BEFORE YOU BEGIN

Thank you for selecting the new PROFORM
stepper. The 225C stepper blends advanced engi-
neering with contemporary styling to provide you with
a low-impact workout in the convenience and privacy
of your own home.
For your benefit, read this manual carefully before
you use the PROFORM

PART IDENTIFICATION CHART

Use the drawings below to identify the small parts used in assembly. The number in parenthesis below each
drawing refers to the key number of the part, from the PART LIST on page 10. The second number refers to the
quantity used in assembly. Note: If a part is not found in the parts bag, check to see if it has been
preassembled.
M10 Locknut (15)–8
M8 x 19mm Button
Head Bolt (21)–2
M4 x 12mm Console
Screw (22)–4
All manuals and user guides at all-guides.com
225C
®
225C stepper. If you have
®
M8 Lock Washer (23)–2
M4 x 10mm Screw (28)—8
questions after reading the manual, please call our
Customer Service Department at 08457 089 009. To
help us assist you, please mention the product model
number and serial number when calling. The model
number is PFEOST51080. The serial number can be
found on a decal attached to the stepper (see the front
cover of this manual for the location of the decal).
M10 x 40mm Bolt (25)–2
M10 x 82mm Carriage Bolt (24)–2
M4 x 16mm Screw (27)—4
