Grizzly H6188 Instruction Sheet

EYE/EAR INJURY HAZARD!
Wear safety glasses and
hearing protection during
use of this tool!
Always disconnect tool from
air to prevent unexpected
operation during service!
DO NOT EXCEED 120 PSI!
Personal
occur.
Introduction
• 230 RPM free speed
• 30 ft/lbs maximum torque
• 90 PSI operating pressure
• 5 CFM average air consumption
• 92 dB(A) sound level
• ⁄ " Air inlet
1
4
• Forward and reverse
• Short, ergonomic profile
Inventory
A.
⁄ " Industrial Air Ratchet ............................. 1
1
4
Operation
Install any ⁄ " drive socket onto your air ratchet.
1
4
Choose from clockwise (R) to tighten, or coun-
terclockwise (L) to loosen by turning the direc-
tion control on top of the ratchet. Connect the air
ratchet to your regulated air source.
WARNING: NO PORTION OF THIS MANUAL MAY BE REPRODUCED IN ANY SHAPE
OR FORM WITHOUT THE WRITTEN APPROVAL OF GRIZZLY INDUSTRIAL, INC.
INJURY HAZARD!
injury could
COPYRIGHT © JUNE, 2006 BY GRIZZLY INDUSTRIAL, INC.
#PC8324 PRINTED IN TAIWAN
MODEL H6188
⁄ " INDUSTRIAL AIR
1
4
RATCHET
INSTRUCTION SHEET
Figure 1. Model H6188
Air ratchet MUST have 3-4 drops of air tool oil
directly dropped into the air fitting before each use
as shown in Figure 2.
Figure 2. Lubricating directly into air fitting.
If you need help with your new pneumatic tool,
call our Tech Support at: (570) 546-9663.
