- Page 1 POWERED LOUDSPEAKER POWERED SUBWOOFER Owner’s Manual Manuale di istruzioni Bedienungsanleitung Руководство пользователя Mode d’emploi Manual de instrucciones Manual do Proprietário POWERED SPEAKER SYSTEM...
- Page 2 AT T E NT I ON RISQUE DE CHOC ELECTRIQUE-NE PAS OUVRIR CAUTION: ATTENTION : POUR RÉDUIRE LES RISQUES D'ÉLECTROCUTION, NE PAS RETIRER TO REDUCE THE RISK OF ELECTRIC SHOCK, LE CAPOT (OU LE DOS). NE CONTIENT PAS DE PIÈCES NÉCESSITANT DO NOT REMOVE COVER (OR BACK).
- Page 3 Yamaha Corporation of America or its subsidiaries. harmful to the operation of other electronic devices. Compliance with FCC regulations does not guarantee that interference will not * This applies only to products distributed by YAMAHA CORPORATION OF AMERICA. (class B) COMPLIANCE INFORMATION STATEMENT...
-
Page 4: Precautions
• Do not place the product in an unstable position where it compatible. Please check with your Yamaha dealer. might accidentally fall over and cause injuries. • Check the electric plug periodically and remove any dirt or •... - Page 5 Using the product while con- • Always consult qualified Yamaha service personnel if the densation is present can cause damage. If there is reason product installation requires construction work, and make to believe that condensation might have occurred, leave sure to observe the following precautions.
-
Page 6: Table Of Contents
Introduction Thank you for purchasing the Yamaha DZR(-D) series POWERED LOUDSPEAKER and DXS-XLF(-D) series POWERED SUBWOOFER. (See the series product lineup below.) These products are designed for live performance, sound reinforcement and fixed installation sound system applications. This manual explains how to install, set up, and configure the connections for the installers, constructors, or general users familiar with speakers. -
Page 7: Functions
0° y Wheel mounting screws For installing the separately sold Yamaha SPW-1 wheels. If you are not using wheels, do not remove these screws. Otherwise, the leakage of air will affect sound quality. - Page 8 Functions Rear Panel (for both Full-range Speakers and Subwoofers) r Display Shows the settings for various functions. t Main knob Turn the knob to move the cursor that appears in the dis- play and change parameter values. Press the knob to execute a setting.
- Page 9 Functions Power section Dante section (Dante models only) !2 [AC IN] jack Connect the supplied AC power cord here. First, connect the power cord to this product, then insert the power cord !4 Dante jacks plug into the AC outlet. When removing the power cord, These are etherCON jacks for a Dante network.
-
Page 10: Home Screen
- INITIALIZE: Performs initialization. - LOG: Displays recorded logs. Saves logs to USB flash drive. - UPDATE FIRMWARE: Update the firmware for the device, and the Dante module. For details, refer to the Reference Manual on the Yamaha Pro Audio global website. http://www.yamahaproaudio.com/... -
Page 11: Main Menus And Examples Of Screens
INPUT or OUTPUT level setting screen. corresponding settings. Recalling INITIAL DATA allows you to return to the factory settings. For details, refer to the Reference Manual on the Yamaha Pro Audio global website. http://www.yamahaproaudio.com/... -
Page 12: Screen Operations
Screen Operations Full range Subwoofer Basic Operations Main knob ] (Back) key Turn the main knob to select an item. The selected item is highlighted. An arrow > on the right indicates that there is sub menu. Press the main knob to execute a selection. Repeat steps 1 and 2 until you reach the edit parameter screen. -
Page 13: Basic Settings
Basic Settings Full range Subwoofer Basic Systems for Analog Connections System example 1 This example uses only DZR and DXS-XLF series speakers. FOH (L) FOH (R) • Individual analog connections on each bus • For the same sound source, use [THRU/DSP OUT] switch to set to [THRU] (L+R) -
Page 14: Dante Connection
For Dante models (DZR-D and DXS-XLF-D series speakers), you can use Dante devices and Dante Controller to make patches. If you connect to a TF series, CL series, or QL series Yamaha digital mixer, you can make patches without using Dante Controller. In particular, the TF series has a Quick Config function that can be configured easily to make patches automatically. -
Page 15: Cardioid Mode Settings
Cardioid Mode Settings Subwoofer Arrange DXS-XLF(-D) series speakers (hereinafter referred to as DXS-XLF(-D)) so that they are facing in opposite directions. Configure the cardioid mode setting on the screen. (See !2 on page 10.) All other settings (LEVEL, POLARITY, LPF etc.) should be configured to the same settings. NOTE •... -
Page 16: Rotatable Horn
Rotatable Horn Full range: DZR15(-D), DZR12(-D), and DZR10(-D) When shipped from the factory, the directivity of DZR(-D) series speaker in a vertical orientation is the setting which makes the sound expand in a horizontal direction, and inhibits or narrows the sound in a vertical direction. We rec- ommend changing the directivity by rotating the horn when you want to install the DZR(-D) series speaker horizon- tally or when you want to use them as a floor monitor and broaden the directivity. -
Page 17: Installation Examples
If the wire is too long, and the speaker happens to fall, the wire may snap as a result of too much strain. • Make sure to use eye bolts according to the standards and safety regulations in your area. Yamaha cannot be held responsible for damage or injury caused by insufficient strength of the support structure or improper installation. - Page 18 By using the separately sold Yamaha UB-DZR series U-bracket, you can expand the installation possibilities. For instructions on installing the U-bracket, refer to the corresponding manual for the UB-DZR series. Examples NOTE The UB-DZR series can be used together with separately sold optional brackets, such as the Yamaha BBS251 Baton Bracket.
-
Page 19: Optional Accessories (Sold Separately)
Display goes off after a few The protection function for the display is Press either the main knob or the [ moments. active. (back) key to return to the normal display. If any specific problem should persist, please contact your Yamaha dealer. -
Page 20: General Specifications (English Only)
General Specifications (English only) General Specifications 0 dBu is referenced to 0.775 Vrms. DZR315(-D) DZR15(-D) DZR12(-D) DZR10(-D) System Type 3-way, Bi-amped powered speaker, 2-way, Bi-amped powered speaker, Bass-reflex Bass-reflex Frequency Range (-10 dB) 31 Hz – 20 kHz 34 Hz – 20 kHz 39 Hz –... - Page 21 The contents of this manual apply to the latest specifications as of the publishing date. To obtain the latest manual, access the Yamaha website then download the manual file.
- Page 22 Dimensions (English only) Dimensions DZR315(-D) 4xM10 4xM10 2xM10 4xM10 Unit: mm DZR15(-D) 2xM8 3xM10 2xM10 2xM8 2xM10 3xM10 2xM8 Unit: mm...
- Page 23 Dimensions DZR12(-D) 2xM8 3xM10 2xM10 2xM8 2xM10 3xM10 2xM8 Unit: mm DZR10(-D) 2xM8 2xM10 2xM8 2xM8 2xM10 2xM10 2xM8 Unit: mm...
- Page 24 Dimensions DXS18-XLF(-D) Ø35 16 x M6 Unit: mm DXS15-XLF(-D) Ø35 16 x M6 Unit: mm...
- Page 25 About Using BSD-Licensed Software The software used by this product includes components that comply with the BSD license. The restrictions placed on users of software released under a typical BSD license are that if they redistribute such software in any form, with or without modification, they must include in the redistribution (1) a disclaimer of liability, (2) the original copyright notice and (3) a list of licensing provisions.
