  • Page 1 POWERED SPEAKER SYSTEM SYSTÈME D'ENCEINTES AMPLIFIÉES SISTEMA DE ALTAVOZ ACTIVO АКТИВНАЯ АКУСТИЧЕСКАЯ СИСТЕМА パワードスピーカーシステム Owner’s Manual Benutzerhandbuch Mode d’emploi Manual de instrucciones Manual do Proprietário Manuale di istruzioni Руководство пользователя ZH-CN ZH-TW 取扱説明書...
  • Page 3: Fcc Information (U.s.a.)

    If these corrective measures do not produce satisfactory results, please contact the local retailer authorized to distribute this type of product. If you cannot locate the appropriate retailer, please contact Yamaha Corporation of America, 6600 Orangethorpe Ave., Buena Park, CA90620, USA.
  • Page 4: Precautions

    Location and connection compatible. Please check with your Yamaha dealer. • Check the electric plug periodically and remove any dirt or • Do not place the product in an unstable position or a location dust which may have accumulated on it.
  • Page 5: Notice

    The serial number is located on the bottom or rear of the unit. Retain this Owner’s Manual in a safe place for future reference. Yamaha cannot be held responsible for damage caused by * This applies only to products distributed (Ser.No)
  • Page 6: Table Of Contents

    Table of Contents PRECAUTIONS ...............4 NOTICE ...................5 Information................5 Introduction................7 Features...................... 7 Package contents ..................7 Optional items ..................... 7 Controls and Functions............8 Top panel ....................8 Rear panel ....................9 Quick Start Guide..............11 Attaching the line array speaker and spacers ........... 11 Connecting microphones, musical instruments, or audio devices ....
  • Page 7: Introduction

    Introduction Introduction Thank you for purchasing the Yamaha DXL1K powered Package contents speaker! This product is designed for musical events or other live performances. To get the most out of this • Subwoofer x 1 • Dedicated cover x 1...
  • Page 8: Controls And Functions

    If the protection circuit is not an acoustic musical instrument. If you turn the deactivated, please contact your Yamaha dealer. control clockwise (toward CLUB), it will boost the high and low ranges, and create an optimum setting [POWER] LED for playback of sound sources.
  • Page 9: Rear Panel

    Controls and Functions Rear panel Mic/Line input jacks (channels 1-2) [LINK OUT] jack Connect microphones, guitars, electronic musical This jack supports an XLR-type plug. Mixed signals instruments or audio equipment. These are combo are output to the other DXL1K. Alternatively, you can jacks that support both XLR and phone plugs.
  • Page 10 Controls and Functions [AC IN] jack Connect the included power cord here. Connect the power cord to this jack, and then insert the power plug into an AC outlet. Be sure to turn off the power switch before connecting or disconnecting the power cord. I / O (Power) switch Turns the power to the unit on (I) or off (O).
  • Page 11: Quick Start Guide

    Quick Start Guide Quick Start Guide Attaching the line array speaker Connecting microphones, musical and spacers instruments, or audio devices Use the included spacers to install the line array speaker Before making connections, lower the volume level to the at approximately the same height as the ears of the minimum by rotating the [LEVEL] controls counter- audience.
  • Page 12 If you have any questions regarding proper connections, please contact your nearest Yamaha dealer. • Use only the included power cord. Otherwise, heat may be generated or an electrical shock may be caused.
  • Page 13: Storing The Unit

    Install the included, dedicated cover over the DXL1K. Put away the line array speaker and spacers into the pocket that is marked with the Yamaha logo. To move the unit, open the flap on top of the cover and hold the handle on the unit. NOTE...
  • Page 14: Troubleshooting

    Since inadequate ventilation can result in overheating this product, the power may be turned off automatically If a problem persists, please contact your Yamaha dealer. to protect the system from overheating. Arrange the ventilation for better cooling, then turn on the power again.
  • Page 15: General Specifications

    General Specifications General Specifications  Main specifications System Type Powered subwoofer with a line array speaker Frequency Response (–10 dB) 37 Hz - 20 kHz Coverage Angle (Horizontal × Vertical) 170° × 30° Crossover Frequency 240 Hz Maximum Output Level 125 dB SPL (Measured peak, IEC noise@1 m) Power Requirements...
  • Page 16: Input Characteristics

    +10 dBu +24 dBu 0 dBu=0.775 Vrms * The contents of this manual apply to the latest specifications as of the publishing date. To obtain the latest manual, access the Yamaha website then download the manual file. DXL1K Owner’s Manual...
  • Page 17: Dimensions

    General Specifications Dimensions  Subwoofer  Line array speaker  Spacer Unit: mm DXL1K Owner’s Manual...
  • Page 18: Block Diagram

    Block Diagram Block Diagram DXL1K Owner’s Manual...
  • Page 19 MEMO DXL1K Owner’s Manual...
