WI-FI PROFESSIONAL
W EATHE R STATI ON
WITH
FORECAST
INSTRUCTION MANUAL
Welcome!
Congratulations on your new Professional Weather Station and welcome to the
La Crosse Technology family! This product was designed with you in mind by our
hometown team of weather enthusiasts based in La Crosse, Wisconsin.
Model: C83100v3
DC: 110121
Wi-Fi Professional Station
Page | 1
Advertisement
Table of Contents
Related Manuals for La Crosse Technology C83100v3
Summary of Contents for La Crosse Technology C83100v3
- Page 1 INSTRUCTION MANUAL Welcome! Congratulations on your new Professional Weather Station and welcome to the La Crosse Technology family! This product was designed with you in mind by our hometown team of weather enthusiasts based in La Crosse, Wisconsin. Model: C83100v3...
-
Page 2: Table Of Contents
TABL E O F C ON TENTS Wind Speed Readings & History Quick Setup Rainfall Readings & History Quick Mounting Tips Temperature/Humidity Readings & HI/LO Button Functions Records Weather Station Icons Feels Like Temperature Connect to La Crosse View™ App Temperature Trend Arrows Benefits of Connecting to La Crosse View™... -
Page 3: Quick Setup
Q UI CK S ET UP 1. Insert 2 - C batteries into your LTV-W1 or LTV-W2 Wind Sensor. 2. Insert 2 - AA batteries into your LTV-R3 Rain Sensor. 3. Insert 2 - AA batteries into your LTV-TH2 Thermo-Hygro Sensor. 4. -
Page 4: Quick Mounting Tips
Q UI CK M OUNT ING T I PS WIND SPEED Ensure the sensor is mounted vertically – an unobstructed rooftop is ideal. • Your wind sensor should be the tallest object in the area to avoid educed wind speed values. RA IN Mount in an open area, preferably off the ground on a level platform. -
Page 5: Weather Station Icons
WE ATHE R STAT IO N I CO N S PRESSURE INHG 12 HR MPH / KMH Miles or Low Battery 12 Hour Kilometers Indicator Forecast IN / MM Sensor Chance of Inches or Reception Precipitation Millimeters INHG / HPA Inches of Mercury Temperature Forecast... -
Page 6: Connect To La Crosse View™ App
EXTRA SENSOR AREA ICONS: • The Extra Sensor area of your station will default to Pressure when you first power up. • When you choose to add additional sensors, the Sensor Reception Indicator will show in the upper left corner whether Press ure or Sensor reading is displayed. •... - Page 7 When connecting your station we highly recommend following along with our detailed support videos, found here: bit.ly/LaCrosseView_Support_Playlist • Your station’s device ID can be found on the back of the display. • Within 15 minutes after your station connects to the La Crosse View app, you should receive notifications to add your sensors.
-
Page 8: Benefits Of Connecting To La Crosse View
B E N EFITS OF CO NN EC T ING TO LA C RO SSE V IEW™ Connecting You to Your Home Anytime, Anywhere FEATURES STANDALONE CONNECTED Wind Speed Wind Direction Rainfall Data Indoor & Outdoor Temperature “Feels Like” Temperature Indoor &... - Page 9 E N HAN CED LAC RO SSE V IEW C O NNEC TED FEATUR E S. • Advanced Forecast Icons & Chance of Precipitation (12 Hour Forecast) • AccuWeather Daily & Hourly Forecasts • AccuWeather HI/LO Temperatures • AccuWeather Wind Direction •...
-
Page 10: Accuweather Daily Forecasts
AC C UWEAT HER DAI LY F ORECASTS Press the DAILY button on the side of your station to scroll through 7 days of future forecasts. You’ll see changing forecast icons, HI/LO Temperature readings. IMPORTANT: After viewing your Daily Forecast, the display will automatically revert back to the default 12 hour forecast after 10 seconds. -
Page 11: Accuweather Hi/Lo Temperatures
AC C U WEAT HE R H I/ LO TEM PERATUR ES TODAY Shows TO DAY Internet Indicator will appear in bottom right corner when connected. • When connected, your daily AccuWeather HI/LO Temperature predictions will display in this section. •... -
Page 12: Additional Sensors Can Read To Your App
Data Stream Items: Customizable Data Streams to enhance your in-home display: Wind Speed • Wind Direction • Wind Gust • UV Index • Visibility • Dew Point • Percentage of Clouds • Sunrise Time • Sunset Time • Hours of Sunlight • Moon Rise Time • Moon Set Time • Temperature/Humidity • and more! Personal Messages Enter up to 20 characters for special events or reminders, such as:... -
Page 13: Status Messages When Connected
STATU S MESSAGE S W HE N C ON NEC TED Quick Tip: • The Wi-Fi Icon indicates Wi-Fi connection- not necessarily app connection. • The Internet Icons by your Forecast, Wind Direction and HI/LO Temperatures will indicate connection to the La Crosse View App and Weather Server. -
Page 14: Features Of Your Weather Station
FE ATURE S OF YOU R W E AT H ER STATI ON Your station provides most functionality when connected to the La Crosse View app. However it is fully functional as a standalone station. Here we have included the details for various functions of your station: •... -
Page 15: Settings Menu
Note: If you press the LIGHT button to manually adjust the backlight, the Auto Dim feature will resume at the next scheduled time to dim. SE T TI N G S ME N U 1. Hold the SET button for 3 seconds to enter settings menu. 2. -
Page 16: Extra Sensor Area
E X TR A S E NSOR AR E A The Extra Sensor area of your station will show Relative Pressure when you first power up. Optional Extra Sensors: Up to 4 additional Thermo-Hygro, Wind Speed, Water Leak or any combination of these sensors can read to the EXTRA SENSOR area of your display. - Page 17 1. Hold the EXTRA SENSOR button 2. Install batteries in the sensor 3. Press TX button Sensor Barcode ID 4. Allow up to 3 minutes to connect Insert Batteries 5. Scan sensor bar code ID TX Button Station normal display-Pressure showing Water Leak sensor added Delete Extra Sensors from your station: 1.
-
Page 18: Wind Speed Readings & History
WI N D S PEE D R E AD INGS & H I STORY Current Speed: Highest wind speed in past 31 seconds. Samples every 3 seconds Top Speed (1 HR): Highest wind speed in past 60 minute period. Wind Direction: When connected wind direction in letters will replace Top 1HR. Top 1HR will still be viewable in history. -
Page 19: Rainfall Readings & History
Reset Wind Speed History: 1. Press the WIND button to view individual wind speed readings. 2. Hold the MINUS button for five seconds to reset the individual value. 3. Wind speed reading will reset to current wind speed, time and date. RA I N FAL L R E A D IN GS &... - Page 20 1 Year: • Current month plus past 11 months total. Current year will show. Total: • Total rainfall since station was powered on or reset. Note: As time passes without rain, the 1 hour, 24 hour, and 7 day rain totals will count down to zero. Reset Rainfall History: 1.
-
Page 21: Temperature/Humidity Readings & Hi/Lo Records
T E M P E RATUR E / H UM ID IT Y READING S & HI/ LO R EC O R D S Your current Indoor and Outdoor temperature and Humidity are constantly displayed on your weather station. Your station records your HI and LO Temperature and Humidity with time and date of occurrence. 1. -
Page 22: Feels Like Temperature
F E ELS L IKE TE M PE R AT U RE Your “Feels Like” Temperature is a combination of outdoor temperature, humidity and wind speed. It is displayed in the Outdoor Temperature area. • When outdoor temperature is higher than 80˚F, your Feels Like Temperature is showing Heat Index. -
Page 23: Sensor Reception Indicators
SE N S OR RECEP T IO N IN DI CATOR S There are Sensor Reception Indicators for your Temperature/Humidity Sensor, Wind Sensor and Rain Sensor. If you add Extra Sensors, There will be a Sensor Reception Indicator for them as well. •... -
Page 24: Delete Sensors
D EL ET E S E NSO R S 1. Press and release the SENSOR button to view sensor type and ID. 2. Hold the MINUS button to delete the sensor from the station. 3. Deleted sensor can no longer show on station. Batteries should be removed. 4. - Page 25 DE TA ILE D SET U P & MO U N TING LTV-W1 or LTV-W2 Wind Speed Sensor 1. Turn the battery cover of your wind sensor to the left. 2. Install fresh “C” batteries. 3. Carefully align and turn battery cover right to tighten. 4.
- Page 26 LTV-R3 Rain Sensor: 1. Flip open both locking tabs on your rain sensor and lift off the funnel portion. 2. Pull up on the battery cover and remove. 3. Install 2-AA batteries according to polarity. 4. Reposition the battery cover over the battery compartment, and firmly push down to lock it back into place 5.
- Page 27 ∙ Press F/C to select Fahrenheit or Celsius display on sensor. Battery Cover C83100v3 Weather Station: 1. Insert the power cord into a wall outlet, then into your station. Remove the red insulation tab from the CR2032 battery installed in the bottom of your weather station to maintain time/date in the event of a power outage.
-
Page 28: Bonus Station Setup
BO NUS STAT ION SE T UP As an added bonus, we’ve included an LTV-D1 Bonus Station to provide basic temperature and humidity readings in another room of your home. Your Bonus Station will receive its data from the included LTV-TH2 Thermo-Hygro Sensor. -
Page 29: Help Us, Help You
Search for Outdoor Sensor: In the rare event your Bonus Station loses connection with the OUTDOOR Thermo-Hygro sensor, the outdoor readings will show dashes. • Simply hold the +/SEARCH button for 3 seconds to search for the sensor. • The sensor reception icon will flash while searching. Restart: 1. -
Page 30: Specifications
SP E CI FICAT ION S Indoor C83100v3 Temperature Range: 32°F to 99°F (0°C to 37°C) LTV-D1 Temperature Range: 32°F to 122°F (0°C to 50°C) Both Stations Humidity Range: 10% RH to 99%RH Relative Pressure: 23.62 to 32.48 InHg (800 to 1100 hPa) -
Page 31: Care And Maintenance
• Promptly remove expired batteries. WA R RAN T Y & SU PP O RT La Crosse Technology, Ltd. provides a 1-year limited time warranty (from date of purchase) on this product relating to manufacturing defects in materials & workmanship. -
Page 32: Fcc Statement
FCC STATE M EN T This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the in- structions, may cause harmful interference to radio communications.
