- Page 1 Lebensmitteltechnik Translation of the original instructions - Miknetum Type: MPR 400 Rühle GmbH, Beim Signauer Schachen 10, 79865 Grafenhausen Germany Phone: +49 7748-523-11; fax: +49 7748-523-8511 www.original-ruehle.de...
-
Page 2: Table Of Contents
Miknetum MPR 400 Table of contents Safety instructions ................3 Safety instructions ..............3 Remaining risk of accidents ..........6 Intended use ................7 Installation instructions ..............8 Machine transport and setup ..........8 Workplace description ............. 9 Connecting the machine ............10 Operating instructions ..............10... -
Page 3: Safety Instructions
Miknetum MPR 400 1 Safety instructions !!! Observe the safety instructions during the installation, operation, cleaning and maintenance of the Rühle Miknetum! Hazard potentially causing irreversible injuries if disre- garded. Warning potentially causing serious injuries if disre- garded. Note Warning of electrical power. - Page 4 Miknetum MPR 400 a) Completely read and understand these operating instructions before transport, commissioning, setup, operation, cleaning, decommissioning, care/maintenance as well as disman- tling/disposal! b) Prepare work instructions for intended and safe transport, commissioning, setup, operation, cleaning, decommissioning, care/maintenance as well as dismantling/disposal!
- Page 5 Miknetum MPR 400 [The information on the proposed personal protective equip- ment has only an advisory function. A full risk assessment should be carried out before using the product to assess whether the indicated personal protective equipment is suitable for local conditions. Personal protective equipment should conform to the relevant EU standards.]...
-
Page 6: Remaining Risk Of Accidents
Miknetum MPR 400 !!! The maintenance personnel may only carry out work specified as "Regular maintenance" unless any other authorisation has been is- sued in writing by the manufacturer of the machine. The maintenance personnel must observe the work procedures from the "Maintenance"... -
Page 7: Intended Use
Miknetum MPR 400 !!! Maintenance Touching electrical components may cause serious inju- ries or death. Work on electrical equipment of the machine may only be carried out by qualified technicians! Always disconnect machine from the mains during this process! The protective covers may be removed only while per-... -
Page 8: Installation Instructions
Miknetum MPR 400 • Handling/processing products and materials which are not foodstuffs is prohibited! • The lifting aid may be used only for the standard trolleys pro- vided and must not be overloaded! Lifting of persons is strictly prohibited! •... -
Page 9: Workplace Description
Miknetum MPR 400 2.2 Workplace description Swivel range of lid Swivel range of standard trolley support Swivel range of drum Swivel range of standard trolley sup- port... -
Page 10: Connecting The Machine
Miknetum MPR 400 The work area around the machine is at least 0.5 m on all sides; for maintenance work it is at least 1 m; if used as passageway, it is at least 1.2 m. 2.3 Connecting the machine The machine is connected to a three-phase outlet (clockwise rotating field);... - Page 11 Miknetum MPR 400 Before the drum moves automatically, a 5 second alarm (horn) sounds. If the power fails when a user program is being executed the machine will react as follows when the power supply is reinstated: it will start up again automatically and the program will continue from that point at which it was in- terrupted by the power failure.
- Page 12 Miknetum MPR 400 When emptying the drum corresponding appropriate pre- cautions must be taken to ensure that no person stands in the discharge area of the machine! Make sure when mounting (or adjusting) the tumbling arm, mixing arm (alternative blind plug), standard trolley...
-
Page 13: Cleaning Instructions
Miknetum MPR 400 4 Cleaning instructions The Miknetum has been designed to allow for complete cleaning of all parts that come into contact with the food product. 4.1 Safety instructions • Also observe Chapter 1 Safety instructions! • The cleaning staff must notify the supervisor immediately of any defects on the machine! •... -
Page 14: Cleaning Agents And Disinfectants
Miknetum MPR 400 The tablet PC and its holder must be cleaned manually and not exposed to any water jet! All other parts and surfaces may be cleaned only with normal water pressure! 4.2 Cleaning agents and disinfectants Recommended cleaning agents and disinfectants:... -
Page 15: Cleaning Procedure
Miknetum MPR 400 17900 Ökoron® SR Ecological cleaner 1.0 – 5.0 15 – 20 20 – 55 13308, FINK – Because of customer-specific application prohibitions, QAC-containing prod- ucts are sometimes not used since the IFS standard must be met. Possible Antisept G alternative products would be, for example, FT 107 DES. - Page 16 Miknetum MPR 400 Also observe Chapter 1 Safety instructions! Only qualified technicians may carry out repairs on the cool- ing system of the machine! Notify and obtain permission from Rühle customer service if welding or cutting work is required on the machine! Reaching into the inside of the machine by opening the side covers is strictly prohibited when performing "Regular care"...
-
Page 17: Regular Care
Miknetum MPR 400 ➢ Replacement of moving parts, e.g. brass ring drum swivelling (drum side) [The information on the proposed personal protective equipment has only an advisory function. A full risk assessment should be carried out before using the product to assess whether the indicated personal protective equipment is suitable for local conditions. -
Page 18: Regular Maintenance
Miknetum MPR 400 5.2 Regular maintenance Regular maintenance of the machine must be carried out every 2000 hours of operation but at least once per year. Maintenance schedule: a) Inspect the safety devices as described in Chapter 1.1 Safety instructions! -
Page 19: Technical Documentation
Miknetum MPR 400 1. The machine contains a cooling system filled with the refrig- erant R452A. It must be pumped off by a refrigeration in- staller and then disposed of correctly! 2. The following components contain oil: Lid drive (lubricating grease) -
Page 20: Electrical Circuit Diagram
Miknetum MPR 400 Vacuum: 0–90% Lifting aid, load capacity: 400 kg Foundation load: 7,0 kN/m² Emission sound pressure level: L ≤ 70 dB(A) Measured according to: DIN EN ISO 11201 accuracy class 2 Measured when: while idling without product, at maxi- mum speed The data on the type plate principally applies;... -
Page 21: Ec Declaration Of Conformity According To Directive 2006/42/Ec
Miknetum MPR 400 8 EC Declaration of Conformity according to Directive 2006/42/EC The manufacturer hereby declares that the following product Name: Rühle GmbH Type: MPR 400 Legal form: Lebensmitteltechnik Address: Beim Signauer Schachen 10 Designation: Miknetum 79865 Grafenhausen From series no.
