Grizzly G5343 Instruction Sheet

EYE/EAR INJURY HAZARD!
Wear safety glasses and
hearing protection during
use of this tool!
Always disconnect tool from
air to prevent unexpected
operation during service!
Only use cutters rated for
RESPIRATORY HAZARD!
Grinding
dust. Wear the appropriate
protection during use!
Introduction
Generating a fast-cutting 22,000 revolutions per
minute, this professional quality die grinder comes
complete with five ⁄ " and five
1
8
stones in an assortment of shapes and grits for
most grinding chores. Fitted in a molded high-
impact plastic case, this powerful grinder also
includes two changing wrenches.
Inventory
A. Die Grinder ................................................. 1
B. ⁄ " NPT Air Fitting ....................................... 1
1
4
C. Collet Wrenches ......................................... 2
D. Mounted Stones ...................................... 10
E. Wrench Set ................................................. 1
WARNING: NO PORTION OF THIS MANUAL MAY BE REPRODUCED IN ANY SHAPE
OR FORM WITHOUT THE WRITTEN APPROVAL OF GRIZZLY INDUSTRIAL, INC.
INJURY HAZARD!
EXPLOSION HAZARD!
Never exceed 90 PSI!
22,000 RPM or less!
produces
⁄ " shank mounted
1
4
COPYRIGHT © APRIL, 2006 BY GRIZZLY INDUSTRIAL, INC.
#PC8125 PRINTED IN TAIWAN
AIR DIE GRINDER KIT
INSTRUCTION SHEET
fine
Operation
Insert your
with the collet wrenches provided. Change the
collet by removing the collet nut with the wrench
set. Connect the air fitting to the die grinder and
then to your regulated air source.
This micro die grinder MUST have 3-4 drops of oil
directly dropped into the air fitting before each use
as shown in Figure 2.
Figure 2. Lubricating directly into air fitting.
If you need help with your new pneumatic tool,
call our Tech Support at: (570) 546-9663.
MODEL G5343
⁄ " & ⁄ "
1 1
8 4
Figure 1. Model G5343.
