Page 2
HARDWARE LIST 16 PCS 16 PCS 8 PCS 7 PCS 1 PC 1 PC 1 PC 1 PC 8 PCS 4 PCS 1 PC 2 PCS 1 PC 1 PC PARTS LIST 1 - 1PC 2 - 1 PC 3 - 1 PC 4 - 1 PC 5 - 1 PC 6 - 1 PC...
Page 3
ASSEMBLY STEPS STEP 1. Fix part 6 and 7 to part 8 using screws (d). d x 4 Slide part 10 into grooves between parts 6 and 7. STEP 2. Insert quickfit screws to part 9 and insert a x 4 cam locks (b) to parts 6 and 7.
Page 4
ASSEMBLY STEPS STEP 3. Fix inner drawer runners (e) and (f) to i x 4 assembled drawer using screws (i), as shown. e x 1 f x 1 STEP 4. Fix handle 11 to assembled drawer using screws (d). d x 2...
Page 5
ASSEMBLY STEPS STEP 5. Fix outer drawer runners (g) and (h) to parts 2 f x 4 and 3 using screws (i), as shown. Stick (j) to parts 2 and 3, as shown. g x 1 h x 1 j x 4 STEP 6.
Page 6
ASSEMBLY STEPS STEP 7. Insert quickfit screws (a) to part 2 and insert a x 4 camlocks (b) to parts 4 and 5. Insert wooden dowels (c) to part 5. b x 4 Fit panel 4 and 5 to part 2. Turn cam locks clockwise to tighten.
Page 7
ASSEMBLY STEPS STEP 9. Insert quickfit screws (a) a x 4 wooden dowels (c) to part 1. Insert camlocks (b) to parts 2 and 3, as shown. b x 4 Fit panel 1 to parts 2 and 3. Turn cam locks clockwise to tighten. c x 4 STEP 10.
Page 8
ASSEMBLY STEPS STEP 12. For extra stability, it is recommended d x 1 that you fix your bedside table to the wall using the additional hardwares (d, l and n), as shown. l x 1 Should you choose not to affix the product to the wall, serious injury may be caused if the product tips over.
