Page 8: About The Motorcycle Bluetooth Communication System With Mesh Intercom
1. ABOUT THE MOTOrcyclE BlUETOOTH cOMMUnicATiOn SySTEM wiTH MESH inTErcOM™ 1.1 Product Details 1.1.1 Headset Main Unit Mesh Intercom Button Status LED Mesh Intercom Antenna Bluetooth Antenna Phone Button Jog Dial DC Power Charging & Firmware Upgrade Port 1.1.2 Universal Clamp Kit Earbud Port Static Boom Microphone... -
Page 9: Package Contents
1 ABOUT THE MOTORCyCLE BLUETOOTH COMMUnICATIOn SySTEM wITH MESH InTERCOM™ 1.2 Package Contents Headset Universal wired Boom wired Main Unit Helmet Clamp Microphone Microphone Hook and Loop Hook and Loop Glued Surface Microphone Fastener for Fastener for Mounting Sponges Boom Microphone wired Microphone Adapter Hook and Loop... -
Page 10: Installing The Headset On Your Helmet
2. InstallIng the headset on Your helmet 2.1 Helmet Installation To securely install the headset on the helmet, please follow this procedure. 1. Insert the back plate of the clamp unit between the internal padding and the external shell of the helmet, and tighten the two screws. Allen Wrench Clamp Unit Note: Depending on the size and shape of your helmet, you may... -
Page 11: Using The Glued Surface Mounting Adapter
2 InStAllIng the heAdSet on YoUr helMet Note: Make sure that the microphone is located properly close to your mouth when you wear the helmet. Adjust the direction of the microphone so that the fin side of the microphone is facing outward, away from your lips. - Page 12 7. Peel off the cover of the adhesive tape of the adapter and attach the unit on the proper surface of your helmet. Caution: Sena recommends using the clamp unit. The glued surface mounting plate is provided for convenience, but is not the recommended mounting method.
-
Page 13: Switching The Microphone
2 InStAllIng the heAdSet on YoUr helMet 2.3 Switching the Microphone If you want to use a different microphone instead of the static boom microphone, please refer to the following steps. 1. Remove the back plate of the clamp unit. 2. -
Page 14: Wired Microphone
2 InStAllIng the heAdSet on YoUr helMet 2.3.2 Wired Microphone In case of the wired microphone, attach the enclosed hook and loop fastener for the wired microphone to the inside of the chin guard for full-face helmets. Place the wired microphone on the hook and loop fastener and connect it to the connector of the clamp unit. -
Page 15: Getting Started
3.2 Downloadable Sena Software 3.2.1 Sena 50 Utility App By simply pairing your phone with your headset, you can use the Sena 50 Utility App for quicker and easier set up and management. • App Features: Mesh Intercom, Bluetooth Intercom, Music, Device settings, Quick Start Guide, and User’s Guide. -
Page 16: Sena Device Manager
3.5 hours of Mesh communication or 6 hours of Bluetooth intercom after charging the headset for 20 minutes. • Any 3rd party USB charger can be used with Sena products if the charger is approved by either the FCC, CE, IC or other locally approved agencies that Sena accepts. -
Page 17: Checking The Battery Level
3 GETTING STARTED 3.5 Checking the Battery Level Instructions are for when powering the headset on. Visual Method HOLD HigH MEDiUM Note: When the battery is low while in use, you will hear a voice prompt saying “Low battery”. 3.6 Volume Adjustment You can raise or lower the volume by rotating the Jog Dial clockwise or counterclockwise. -
Page 18: Pairing The Headset With Other Bluetooth Devices
GPS, MP3 player or Sena SR10 Two-Way Radio Adapter via Mobile Phone Pairing, Second Mobile Phone Pairing and GPS Pairing. The headset can also be paired with up to three other Sena headsets. Pairs with up to Three Sena Headsets... -
Page 19: Pairing When The 50S Is Turned On
4 Pairing the headSet with Other BluetOOth deviCeS 2. With your mobile phone in Bluetooth-pairing mode, select Sena 50S in the list of devices detected. 3. If your mobile phone asks for a PIN, enter 0000. nuMBeR 4.1.2 Pairing When the 50S is Turned On 1. -
Page 20: Second Mobile Phone Pairing - Second Mobile Phone, Gps, And Sr10
“Second mobile phone pairing” = Blue flashing light indicates device is now discoverable. 2. With your mobile phone in Bluetooth-pairing mode, select Sena 50S in the list of devices detected. 3. If your mobile phone asks for a PIN, enter 0000. -
Page 21: Phone Selective Pairing - Hands-Free Profile
“Phone selective pairing” = Blue flashing light indicates device is now discoverable. 2. With your mobile phone in Bluetooth-pairing mode, select Sena 50S in the list of devices detected. 3. If your mobile phone asks for a PIN, enter 0000. -
Page 22: Gps Pairing
= Green flashing lights indicates device is now discoverable. 2. With your Bluetooth device on the GPS navigation screen, select Sena 50S in the list of devices detected. 3. If your Bluetooth device asks for a PIN, enter 0000. nuMBeR... -
Page 23: Mobile Phone Usage
5. MOBILE PHONE USAGE 5.1 Making and Answering Calls Answer a Call End a Call Reject a Call HOLD HOLD Note: If you have a GPS device connected, you will not hear its voice navigations during a phone call. 5.2 Siri and Google Assistant The 50S supports the Siri and Google Assistant access directly. -
Page 24: Speed Dialing
5.3 Speed Dialing 5.3.1 Assigning Speed Dial Presets Speed Dial Presets could be assigned in the settings menu, accessible through Sena Device Manager or Sena 50 Utility App. 5.3.2 Using Speed Dial Presets 1. Enter into the Speed Dial menu. -
Page 25: Stereo Music
6. STEREO MUSIC 6.1 Playing Music with Bluetooth Devices 1. Play or pause music. Play/Pause Music HOLD “[Beep, Beep]” 2. Adjust the volume. Volume Up/Down ROTATE ROTATE 3. Track forward or back. Track Forward/Backward ROTATE ROTATE 6.2 Playing Music with non-Bluetooth Devices You can play music that is stored on non-Bluetooth devices such as MP3 players. -
Page 26: Music Sharing
6 STEREO MUSIC 6.3 Music Sharing You can start sharing music with one intercom friend using Bluetooth stereo music during a two-way intercom conversation and one participant of a Mesh. Both you and your intercom friend can remotely control music playback such as track forward and track back. If you start sharing music while Bluetooth intercom and Mesh Intercom are running at the same time, then music shared during Bluetooth intercom will take priority over music shared during Mesh Intercom. -
Page 27: Mesh Intercom
7. MESH INTERCOM What is Mesh Intercom? Mesh Intercom™ is a dynamic communication system created by Sena that provides instant and effortless bike-to-bike communication without a pre-grouping process. Mesh Intercom allows riders to connect and communicate with nearby users without the need to pair each headset together. -
Page 28: Open Mesh
7 MESH INTERCOM 7.1.1 Open Mesh Open Mesh is an open group intercom function. Users can freely communicate with each other in the same Open Mesh channel and select which channel (1-9) to use through the headset. It can connect with a virtually unlimited number of users in each channel. Channel 1 Channel 2 Channel 9... -
Page 29: Group Mesh
7 MESH INTERCOM 7.1.2 Group Mesh Group Mesh is a closed group intercom function that allows users to join, leave, or rejoin a group intercom conversation without pairing each headset. Users can freely communicate with each other in the same private group in Group Mesh. -
Page 30: Channel Setting (Default: Channel 1)
7 MESH INTERCOM 7.3.1 Channel Setting (Default: channel 1) If the Open Mesh communication experiences interference because other groups are also using channel 1 (default), change the channel. You can select from channels 1 to 9. Channel 1 Channel 2 Channel 9 Enter into the Channel Setting “Channel setting, 1”... -
Page 31: Using Mesh In Group Mesh
7 MESH INTERCOM Note: • Channel Setting always starts with channel 1. • If you do not press any button for approximately 10 seconds in a specific channel, the channel is automatically saved. • If you want to cancel during Channel Setting, tap the Phone Button. -
Page 32: Joining An Existing Group Mesh
7 MESH INTERCOM 2. The headsets complete Mesh Grouping and automatically switch from Open Mesh to Group Mesh. “Group Mesh” Open Mesh Group Mesh Note: • If the Mesh Grouping is not completed within 30 seconds, users will hear a voice prompt, “Grouping failed”. • If you want to cancel during the Mesh Grouping, tap the Mesh Intercom Button or Phone Button. - Page 33 7 MESH INTERCOM 1. One of the current members and a new member enter into Mesh Grouping to join the Existing Group Mesh. (NEW MEMBER) HOLD CURRENT MEMBER IN GROUP MESH “Mesh Grouping” 2. The headsets complete Mesh Grouping. The new members will hear a voice prompt as their headsets automatically switch from Open Mesh to Group Mesh.
-
Page 34: Reset Mesh
7 MESH INTERCOM 7.5 Reset Mesh If a headset in an Open Mesh or Group Mesh resets the Mesh, it will automatically return to Open Mesh (default: channel 1). HOLD 7.6 Toggling Open Mesh/Group Mesh Users are able to toggle between Open Mesh and Group Mesh without resetting the Mesh. -
Page 35: Bluetooth Intercom
Pairing Headset A with Headset B HOLD “Intercom pairing” = Red flashing light indicates device is now discoverable. The 50S will automatically pair with a Sena headset. = Flashing blue LED confirms intercoms are paired. 50S Motorcycle Bluetooth Communication System | 34... -
Page 36: Two-Way Intercom
8 BLUETOOTH INTERCOM 2. Repeat step 1 to pair with Intercom Friends C & D. Last-Come, First-Served Intercom Friend 1 Intercom Intercom Friend 1 Friend 2 Intercom Intercom Intercom Friend 1 Friend 2 Friend 3 8.2 Two-Way Intercom You can start or end an intercom conversation with an Intercom Friend by tapping the Jog Dial. -
Page 37: Multi-Way Intercom
8 BLUETOOTH INTERCOM 8.3 Multi-Way Intercom Multi-Way Intercom enables conference-call-style conversations with up to three Intercom Friends at the same time. While Multi- Way Intercom is in progress, mobile phone connection is temporarily disconnected. However, as soon as Multi-Way Intercom terminates, the mobile phone connection will be reestablished. -
Page 38: Starting A Four-Way Intercom Conference
8 BLUETOOTH INTERCOM 3. Then, you (A) can call the second Intercom Friend (C), or the second Intercom Friend (C) may join the intercom by making an intercom call to you (A). Starting an Intercom Conversation with Intercom Friend C Intercom Friend B Intercom Friend C 4. -
Page 39: Ending Multi-Way Intercom
8 BLUETOOTH INTERCOM 8.3.3 Ending Multi-Way Intercom 1. Press and hold the Jog Dial for 1 second until you hear a beep to terminate all intercom connections. 2. Tap the Jog Dial to disconnect from your first Intercom Friend. Double tap the Jog Dial to disconnect from your second Intercom Friend. -
Page 40: Group Intercom
8 BLUETOOTH INTERCOM 3. To disconnect the mobile phone call during a conference phone call, tap the Phone Button. End Phone Call from Conference Note: When you have an incoming intercom call during a mobile phone call, you will hear high tone double beeps. 8.5 Group Intercom Group Intercom allows you to instantly create a Multi-Way Conference Intercom with three of the most recently paired headsets. -
Page 41: Mesh Intercom Conference With Bluetooth Intercom Participant
Users can use the existing Bluetooth intercom and Mesh Intercom function at the same time. In this case, it is recommended to communicate with other Sena headsets via Bluetooth intercom connection and use Mesh Intercom between 50S headsets. A user who is in Open Mesh or Group Mesh when using Mesh Intercom is able to include up to 3 of their Bluetooth intercom friends. - Page 42 Bluetooth intercom friends while in Open Mesh or Group Mesh when using Mesh Intercom. • If a closed loop is created, as shown below, each user will experience severe noise issues. Sena recommends that a closed loop not be created. Sena Headset...
-
Page 43: Universal Intercom
The intercom distance depends on the performance of the Bluetooth headset to which it is connected. When a non-Sena Bluetooth headset is paired with the Sena headset, if another Bluetooth device is paired via Second Mobile Phone Pairing, it will be disconnected. -
Page 44: Mesh Intercom Conference With Two-Way Universal Intercom Participant
Headset Non-Sena Non-Sena Headset Headset Note: Some non-Sena headsets may not support Multi-Way Universal Intercom. 8.8 Mesh Intercom Conference with Two-way Universal Intercom Participant Users can use the existing Two-way Universal Intercom and Mesh Intercom function at the same time. In this case, it is recommended to communicate with non-Sena headset via Two-way Universal Intercom connection and use Mesh Intercom between 50S headsets. -
Page 45: Using The Fm Radio
9. USING THE FM RADIO 9.1 FM Radio On/Off FM Radio On FM Radio Off HOLD HOLD “FM on” “FM off” 9.2 Seek and Save Radio Stations The “Seek” feature searches for radio stations. 1. Search for radio stations. Seek Stations Forward Seek Stations Backward ROTATE ROTATE... -
Page 46: Scan And Save Radio Stations
1. Scan for stations. Start Scanning 2. The Sena tuner pauses at each station it finds for 8 seconds before moving to the next. 3. Save the current station. The station will be saved as the next preset number. -
Page 47: Temporary Station Preset
Using the methods above, up to 10 radio stations can be stored. You can navigate through the saved stations. Navigate through Preset Stations Note: You can use the Sena Device Manager or the Sena 50 Utility App to save the preset stations. 9.6 Region Selection You can select the proper FM frequency range for your location from the Sena Device Manager or the Sena 50 Utility App. -
Page 48: Ambient Mode
10. Ambient mode You can hear the ambient sound outside of your helmet by activating the Ambient Mode. Start/Stop Ambient Mode Note: The Ambient Mode has higher priority than mobile phone, so you cannot listen to music, or have an intercom conversation if the Ambient Mode is activated. -
Page 49: Voice Command
Volume Down “Hey Sena, Volume Down” Bluetooth Intercom/Mesh Phone Pairing “Hey Sena, Phone Pairing” Intercom/FM Radio/Music Bluetooth Intercom Pairing “Hey Sena, Pairing Intercom” Start/End each “Hey Sena, Intercom Bluetooth Intercom [one, two, three]” Standby/ Bluetooth Turn on Mesh Intercom “Hey Sena, Mesh On”... - Page 50 Note: • You can set a language to another language by using the Unit Language feature on the Sena 50 Utility App. • If you set a language that does not support voice commands, the voice command will works only with English commands.
-
Page 51: Function Priority And Firmware Upgrades
12.2 Firmware Upgrades The headset supports firmware upgrades. You can upgrade the firmware using the Sena Device Manager. Please visit sena.com to check for the latest software downloads. Click Here to Visit sena.com 50S Motorcycle Bluetooth Communication System | 50... -
Page 52: Configuration Setting
13. CONFIGURATION SETTING 13.1 Headset Configuration Setting Access the Configuration Menu Navigate Between Menu Options HOLD ROTATE ROTATE Execute Menu Options Headset Configuration Menu Voice Configuration Menu Tap the Phone Button Delete All Pairings Execute Remote Control Pairing Execute Universal Intercom Pairing Execute Exit Execute... -
Page 53: Delete All Pairings
Remote Control device in pairing mode. 13.2 Software Configuration Setting You can change the settings of the headset through the Sena Device Manager or the Sena 50 Utility App. 13.2.1 Speed Dial Assign phone numbers for speed dialing to make a phone call quickly. - Page 54 13 CONFIGURATION SETTING 13.2.4 Audio Equalizer (Default: Off) You can use the Audio Equalizer to increase/decrease the decibel level of different frequency ranges of audio. Balance will adjust all of the frequency ranges to be the same volume level (0 dB). Bass Boost will increase the bass range of audio (20 Hz - 250 Hz).
-
Page 55: (Default: Disabled)
13 CONFIGURATION SETTING 13.2.8 Bluetooth Intercom Audio Multitasking (Default: Disabled) Audio Multitasking (Bluetooth Intercom Audio Multitasking and Mesh Intercom Audio Multitasking) allows you to have an intercom conversation while simultaneously listening to music, FM radio, or GPS instructions. The overlaid audio is played in the background with reduced volume whenever there is an intercom conversation and will return to normal volume once the conversation is finished. -
Page 56: Hd Intercom (Default: Enable)
13 CONFIGURATION SETTING 13.2.11 HD Intercom (Default: Enable) HD Intercom enhances the two-way intercom audio from normal quality to HD quality. HD Intercom will become temporarily disabled when you enter into a multi-way intercom. If this feature is disabled, the two-way intercom audio will change to normal quality. -
Page 57: Voice Prompt (Default: Enable)
13 CONFIGURATION SETTING 13.2.15 Voice Prompt (Default: Enable) You can disable voice prompts by software configuration settings, but the following voice prompts are always on. - Headset configuration settings menu, battery level indicator, speed dial, FM radio functions 13.2.16 RDS AF Setting (Default: Disable) Radio Data System (RDS) Alternative Frequency (AF) Setting allows a receiver to re-tune to the second frequency location when the first signal becomes too weak. -
Page 58: Troubleshooting
14. TROUBLESHOOTING Please visit sena.com for answers to frequently asked questions. This detailed online FAQ section deals with troubleshooting, illustrates case studies and contains tips on using the headset. Click Here to Visit sena.com 14.1 Fault Reset When the headset is not working properly, you can easily reset the unit: 1. -
Page 59: Factory Reset
14 TROUBLESHOOTING 14.2 Factory Reset To erase all of your settings and start fresh, the headset can be restored to factory default settings using the Factory Reset feature. HOLD “Factory Reset” = Solid red “Headset reset, good-bye” Note: If you press the Phone Button or do not press the Jog Dial within 5 seconds, the reset attempt is canceled and the headset returns to standby mode. - Page 60 ® Hero3 and Hero4 allowing for Bluetooth capabilities. The Bluetooth word mark and logos are owned by the ® Bluetooth SIG, Inc. and any use of such marks by Sena is under license. iPhone and iPod touch are registered ®...
