- Page 1 OWNER’S MANUAL MANUEL DE L’UTILISATEUR SA221S...
-
Page 2: Important Safety Instructions
IMPORTA NT SA FET Y IN S TR U C TI ON S This lightning flash with arrowhead symbol, within an The exclamation point within an equilatereal triangle is intended to alert the user to the presence equilateral triangle, is intended to alert the user to the presence of uninsulated “dangerous of important operating and maintenance (servicing) instructions in the literature accompanying voltage”... - Page 3 Synergy SA221S Powered Speaker Thank you for choosing Yorkville’s Synergy SA221S subwoofer, the companion subwoofer to the SA153. The SA series excels in sound reinforcement applications where a line array is desired but cannot be easily accommodated. Cabinet Features The SA221S is constructed of high strength multiply birch plywood for ultimate durability. There are 2 woofers, each 21-inch long-throw.
- Page 4 6. Clip, X-Max, VC-Therm, Activity Indicators The Clip and Limit LED indicators illuminate to guide the user to proper operating levels. Illumination either of the yellow Limit LEDs indicates that a level has been reached where the SA221S limit- ers are reducing the signal internally to prevent damage or distortion. It also indicates that further increases in input level or increasing the SA221S Level control position will not appreciably increase acoustic output.
- Page 5 15 AMP 20 AMP 12A = MAX Output 16A = MAX Output 8A = MAX Output 8A = 80% Output 12A = 90% Output 6A = 90% Output 6A = 60% Output 8A = 80% Output 4A = 80% Output 6A = 60% Output 3A = 60% Output LINE...
- Page 6 Specifications Active Active or Passive 6000 watts program 17000 watts peak Program Power (watts) Measured Max SPL (C-Weighted, Max Hold) 130.6 dB Cont., 142.6 dB Peak Frequency Response (Hz +/- 3dB) 28Hz-100Hz Crossover Frequency (Hz) 50 or 100 Hz lowpass Cabinet Configuration Bass Reflex Driver Configuration...
- Page 7 Enceinte Amplifiée Synergy SA221S Nous vous remercions d’avoir choisi le caisson de basse Synergy SA221S de Yorkville, le caisson de basse compagnon du SA153. La série SA excelle dans les applications de renforcement sonore où un ensemble de lignes est souhaité mais ne peut être facilement installé.
- Page 8 Yorkville Sound pour plus de détails. 5. Commande de Niveau SA221S Cette commande permet de régler le niveau de volume du SA221S par rapport au niveau du signal d’entrée. Les tables de mixage et autres sources audio connectées au SA221S ont tendance à avoir des tensions de sortie différentes, ce qui signifie que la commande de niveau sur le SA221S est utilisé...
- Page 9 15 AMP 20 AMP 12A = MAX Output 16A = MAX Output 8A = MAX Output 8A = 80% Output 12A = 90% Output 6A = 90% Output 6A = 60% Output 8A = 80% Output 4A = 80% Output 6A = 60% Output 3A = 60% Output LINE...
- Page 10 Spécifications Actif Actif ou passif Puissance Nominale (watts) 6000 watts de programme 17000 watts de crête SPL maximum mesuré (pondéré C, maintien maximum) 130,6 dB Cont., 142,6 dB Crête Réponse en fréquence (Hz +/- 3dB) 28Hz-100Hz Fréquence de coupure (Hz) Passe-bas 50 ou 100 Hz Configuration de l'enceinte Bass Reflex...
-
Page 13: Rated Current
Yorkville Synergy Convenience Receptacle Installation (Cascade Installation) RATED CURRENT Table 1 - SYNERGY RATED CURRENT LINE CURRENT RATED LIMIT SWITCH MAINS VOLTAGE MODEL CURRENT (Arms) (Arms) SA102 SA153 120V 60 Hz SA115S (NORTH AMERICA) SA221S 11.0 11.0 SA315S 10.2 10.2 10.2... - Page 14 Installation d'Un Réceptacle de Commodité Yorkville Synergy (Installation en Cascade) COURANT NOMINAL Tableau 1 - COURANT NOMINAL DE SYNERGIE COURANT DE LIGNE COURANT COMMUTATEUR DE LIMITEUR TENSION PRINCIPALE MODÈLE NOMINAL (Armes) (Armes) SA102 SA153 120V 60 Hz SA115S (AMÉRIQUE DU NORD) SA221S 11.0...
- Page 15 Unlimited Warranty Yorkville's two and ten-year unlimited warranty on this product is transferable and does not require registration with Yorkville Sound or your dealer. If this product should fail for any reason within two years of the original purchase date (ten years for the wooden enclosure), simply return it to your Yorkville dealer with original proof of purchase and it will be repaired free of charge.
- Page 16 WORLD HEADQUARTERS CANADA U.S.A. Yorkville Sound Limited Yorkville Sound Inc. 550 Granite Court 4625 Witmer Industrial Estate Pickering, Ontario Niagara Falls, New York L1W 3Y8 CANADA 14305, USA Voice: 905-837-8481 Voice: 716-297-2920 Fax: 905-837-8746 Fax: 716-297-3689 Manual-Owners-SYNERGY-SA221S-00-1v2 • June 24, 2022...
