Summary of Contents for George Foreman GFGBBQ4BW
- Page 1 4 BURNER GAS BBQ GFGBBQ4BW WARNING: PLEASE ENSURE YOU HAVE READ THROUGH THE SAFETY AND OPERATING INSTRUCTIONS BEFORE USE. PLEASE RETAIN INSTRUCTIONS FOR FUTURE REFERENCE For Customer Services & Spare Parts please call 0345 209 7461 Or visit us at https://www.georgeforeman.co.uk/...
-
Page 2: Table Of Contents
CONTENTS Page(s) Safety instructions BBQ Feature Diagram & Parts List BBQ Assembly 8-23 Attaching Gas Cylinder Disconnecting Gas cylinder Lighting your BBQ Food Safety Tips for use Storage Cleaning and care Troubleshooting 31-32 Guarantee and customer services Notes 34-35... -
Page 3: Safety Instructions
SAFETY INSTRUCTIONS IMPORTANT SAFETY INSTRUCTIONS READ CAREFULLY AND KEEP FOR FUTURE REFERENCE WARNING: • The Barbeque must be installed on a secure level base prior to use. • Read the instructions before using the appliance. • Always light the barbecue with the lid open. •... - Page 4 • The appliance must be installed with 1m clearance in all directions around the appliance and should not be used underneath any overhead obstruction. • In the event of a gas leak, turn off the gas supply at the gas cylinder, extinguish any open flames and keep the lid open.
- Page 5 SAFETY CHECKS BEFORE USE • If you smell gas shut off gas to the appliance, extinguish any open flames, open lid and if the odour continues, keep away from the appliance and immediately call your gas supplier or your fire department.
-
Page 6: Bbq Feature Diagram & Parts List
BBQ FEATURE DIAGRAM & PARTS LIST GFGBBQ4BW... -
Page 7: Bbq Assembly
BBQ PARTS LIST PART DESCRIPTION Right Leg shelf Left Leg Top left leg assembly (Left) Support bracket (Left) Support bracket (Right) Top right leg assembly (Right) Leg Cap Wheel Axle Wheel BBQ Assembly Tea Towel Rail Hook Side Shelf Drip Tray Oil Cup Support Oil Cup Heating Diffuser... - Page 8 BBQ ASSEMBLY...
- Page 9 BBQ ASSEMBLY...
- Page 10 BBQ ASSEMBLY...
- Page 11 BBQ ASSEMBLY...
- Page 12 BBQ ASSEMBLY...
- Page 13 BBQ ASSEMBLY...
- Page 14 BBQ ASSEMBLY...
- Page 15 BBQ ASSEMBLY...
- Page 16 BBQ ASSEMBLY...
- Page 17 BBQ ASSEMBLY...
- Page 18 BBQ ASSEMBLY...
- Page 19 BBQ ASSEMBLY...
- Page 20 BBQ ASSEMBLY...
- Page 21 BBQ ASSEMBLY...
- Page 22 BBQ ASSEMBLY...
- Page 23 BBQ ASSEMBLY...
-
Page 24: Attaching Gas Cylinder
ATTACHING YOUR GAS CYLINDER After purchasing your gas cylinder you will then be ready to set it up with your gas grill. When changing the gas cylinder it must not be near any source of ignition. Position the gas cylinder at the left side of your gas grill, keeping in mind that the bottle must be kept away from heat and in a safe position. -
Page 25: Disconnecting Gas Cylinder
DISCONNECTING YOUR GAS CYLINDER When you have finished using the appliance you must remove the gas cylinder. In order to do this you turn the small lever on the regulator from its open position (vertical) to its closed position (horizontal). Once the gas supply has been turned off you then need to remove the regulator from the gas cylinder. -
Page 26: Lighting Your Bbq
LIGHTING YOUR BBQ USING THE AUTOMATIC IGNITION Caution: The lid must be open when lighting the BBQ Do not stand with your face directly over the gas grill when lighting it. 1. Ensure the dial is in the “OFF” position. 2. -
Page 27: Food Safety
FOOD SAFETY Thoroughly defrost frozen meat and poultry in the refrigerator before cooking. Keep raw meat and poultry separate from cooked foods. Always wash hands after handling raw meat and poultry, before handling any ready to eat foods. Wipe and disinfect surfaces that have been in contact with raw meat and poultry. -
Page 28: Tips For Use
TIPS FOR USE Preheating the grill before barbecuing is important. Follow the Lighting your BBQ instructions, then turn control dial to the “HIGH” position and close the lid to preheat the grill. This will take 10 to 15 minutes depending on conditions such as air temperature and wind. -
Page 29: Storage
STORAGE Your Gas Bottle must be stored outdoors in a well ventilated area and must be disconnected from your gas grill when not being used. Ensure that you are outdoors and away from any sources of ignition before attempting to disconnect your gas bottle from your BBQ. -
Page 30: Cleaning And Care
CLEANING INSTRUCTIONS Ensure the appliance is cold before cleaning. Empty the grease tray after each use and wash in warm soapy water. Grill trays should be cleaned by soaking and washing in warm soapy water. The interior surfaces of the grill housing cover should also be washed with warm, soapy water. -
Page 31: Troubleshooting
TROUBLE SHOOTING PROBLEM POSSIBLE CAUSE PREVENTION/ SOLUTION Gas leaking from Turn off gas at LP tank, if hose is cut or Damaged hose cracked/cut/burned hose cracked, replace hose. Gas leaking from LP tank Mechanical failure due to resting or Turn off LP tank valve and replace. mishandling Gas leaking from LP tank Failure of tank valve from mishandling or... - Page 32 TROUBLE SHOOTING PROBLEM POSSIBLE CAUSE PREVENTION/ SOLUTION Burner will not light using Electrical issues: 1.Replace electrode. ignitor 1. Electrode cracked or broken;” sparks at 2.Tip of electrode should be pointing crack.” toward port hole in burner. The distance 2. Electrode tip not in proper position should be 1/8”...
-
Page 33: Guarantee And Customer Services
GUARANTEE AND CUSTOMER SERVICES This product is guaranteed for 12 months from the date of the original purchase. If any defect arises due to faulty materials or workmanship, the faulty product must be returned to the place of purchase. Refund or replacement is at the discretion of the retailer. The following conditions apply: •... -
Page 34: Notes
4 BURNER GAS BBQ GFGBBQ4BW Made by G2S under license. G2S Ltd, Wigan, WN2 4AY George Foreman is the registered trademark of Spectrum Brands (U.K.) Ltd. Revision 2.2...
